写在前面
终于又捡起来FLTK了, 先来看看怎么通过FLUID创建一个图形界面并完成回调函数的创建, 参考的是官方教程中关于创建一个CubeView程序的例子, 教程里面很多都与最新版本的FLTK界面不太一致, 但是通过我的摸索还是找出了方法. 下面来分享一下.
创建类
直接点New新建各种类型即可, 一些注意事项在官方文档中给出了, 一些类或者组件的名称都用粗体标出来了(如下图), 需要对应, 不然后面回调函数连接不上.
在CubeViewUI类中主要实现了构造函数以及一个show方法, 用于显示窗体.
最后的结果如下, 这里其实主要是要看清楚是水平组件还是垂直组件, 这个很重要, 其次就是主窗体的大小, 配比要合适.
回调函数
其实就是两行, 主要用于五个主要组件中, 分为两组:
slider
-
Zoom:
cube->size=((Fl_Value_Slider *)o)->value(); cube->redraw(); -
ypan:
cube->pany(((Fl_Value_Slider *)o)->value()); cube->redraw(); -
xpan:
cube->panx(((Fl_Value_Slider *)o)->value()); cube->redraw();
roller
-
vrot:
cube->v_angle(((Fl_Roller *)o)->value()); cube->redraw(); -
hrot
cube->h_angle(((Fl_Roller *)o)->value()); cube->redraw();
CubeView类(显示图形)
最后是主要的显示窗体的类, 这需要在extra Code部分添加头文件声明:
#include "CubeView.h"
这部分代码如下:
// CubeView.h
#include <FL/gl.h>
#include <FL/Fl_Gl_Window.H>
#include <math.h>class CubeView : public Fl_Gl_Window {
public:CubeView(int x, int y, int w, int h, const char *l = 0);// this value determines the scaling factor used to draw the cube.double size;/* Set the rotation about the vertical (y ) axis.** This function is called by the horizontal roller in CubeViewUI* and the initialize button in CubeViewUI.*/void v_angle(float angle) { vAng = angle; };// Return the rotation about the vertical (y ) axis.float v_angle() { return vAng; };/* Set the rotation about the horizontal (x ) axis.** This function is called by the vertical roller in CubeViewUIand the* initialize button in CubeViewUI.*/void h_angle(float angle) { hAng = angle; };// the rotation about the horizontal (x ) axis.float h_angle() { return hAng; };/* Sets the x shift of the cube view camera.** This function is called by the slider in CubeViewUI and the* initialize button in CubeViewUI.*/void panx(float x) { xshift = x; };/* Sets the y shift of the cube view camera.** This function is called by the slider in CubeViewUI and the* initialize button in CubeViewUI.*/void pany(float y) { yshift = y; };/* The widget class draw() override.* The draw() function initialize Gl for another round of* drawing then calls specialized functions for drawing each* of the entities displayed in the cube view.*/void draw();private:/* Draw the cube boundaries* Draw the faces of the cube using the boxv[] vertices, using* GL_LINE_LOOP for the faces. The color is #defined by* CUBECOLOR.*/void drawCube();float vAng, hAng;float xshift, yshift;float boxv0[3];float boxv1[3];float boxv2[3];float boxv3[3];float boxv4[3];float boxv5[3];float boxv6[3];float boxv7[3];
};
// CubeView.cxx
#include "CubeView.h"CubeView::CubeView(int x, int y, int w, int h, const char *l): Fl_Gl_Window(x, y, w, h, l) {vAng = 0.0;hAng = 0.0;size = 10.0;/* The cube definition. These are the vertices of a unit cube* centered on the origin.*/boxv0[0] = -0.5;boxv0[1] = -0.5;boxv0[2] = -0.5;boxv1[0] = 0.5;boxv1[1] = -0.5;boxv1[2] = -0.5;boxv2[0] = 0.5;boxv2[1] = 0.5;boxv2[2] = -0.5;boxv3[0] = -0.5;boxv3[1] = 0.5;boxv3[2] = -0.5;boxv4[0] = -0.5;boxv4[1] = -0.5;boxv4[2] = 0.5;boxv5[0] = 0.5;boxv5[1] = -0.5;boxv5[2] = 0.5;boxv6[0] = 0.5;boxv6[1] = 0.5;boxv6[2] = 0.5;boxv7[0] = -0.5;boxv7[1] = 0.5;boxv7[2] = 0.5;
};
// The color used for the edges of the bounding cube.
#define CUBECOLOR 255, 255, 255, 255
void CubeView::drawCube() {/* Draw a colored cube */
#define ALPHA 0.5glShadeModel(GL_FLAT);glBegin(GL_QUADS);glColor4f(0.0, 0.0, 1.0, ALPHA);glVertex3fv(boxv0);glVertex3fv(boxv1);glVertex3fv(boxv2);glVertex3fv(boxv3);glColor4f(1.0, 1.0, 0.0, ALPHA);glVertex3fv(boxv0);glVertex3fv(boxv4);glVertex3fv(boxv5);glVertex3fv(boxv1);glColor4f(0.0, 1.0, 1.0, ALPHA);glVertex3fv(boxv2);glVertex3fv(boxv6);glVertex3fv(boxv7);glVertex3fv(boxv3);glColor4f(1.0, 0.0, 0.0, ALPHA);glVertex3fv(boxv4);glVertex3fv(boxv5);glVertex3fv(boxv6);glVertex3fv(boxv7);glColor4f(1.0, 0.0, 1.0, ALPHA);glVertex3fv(boxv0);glVertex3fv(boxv3);glVertex3fv(boxv7);glVertex3fv(boxv4);glColor4f(0.0, 1.0, 0.0, ALPHA);glVertex3fv(boxv1);glVertex3fv(boxv5);glVertex3fv(boxv6);glVertex3fv(boxv2);glEnd();glColor3f(1.0, 1.0, 1.0);glBegin(GL_LINES);glVertex3fv(boxv0);glVertex3fv(boxv1);glVertex3fv(boxv1);glVertex3fv(boxv2);glVertex3fv(boxv2);glVertex3fv(boxv3);glVertex3fv(boxv3);glVertex3fv(boxv0);glVertex3fv(boxv4);glVertex3fv(boxv5);glVertex3fv(boxv5);glVertex3fv(boxv6);glVertex3fv(boxv6);glVertex3fv(boxv7);glVertex3fv(boxv7);glVertex3fv(boxv4);glVertex3fv(boxv0);glVertex3fv(boxv4);glVertex3fv(boxv1);glVertex3fv(boxv5);glVertex3fv(boxv2);glVertex3fv(boxv6);glVertex3fv(boxv3);glVertex3fv(boxv7);glEnd();
}; // drawCube
void CubeView::draw() {if (!valid()) {glLoadIdentity();glViewport(0, 0, w(), h());glOrtho(-10, 10, -10, 10, -20000, 10000);glEnable(GL_BLEND);glBlendFunc(GL_SRC_ALPHA, GL_ONE_MINUS_SRC_ALPHA);}glClear(GL_COLOR_BUFFER_BIT | GL_DEPTH_BUFFER_BIT);glPushMatrix();glTranslatef(xshift, yshift, 0);glRotatef(hAng, 0, 1, 0);glRotatef(vAng, 1, 0, 0);glScalef(float(size), float(size), float(size));drawCube();glPopMatrix();
};
主文件(main)
#include "CubeViewUI.h"static int my_handler(int event) {if (event == FL_SHORTCUT) return 1;// eat all shortcut keysreturn 0;
}int main(int argc, char **argv) {CubeViewUI ui;Fl::add_handler(my_handler);ui.show(argc, argv);return Fl::run();
}
这里我加上了句柄函数, 这个函数用来使esc键失效, 否则在窗体中按下esc会直接关闭窗口.
编译链接
重点要说一下编译链接这块.
官方Makefile
先给出官方文档1中的Makefile, 其实用Cmake要方便一些, 但是Makefile也要会写才行.
CXX = $(shell fltk-config --cxx)
DEBUG = -g
CXXFLAGS = $(shell fltk-config --use-gl --use-images --cxxflags ) -I.
LDFLAGS = $(shell fltk-config --use-gl --use-images --ldflags )
LDSTATIC = $(shell fltk-config --use-gl --use-images --ldstaticflags )
LINK = $(CXX)TARGET = cube
OBJS = CubeMain.o CubeView.o CubeViewUI.o
SRCS = CubeView.cxx CubeViewUI.cxx.SUFFIXES: .o .cxx
%.o: %.cxx$(CXX) $(CXXFLAGS) $(DEBUG) -c $<all: $(TARGET)$(LINK) -o $(TARGET) $(OBJS) $(LDSTATIC)$(TARGET): $(OBJS)
CubeMain.o: CubeMain.cxx CubeViewUI.h
CubeView.o: CubeView.cxx CubeView.h CubeViewUI.h
CubeViewUI.o: CubeViewUI.cxx CubeView.hclean: $(TARGET) $(OBJS)rm -f *.o 2> /dev/nullrm -f $(TARGET) 2> /dev/null
CmakeLists
再给出Cmake文件(之前其实就介绍过)
cmake_minimum_required(VERSION 3.24)
project(fltk_proj)set(CMAKE_CXX_STANDARD 17)FIND_PACKAGE(FLTK REQUIRED)# 相当于gcc `-I`参数
include_directories("/opt/homebrew/include")
# 相当于gcc `-L`参数
link_directories("/opt/homebrew/lib")# 相当于gcc `-l`参数
link_libraries("fltk")
link_libraries("Xext")
link_libraries("X11")
link_libraries("m")# 添加可执行程序
add_executable(test1 CubeMain.cxx CubeViewUI.cxx CubeView.cxx)# MESSAGE(${FLTK_LIBRARIES})
TARGET_LINK_LIBRARIES(test1 ${FLTK_LIBRARIES})
最后如果想生成MacOS下的test.app目录, 那么只需要在命令行中输入:
fltk-config --post <前面生成的可执行文件名>
就会在同级目录下生成xxx.app了, 还是相当方便的.
部署.app目录的Shell脚本
后来我发现这个步骤可以通过Shell脚本来完成(fltk-config本质是就是一个可执行的脚本文件)
具体参考了fltk-config源码, 以及2. 脚本如下:
#!/bin/shcompile=$1
case "$compile" in
*.cxx)prog=$(basename "$compile" .cxx);;
*.cpp)prog=$(basename "$compile" .cpp);;
*.cc)prog=$(basename "$compile" .cc);;
*.C)prog=$(basename "$compile" .C);;
*)echo "ERROR: Unknown/bad C++ soure file extension on \"$compile\"!"exit 1;;
esacpost=$prog
echo Creating "$post.app" bundle for desktop...id=$(echo $post | tr ' ' '_')
echo $id# Make the bundle directory and move the executable there
rm -rf "$post.app/Contents/MacOS"
mkdir -p "$post.app/Contents/MacOS"
mv "$post" "$post.app/Contents/MacOS"# Make a shell script that runs the bundled executable
echo "#!/bin/sh" >"$post"
echo 'dir="`dirname \"$0\"`"' >>"$post"
echo 'exec "$dir/'"$post.app/Contents/MacOS/$post"'" "$@"' >>"$post"
chmod +x "$post"# Make the simplest Info.plist needed for an application
cat >"$post.app/Contents/Info.plist" <<EOF
<?xml version="1.0" encoding="UTF-8"?>
<plist version="0.9"><dict><key>CFBundleInfoDictionaryVersion</key><string>6.0</string><key>CFBundleExecutable</key><string>$post</string><key>CFBundleIdentifier</key><string>org.fltk.$id</string><key>CFBundleName</key><string>$post</string><key>CFBundlePackageType</key><string>APPL</string><key>NSHighResolutionCapable</key><true/></dict>
</plist>
EOFecho "done!"用法为:(保存为gen_app.sh)
./gen_app.sh test.cpp
终极版Makefile(集合编译链接与部署)
但是不够简洁, 于是想着把Shell集成在Makefile里面, 于是就有: (部分较官方文档有改动)
CXX = $(shell fltk-config --cxx)
DEBUG = -g
CXXFLAGS = $(shell fltk-config --use-gl --use-images --cxxflags ) -I.
LDFLAGS = $(shell fltk-config --use-gl --use-images --ldflags )
LDSTATIC = $(shell fltk-config --use-gl --use-images --ldstaticflags )
LINK = $(CXX)TARGET = cube
OBJS = CubeMain.o CubeView.o CubeViewUI.o
SRCS = CubeMain.cxx CubeView.cxx CubeViewUI.cxxAPP_NAME= $(TARGET)define info_plist
<?xml version="1.0" encoding="UTF-8"?> \
<plist version="0.9"> \<dict> \<key>CFBundleInfoDictionaryVersion</key> \<string>6.0</string> \<key>CFBundleExecutable</key> \<string>APP_NAME</string> \<key>CFBundleIdentifier</key> \<string>org.fltk.APP_NAME</string> \<key>CFBundleName</key> \<string>APP_NAME</string> \<key>CFBundlePackageType</key> \<string>APPL</string> \<key>NSHighResolutionCapable</key> \<true/> \</dict> \
</plist>
endef.SUFFIXES: .o .cxx
compile: $(SRCS)@echo "compiling..."@$(CXX) $(CXXFLAGS) $(DEBUG) -c $^all: compile link runbundle_app: clean_app package_apprun: compile link $(TARGET)./$(TARGET)package_app: compile link@echo "bundling..."@mkdir -p $(APP_NAME).app/Contents/{MacOS,Resources}@echo '$(info_plist)' > "$(APP_NAME).app/Contents/Info.plist"@sed -e "s/APP_NAME/$(APP_NAME)/g" -i "" "$(APP_NAME).app/Contents/Info.plist"@cp $(TARGET) "$(APP_NAME).app/Contents/MacOS/$(APP_NAME)"
# cp -R "$(FRAMEWORK_PATH)/SDL2.framework" "$(APP_NAME).app/Contents/Resources/"link: $(OBJS)@echo "linking..."@$(LINK) -o $(TARGET) $(OBJS) $(LDSTATIC)clean: clean_app@echo "Delete *.o $(TARGET)..."@rm -f *.o 2> /dev/null@rm -f $(TARGET) 2> /dev/nullclean_app:@echo "Delete $(APP_NAME).app..."@rm -rf $(APP_NAME).app用这套Makefile, 配合clion, 简直无敌!
效果
几点注意
- Makefile缩进需要用制表符, 如果要用空格需要在开头加上
.RECIPEPREFIX := $(.RECIPEPREFIX)<space>, 其中<space>是一个空格. - FLUID界面也会被
esc关闭, 注意保存, 可以通过快捷键⌘+S保存, 然后⌘+⇧+C生成头文件和源码. - 控件通过拖放完成布局, 需要调整部分控件的范围与
step, 例如roller和slider. - 布局应该和回调函数分离, 便于维护, 后续会写相关文章.
