JSqlparser 使用攻略（高效的SQL解析工具）

article/2025/10/5 4:35:20

JSqlparser github地址

目录

    • Maven 引用
      • 远程仓库
      • 依赖包
    • SQL解析
      • 获取SQL中的信息
      • 创建Select的方式
        • 创建Select（非SQL String 创建）
      • Insert 插入字段和值
      • where条件中字段替换
      • 解析SQL例子
        • 获取所有tableNames
        • 自动生成别名
        • SQL函数
        • 单表where条件拼装
        • JOIN 拼装
    • 校验SQL
    • 总结

JSqlParser is a SQL statement parser. It translates SQLs in a traversable hierarchy of Java classes. JSqlParser is not limited to one database but provides support for a lot of specials of Oracle, SqlServer, MySQL, PostgreSQL … To name some, it has support for Oracles join syntax using (+), PostgreSQLs cast syntax using ::, relational operators like != and so on.

JSqlParser 是SQL语句分析的插件，他使用Java语言去解析SQL。sqlparser提供很多的数据库语法解析支持其中支持很多oracle的特殊语法。

可以结合mybatis的拦截修改SQL来实现多租户、SQL拼接甚至联表的功能。

可以参考我之前写的MyBatis 通过拦截修改SQL

Maven 引用

远程仓库

<repositories><repository><id>jsqlparser-snapshots</id><snapshots><enabled>true</enabled></snapshots><url>https://oss.sonatype.org/content/groups/public/</url></repository>
</repositories>

依赖包

<dependency><groupId>com.github.jsqlparser</groupId><artifactId>jsqlparser</artifactId><version>4.4</version>
</dependency>

SQL解析

获取SQL中的信息

public class TestSqlparser {public static void main(String[] args) throws JSQLParserException {// 根据sql创建selectSelect stmt = (Select) CCJSqlParserUtil.parse("SELECT col1 AS a, col2 AS b, col3 AS c FROM table T WHERE col1 = 10 AND col2 = 20 AND col3 = 30");Map<String, Expression> map = new HashMap<>();Map<String, String> mapTable = new HashMap<>();((PlainSelect) stmt.getSelectBody()).getFromItem().accept(new FromItemVisitorAdapter() {@Overridepublic void visit(Table table) {// 获取别名 => 表名mapTable.put(table.getAlias().getName(), table.getName());}});((PlainSelect) stmt.getSelectBody()).getWhere().accept(new ExpressionVisitorAdapter() {@Overridepublic void visit(AndExpression expr) {// 获取where表达式System.out.println(expr);}});for (SelectItem selectItem : ((PlainSelect)stmt.getSelectBody()).getSelectItems()) {selectItem.accept(new SelectItemVisitorAdapter() {@Overridepublic void visit(SelectExpressionItem item) {// 获取字段别名 => 字段名map.put(item.getAlias().getName(), item.getExpression());}});}System.out.println("map " + map);System.out.println("mapTables" + mapTable);}
}

在这里插入图片描述

创建Select的方式

创建Select（非SQL String 创建）

@Test
public void testCreateSelect1 () throws JSQLParserException {Select select1 = SelectUtils.buildSelectFromTable(new Table("mytable"));Select select2 = SelectUtils.buildSelectFromTableAndExpressions(new Table("mytable"), new Column("a"), new Column("b"));Select select3 = SelectUtils.buildSelectFromTableAndExpressions(new Table("mytable"), "a+b", "test");System.out.println(select1.toString());System.out.println(select2.toString());System.out.println(select3.toString());}

在这里插入图片描述

Insert 插入字段和值

@Test
public void testCreateSelect2() throws JSQLParserException {Insert insert = (Insert) CCJSqlParserUtil.parse("insert into mytable (col1) values (1)");System.out.println(insert.toString());//adding a columninsert.getColumns().add(new Column("col2"));//adding a value using a visitorinsert.getItemsList().accept(new ItemsListVisitor() {public void visit(SubSelect subSelect) {throw new UnsupportedOperationException("Not supported yet.");}public void visit(ExpressionList expressionList) {expressionList.getExpressions().add(new LongValue(5));}@Overridepublic void visit(NamedExpressionList namedExpressionList) {}public void visit(MultiExpressionList multiExprList) {throw new UnsupportedOperationException("Not supported yet.");}});System.out.println(insert.toString());//adding another columninsert.getColumns().add(new Column("col3"));//adding another value (the easy way)((ExpressionList) insert.getItemsList()).getExpressions().add(new LongValue(10));System.out.println(insert.toString());
}

在这里插入图片描述

import net.sf.jsqlparser.JSQLParserException;
import net.sf.jsqlparser.expression.LongValue;
import net.sf.jsqlparser.expression.StringValue;
import net.sf.jsqlparser.parser.CCJSqlParserUtil;
import net.sf.jsqlparser.statement.Statement;
import net.sf.jsqlparser.util.deparser.ExpressionDeParser;
import net.sf.jsqlparser.util.deparser.SelectDeParser;
import net.sf.jsqlparser.util.deparser.StatementDeParser;public class ReplaceColumnValues {static class ReplaceColumnAndLongValues extends ExpressionDeParser {@Overridepublic void visit(StringValue stringValue) {this.getBuffer().append("?");}@Overridepublic void visit(LongValue longValue) {this.getBuffer().append("?");}}public static String cleanStatement(String sql) throws JSQLParserException {StringBuilder buffer = new StringBuilder();ExpressionDeParser expr = new ReplaceColumnAndLongValues();SelectDeParser selectDeparser = new SelectDeParser(expr, buffer);expr.setSelectVisitor(selectDeparser);expr.setBuffer(buffer);StatementDeParser stmtDeparser = new StatementDeParser(expr, selectDeparser, buffer);Statement stmt = CCJSqlParserUtil.parse(sql);stmt.accept(stmtDeparser);return stmtDeparser.getBuffer().toString();}public static void main(String[] args) throws JSQLParserException {System.out.println(cleanStatement("SELECT 'abc', 5 FROM mytable WHERE col='test'"));System.out.println(cleanStatement("UPDATE table1 A SET A.columna = 'XXX' WHERE A.cod_table = 'YYY'"));System.out.println(cleanStatement("INSERT INTO example (num, name, address, tel) VALUES (1, 'name', 'test ', '1234-1234')"));System.out.println(cleanStatement("DELETE FROM table1 where col=5 and col2=4"));}
}

输出：

SELECT ?, ? FROM mytable WHERE col = ?
UPDATE table1 A SET A.columna = ? WHERE A.cod_table = ?
INSERT INTO example (num, name, address, tel) VALUES (?, ?, ?, ?)
DELETE FROM table1 WHERE col = ? AND col2 = ?

where条件中字段替换

替换条件字段col_1到col1

@Testpublic void replace () throws JSQLParserException {Select stmt = (Select) CCJSqlParserUtil.parse("SELECT col1 AS a, col2 AS b, col3 AS c FROM table WHERE col_1 = 10 AND col_2 = 20 AND col_3 = 30");System.out.println("before " + stmt.toString());((PlainSelect)stmt.getSelectBody()).getWhere().accept(new ExpressionVisitorAdapter() {@Overridepublic void visit(Column column) {column.setColumnName(column.getColumnName().replace("_", ""));}});System.out.println("after " + stmt.toString());}

在这里插入图片描述

解析SQL例子

Statement stmt = CCJSqlParserUtil.parse("SELECT * FROM tab1");
Statements stmt = CCJSqlParserUtil.parseStatements("SELECT * FROM tab1; SELECT * FROM tab2");
Expression expr = CCJSqlParserUtil.parseExpression("a*(5+mycolumn)");

可以直接将String SQL片段解析成Expression再将expr插入到SQL语句中。

获取所有tableNames

Statement statement = CCJSqlParserUtil.parse("SELECT * FROM MY_TABLE1");
Select selectStatement = (Select) statement;
TablesNamesFinder tablesNamesFinder = new TablesNamesFinder();
List<String> tableList = tablesNamesFinder.getTableList(selectStatement);

自动生成别名

Select select = (Select) CCJSqlParserUtil.parse("select a,b,c from test");
final AddAliasesVisitor instance = new AddAliasesVisitor();
select.getSelectBody().accept(instance);

结果：
SELECT a AS A1, b AS A2, c AS A3 FROM test

SQL函数

/*** SQL 函数* SELECT function(列) FROM 表*/
@Test
public void testFun() throws JSQLParserException {Table t1 = new Table("tab1").withAlias(new Alias("t1").withUseAs(true)); // 表1PlainSelect plainSelect = new PlainSelect();plainSelect.setFromItem(t1); // 设置FROM t1= >  SELECT  FROM tab1 AS t1List<SelectItem> selectItemList = new ArrayList<>(); // 查询元素集合SelectExpressionItem selectExpressionItem001 = new SelectExpressionItem(); // 元素1表达式selectExpressionItem001.setExpression(new Column(t1,"col001"));SelectExpressionItem selectExpressionItem002 = new SelectExpressionItem(); // 元素2表达式selectExpressionItem002.setExpression(new Column(t1,"col002"));selectItemList.add(0, selectExpressionItem001); // 添加入队selectItemList.add(1, selectExpressionItem002); // 添加入队// COUNTSelectExpressionItem selectExpressionItemCount = new SelectExpressionItem(); // 创建函数元素表达式selectExpressionItemCount.setAlias(new Alias("count")); // 设置别名Function function = new Function(); // 创建函数对象  Function extends ASTNodeAccessImpl implements Expressionfunction.setName("COUNT"); // 设置函数名ExpressionList expressionListCount = new ExpressionList(); // 创建参数表达式expressionListCount.setExpressions(Collections.singletonList(new Column(t1, "id")));function.setParameters(expressionListCount); // 设置参数selectExpressionItemCount.setExpression(function);selectItemList.add(2,selectExpressionItemCount);plainSelect.setSelectItems(selectItemList); // 添加查询元素集合入select对象System.err.println(plainSelect); // SELECT t1.col001, t1.col002, COUNT(t1.id) AS count FROM tab1 AS t1
}

单表where条件拼装

/*** 单表SQL查询** @throws JSQLParserException*/
@Test
public void testSelectOneTable() throws JSQLParserException {// 单表全量Table table = new Table("test");Select select = SelectUtils.buildSelectFromTable(table);System.err.println(select); // SELECT * FROM test// 指定列查询Select buildSelectFromTableAndExpressions = SelectUtils.buildSelectFromTableAndExpressions(new Table("test"), new Column("col1"), new Column("col2"));System.err.println(buildSelectFromTableAndExpressions); // SELECT col1, col2 FROM test// WHERE =EqualsTo equalsTo = new EqualsTo(); // 等于表达式equalsTo.setLeftExpression(new Column(table, "user_id")); // 设置表达式左边值equalsTo.setRightExpression(new StringValue("123456"));// 设置表达式右边值PlainSelect plainSelect = (PlainSelect) select.getSelectBody(); // 转换为更细化的Select对象plainSelect.setWhere(equalsTo);System.err.println(plainSelect);//  SELECT * FROM test WHERE test.user_id = '123456'// WHERE  != <>NotEqualsTo notEqualsTo = new NotEqualsTo();notEqualsTo.setLeftExpression(new Column(table, "user_id")); // 设置表达式左边值notEqualsTo.setRightExpression(new StringValue("123456"));// 设置表达式右边值PlainSelect plainSelectNot = (PlainSelect) select.getSelectBody();plainSelectNot.setWhere(notEqualsTo);System.err.println(plainSelectNot);//  SELECT * FROM test WHERE test.user_id <> '123456'// 其他运算符, 参考上面代码添加表达式即可GreaterThan gt = new GreaterThan(); // ">"GreaterThanEquals geq = new GreaterThanEquals(); // ">="MinorThan mt = new MinorThan(); // "<"MinorThanEquals leq = new MinorThanEquals();// "<="IsNullExpression isNull = new IsNullExpression(); // "is null"isNull.setNot(true);// "is not null"LikeExpression nlike = new LikeExpression();nlike.setNot(true); // "not like"Between bt = new Between();bt.setNot(true);// "not between"// WHERE LIKELikeExpression likeExpression = new LikeExpression(); // 创建Like表达式对象likeExpression.setLeftExpression(new Column("username")); // 表达式左边likeExpression.setRightExpression(new StringValue("张%")); // 右边表达式PlainSelect plainSelectLike = (PlainSelect) select.getSelectBody();plainSelectLike.setWhere(likeExpression);System.err.println(plainSelectLike); // SELECT * FROM test WHERE username LIKE '张%'// WHERE INSet<String> deptIds = Sets.newLinkedHashSet(); // 创建IN范围的元素集合deptIds.add("0001");deptIds.add("0002");ItemsList itemsList = new ExpressionList(deptIds.stream().map(StringValue::new).collect(Collectors.toList())); // 把集合转变为JSQLParser需要的元素列表InExpression inExpression = new InExpression(new Column("dept_id "), itemsList); // 创建IN表达式对象，传入列名及IN范围列表PlainSelect plainSelectIn = (PlainSelect) select.getSelectBody();plainSelectIn.setWhere(inExpression);System.err.println(plainSelectIn); // SELECT * FROM test WHERE dept_id  IN ('0001', '0002')// WHERE BETWEEN ANDBetween between = new Between();between.setBetweenExpressionStart(new LongValue(18)); // 设置起点值between.setBetweenExpressionEnd(new LongValue(30)); // 设置终点值between.setLeftExpression(new Column("age")); // 设置左边的表达式，一般为列PlainSelect plainSelectBetween = (PlainSelect) select.getSelectBody();plainSelectBetween.setWhere(between);System.err.println(plainSelectBetween); // SELECT * FROM test WHERE age BETWEEN 18 AND 30//  WHERE AND 多个条件结合,都需要成立AndExpression andExpression = new AndExpression(); // AND 表达式andExpression.setLeftExpression(equalsTo); // AND 左边表达式andExpression.setRightExpression(between);  // AND 右边表达式PlainSelect plainSelectAnd = (PlainSelect) select.getSelectBody();plainSelectAnd.setWhere(andExpression);System.err.println(plainSelectAnd); //  SELECT * FROM test WHERE test.user_id = '123456' AND age BETWEEN 18 AND 30//  WHERE OR 多个条件满足一个条件成立返回OrExpression orExpression = new OrExpression();// OR 表达式orExpression.setLeftExpression(equalsTo); // OR 左边表达式orExpression.setRightExpression(between);  // OR 右边表达式PlainSelect plainSelectOr = (PlainSelect) select.getSelectBody();plainSelectOr.setWhere(orExpression);System.err.println(plainSelectOr); // SELECT * FROM test WHERE test.user_id = '123456' OR age BETWEEN 18 AND 30// ORDER BY 排序OrderByElement orderByElement = new OrderByElement(); // 创建排序对象orderByElement.isAsc(); //  设置升序排列 从小到大orderByElement.setExpression(new Column("col01")); // 设置排序字段PlainSelect plainSelectOrderBy = (PlainSelect) select.getSelectBody();plainSelectOrderBy.addOrderByElements(orderByElement);System.err.println(plainSelectOrderBy); // SELECT * FROM test WHERE test.user_id = '123456' OR age BETWEEN 18 AND 30 ORDER BY col01
}

JOIN 拼装

/*** 多表SQL查询* JOIN / INNER JOIN: 如果表中有至少一个匹配，则返回行* LEFT JOIN: 即使右表中没有匹配，也从左表返回所有的行* RIGHT JOIN: 即使左表中没有匹配，也从右表返回所有的行* FULL JOIN: 只要其中一个表中存在匹配，就返回行*/@Testpublic void testSelectManyTable() {Table t1 = new Table("tab1").withAlias(new Alias("t1").withUseAs(true)); // 表1Table t2 = new Table("tab2").withAlias(new Alias("t2", false)); // 表2PlainSelect plainSelect = new PlainSelect().addSelectItems(new AllColumns()).withFromItem(t1); // SELECT * FROM tab1 AS t1// JOIN ON 如果表中有至少一个匹配，则返回行Join join = new Join(); // 创建Join对象join.withRightItem(t2); // 添加Join的表 JOIN t2 =>JOIN tab2 t2EqualsTo equalsTo = new EqualsTo(); // 添加 = 条件表达式  t1.user_id  = t2.user_idequalsTo.setLeftExpression(new Column(t1, "user_id "));equalsTo.setRightExpression(new Column(t2, "user_id "));join.withOnExpression(equalsTo);// 添加ONplainSelect.addJoins(join);System.err.println(plainSelect); // SELECT * FROM tab1 AS t1 JOIN tab2 t2 ON t1.user_id  = t2.user_id// 设置join参数可实现其他类型join// join.setLeft(true); LEFT JOIN// join.setRight(true);  RIGHT JOIN// join.setFull(true); FULL JOIN// join.setInner(true);
}

校验SQL

String sql = "DROP INDEX IF EXISTS idx_tab2_id;";// validate statement if it's valid for all given databases.
Validation validation = new Validation(Arrays.asList(DatabaseType.SQLSERVER, DatabaseType.MARIADB,DatabaseType.POSTGRESQL, DatabaseType.H2), sql);
List<ValidationError> errors = validation.validate();// validate against pre-defined FeaturesAllowed.DML set
String sql = "CREATE TABLE tab1 (id NUMERIC(10), val VARCHAR(30))";
Validation validation = new Validation(Arrays.asList(FeaturesAllowed.DML), sql);
List<ValidationError> errors = validation.validate();
// only DML is allowed, got error for using a DDL statement
log.error (errors);

Validates metadata such as names of tables, views, columns for their existence or non-existence

java.sql.Connection connection = ...;
String sql = "ALTER TABLE mytable ADD price numeric(10,5) not null";
Validation validation = new Validation(Arrays.asList(new JdbcDatabaseMetaDataCapability(connection,
// NamesLookup: Databases handle names differentlyNamesLookup.UPPERCASE)), sql);
List<ValidationError> errors = validation.validate();// do something else with the parsed statements
Statements statements = validation.getParsedStatements();// check for validation-errors
if (!errors.isEmpty()) {...
}

总结

我们可以借助JSqlparser来解析SQL并且动态拼接生成SQL，在Mybatis-plus中的租户其实也是类似这样实现的。甚至有兴趣的同学可以自己做一个SQL拼装器，将前台筛选的条件转换为SQL进行查询。所有的查询字段、条件、联表等等都做成动态拼装。

参考文章

JSqlParser入门系列(3)-JSqlParser之WHERE、多表Join、函数构建SQL
SqlParser


http://chatgpt.dhexx.cn/article/2k19KdDN.shtml
