JSQLParser 解析复杂SQL 2.0

前言

这段时间，为了开发数据中台项目，我去研究学习了JSQLParser（Java中解析SQL语句的工具），并且结合网上资料，写了一个初步的SQL解析工具类...

正文

时隔三天，我又回来了，因为之前JSQLParser的使用方式果然不太正确😅 。基本上正常的SQL通过JSQLParser都可以完美解析出它的结构。

主要错误如下：

表别名的解析是包含from和join两部分的，之前只解析了from，所以无法获得所有的表。

SQL是可以不断嵌套的，解析的时候必须判断是否含有子查询，然后将子查询的SQL语句递归解析。

没有对union的情况做判断 2023/5/12.

关于字段类型的解析，可以用jdbc查询返回的map，然后判断instanceof的字段类型，非常简单。

这里就贴下最新的代码吧，目前已经支持了嵌套SQL的解析~~

实体类：

NormalSqlStructureDto.class

   /*** SQL语句*/private String sql;/*** 表名*/private List<String> tableNames;/*** 检索项*/private List<String> selectItems;/*** 字段和表的映射关系*/private List<ColMappingDto> colMappings;/*** 表别名映射*/private Map<String, Object> tableAliasMapping;

ColMappingDto.class

 /** 字段名 */private String name;/** 字段别名 */private String alias;/** 关联表 */private Object table;/** 表别名 */private Object tableAlias;/** 字段类型 */private String type;

主要实现类：

public class JsqlParserUtil {/*** 表名列表*/private final static ThreadLocal<List<String>> TABLE_NAME_LIST = new ThreadLocal<>();/*** 查询字段名列表*/private final static ThreadLocal<List<String>> COLUMN_NAME_LIST = new ThreadLocal<>();/*** 表别名映射关系*/private final static ThreadLocal<Map<String, Object>> TABLE_AND_ALIAS_MAPPING = new ThreadLocal<>();/*** 字段映射关系列表*/private final static ThreadLocal<List<ColMappingDto>> COL_MAPPING_LIST = new ThreadLocal<>();private static Logger logger = LoggerFactory.getLogger("JsqlParserUtil");public static void main(String[] args) throws JSQLParserException {//1、获取原始sql输入
//        String sql = "select t1.s_id as id," +
//                "t1.s_name," +
//                "t1.join_date, \n" +
//                "t2.score, \n" +
//                "t2.* \n" +
//                "from schema1.edu_college_student t1\n" +
//                "join schema2.edu_college_test_score t2\n" +
//                "on t2.s_id = t1.s_id \n" +
//                "where 1=1 \n";//        String sql = "select t11.*,t1.* \n" +
//                "from original_data.edu_college_student As t1\n" +
//                "JOIN original_data.edu_college_test_score t11\n" +
//                "on t1.s_id = t11.s_id \n" +
//                "where 1=1 \n";//        String sql = "select t1.*,t1.*,t2.*\n" +
//                "from edu_college_student t1\n" +
//                "join edu_college_test_score t2 on t2.s_id = t1.s_id";//        String sql = "select '1' from meta_dict_type";//        String sql = "select\n" +
//                "  t1.s_id,\n" +
//                "  t1.s_name,\n" +
//                "  max(t2.score) as maxscore,\n" +
//                "  t2.course\n" +
//                "from\n" +
//                "  original_data.edu_college_student t1\n" +
//                "  join original_data.edu_college_test_score t2 on t2.s_id = t1.s_id\n" +
//                "group by\n" +
//                "  t2.course,\n" +
//                "  t1.s_id,\n" +
//                "  t1.s_name";//        String sql = "select t2.id from (select t1.id from (select id from original_data.edu_college_student) t1) t2";//        String sql = "select t1.stime,t1.sscore from (select o.create_time as stime,t.score as sscore from original_data.edu_college_student o join original_data.edu_college_test_score t on t.s_id = o.s_id ) t1";//        String sql = "select t1.s_id as sid, t1.t1.s_name from original_data.edu_college_student t1";//        String sql = "select\n" +
//                "  v1.id as t_id,\n" +
//                "  v1.s_name as t_s_name,\n" +
//                "  v1.join_date as t_date,\n" +
//                "  v1.score As t_score,\n" +
//                "  t3.course AS t_course\n" +
//                "from\n" +
//                "  (\n" +
//                "    select\n" +
//                "      t1.s_id as id,\n" +
//                "      t1.s_name,\n" +
//                "      t1.join_date,\n" +
//                "      t2.score\n" +
//                "    from\n" +
//                "      original_data.edu_college_student t1\n" +
//                "      join original_data.edu_college_test_score t2 on t2.s_id = t1.s_id\n" +
//                "    where\n" +
//                "      1 = 1\n" +
//                "  ) v1\n" +
//                "  join original_data.edu_college_sign_in_situation t3 on t3.s_id = v1.id\n" +
//                "  limit 10";String sql = "select '正常签到' as '签到情况',sum(1) as '次数' from `original_data`.hr_attendance_summary_day where is_early = 0 and is_later = 0 \n" +"union all \n" +"SELECT '迟到' AS '签到情况',if(SUM(is_later)is null,0,SUM(is_later)) AS '次数' FROM `original_data`.hr_attendance_summary_day WHERE is_later = 1\n" +"union all \n" +"SELECT '早退' AS '签到情况',if(SUM(is_early)is null,0,SUM(is_early)) AS '次数' FROM `original_data`.hr_attendance_summary_day WHERE is_early = 1";try {getStructure(sql.replaceAll("[\r\n]", " "), true);} catch (Exception e) {e.printStackTrace();}}/*** 获取SQL结构** @param sql SQL语句* @throws JSQLParserException 解析异常*/public static NormalSqlStructureDto getStructure(String sql, boolean isAlias) throws JSQLParserException {//logger.info("【START】");TABLE_NAME_LIST.set(new ArrayList<>());COLUMN_NAME_LIST.set(new ArrayList<>());TABLE_AND_ALIAS_MAPPING.set(new HashMap<>());COL_MAPPING_LIST.set(new ArrayList<>());NormalSqlStructureDto normalSqlStructureDto = new NormalSqlStructureDto();if (StringUtils.isEmpty(sql)) {throw new ServiceException("请先输入SQL语句");}normalSqlStructureDto.setSql(sql);sql = sql.replaceAll("(\\$\\{\\w*\\})|(\\{\\{\\w+\\}\\})", "''");analysisSql(sql, isAlias, false);normalSqlStructureDto.setSelectItems(COLUMN_NAME_LIST.get());normalSqlStructureDto.setTableNames(TABLE_NAME_LIST.get());normalSqlStructureDto.setTableAliasMapping(TABLE_AND_ALIAS_MAPPING.get());List<ColMappingDto> colMappingDtoList = COL_MAPPING_LIST.get();for (ColMappingDto mapping : colMappingDtoList) {if (Objects.isNull(mapping.getTable()) && Objects.nonNull(mapping.getTableAlias())) {mapping.setTable(TABLE_AND_ALIAS_MAPPING.get().get(mapping.getTableAlias()));}}normalSqlStructureDto.setColMappings(colMappingDtoList);//logger.info("【END】");return normalSqlStructureDto;}/*** 解析SQL** @param sql         SQL语句* @param isAlias     true|false 是否使用别称<br> eg. 【s_id as id】 => 【id】<br>* @param isSubSelect 是否是子查询* @throws JSQLParserException 解析异常*/private static void analysisSql(String sql, boolean isAlias, boolean isSubSelect) throws JSQLParserException {//logger.info("是否是子查询: " + isSubSelect);CCJSqlParserManager parserManager = new CCJSqlParserManager();// 解析SQL为Statement对象Statement statement = parserManager.parse(new StringReader(sql));Select select = (Select) CCJSqlParserUtil.parse(sql);SelectBody selectBody = select.getSelectBody();// 判断是否是union查询if(selectBody instanceof SetOperationList){SetOperationList operationList = (SetOperationList) select.getSelectBody();List<SelectBody> plainSelects = operationList.getSelects();for (SelectBody plainSelect : plainSelects) {analysisSql(plainSelect.toString(), isAlias, isSubSelect);}} else if(selectBody instanceof PlainSelect){analysisSelectBody(isAlias, isSubSelect, statement, select);}}/*** 解析SelectBody** @param isAlias true|false 是否使用别称<br> eg. 【s_id as id】 => 【id】<br>* @param isSubSelect 是否是子查询* @param statement Statement对象* @param select Select对象* @throws JSQLParserException 解析异常*/private static void analysisSelectBody(boolean isAlias, boolean isSubSelect, Statement statement, Select select) throws JSQLParserException {PlainSelect plainSelect = (PlainSelect) select.getSelectBody();// 1.解析表名List<String> tableNameList = getTable(statement);// 表别名映射Map<String, Object> tableMapping = new HashMap<>();tableNameList.forEach(i -> tableMapping.put(i, i));if (CollectionUtils.isEmpty(TABLE_AND_ALIAS_MAPPING.get())) {TABLE_AND_ALIAS_MAPPING.get().putAll(tableMapping);}if (CollectionUtils.isEmpty(TABLE_NAME_LIST.get())) {TABLE_NAME_LIST.get().addAll(tableNameList);}// 字段和表的映射List<ColMappingDto> colMappingList = new ArrayList<>();// 2.解析查询元素 列，函数等getSelectItems(plainSelect, tableNameList, tableMapping, colMappingList, isAlias, isSubSelect);// 3.解析from（可能含有子查询）FromItem fromItem = plainSelect.getFromItem();String fromTable = getFromItem(fromItem, isAlias);//logger.info("from 表名：" + fromTable);// 4.解析joinList<Join> tablewithjoin = getJoinItem(plainSelect);if (!CollectionUtils.isEmpty(tablewithjoin)) {tablewithjoin.forEach(i -> System.out.println("连接方式为：" + i));}}/*** 获取join的项目** @param plainSelect* @return*/private static List<Join> getJoinItem(PlainSelect plainSelect) {// 如果关联后面是子查询，可以通过遍历join集合，获取FromItem rightItem = join.getRightItem();List<Join> joinList = plainSelect.getJoins();if (joinList != null) {for (int i = 0; i < joinList.size(); i++) {//注意 ， leftjoin rightjoin 等等的to string()区别Join join = joinList.get(i);String alias = join.getRightItem().getAlias().toString().trim();String tableName = join.getRightItem().toString().replaceAll("(?i)\\s+as\\s+", " ").replace(alias, "").trim();//logger.info("join 表名：" + join.getRightItem().toString());//logger.info("物理名：" + tableName);//logger.info("别名：" + alias);TABLE_AND_ALIAS_MAPPING.get().put(alias, tableName);}}return joinList;}/*** 获取from的项目** @param fromItem* @return* @throws JSQLParserException 解析异常*/private static String getFromItem(FromItem fromItem, boolean isAlias) throws JSQLParserException {// 判断fromItem属于哪种类型，如果是subSelect类型就是子查询if (fromItem instanceof SubSelect) {//logger.info("-----------------子查询开始-----------------");SelectBody selectBody = ((SubSelect) fromItem).getSelectBody();//logger.info("子查询" + selectBody.toString());analysisSql(selectBody.toString(), true, true);//logger.info("-----------------子查询结束-----------------");}String alias = "";try {alias = fromItem.getAlias().toString().trim();Table table = ((Table) fromItem);String tableName = table.getName();String schemaName = table.getSchemaName();schemaName = StringUtils.isEmpty(schemaName) ? "" : schemaName;String name = schemaName + "." + tableName;//logger.info("物理名：" + name);//logger.info("别名：" + alias);TABLE_AND_ALIAS_MAPPING.get().put(alias, name);} catch (Exception e) {if (StringUtils.isNotEmpty(alias)) {TABLE_AND_ALIAS_MAPPING.get().put(alias, fromItem.toString());}} finally {return fromItem.toString();}}/*** 获取当前查询字段** @param plainSelect* @param tableNameList* @param tableMapping* @param colMappingList*/private static void getSelectItems(PlainSelect plainSelect, List<String> tableNameList, Map<String, Object> tableMapping, List<ColMappingDto> colMappingList, boolean isAlias, boolean isSubSelect) {// 目前不解析子查询if (isSubSelect) {return;}List<SelectItem> selectItems = plainSelect.getSelectItems();List<String> columnList = new ArrayList<>();if (!CollectionUtils.isEmpty(selectItems)) {for (SelectItem selectItem : selectItems) {ColMappingDto colMapping = new ColMappingDto();// 字段名称String columnName = "";// 表别名String tblAlias = "";try {if (selectItem instanceof SelectExpressionItem) {SelectExpressionItem selectExpressionItem = (SelectExpressionItem) selectItem;Alias alias = selectExpressionItem.getAlias();Expression expression = selectExpressionItem.getExpression();Column col = ((Column) expression);Table colTbl = col.getTable();if (Objects.nonNull(colTbl)) {tblAlias = colTbl.getName();}if (!isAlias) {columnName = selectItem.toString();} else if (expression instanceof CaseExpression) {// case表达式columnName = alias.getName();} else if (expression instanceof LongValue || expression instanceof StringValue || expression instanceof DateValue || expression instanceof DoubleValue) {// 值表达式columnName = Objects.nonNull(alias.getName()) ? alias.getName() : expression.getASTNode().jjtGetValue().toString();} else if (expression instanceof TimeKeyExpression) {// 日期columnName = alias.getName();} else {if (alias != null) {columnName = alias.getName();} else {SimpleNode node = expression.getASTNode();Object value = node.jjtGetValue();if (value instanceof Column) {columnName = ((Column) value).getColumnName();} else if (value instanceof Function) {columnName = value.toString();} else {// 增加对select 'aaa' from table; 的支持columnName = String.valueOf(value);columnName = getString(columnName);}}}columnName = getString(columnName);colMapping.setName(col.getColumnName());if (Objects.nonNull(alias) && StringUtils.isNotEmpty(alias.getName())) {colMapping.setAlias(alias.getName());}
//                        colMapping.setTable(tableMapping.get(tblAlias));colMapping.setTableAlias(tblAlias);} else if (selectItem instanceof AllTableColumns) {AllTableColumns allTableColumns = (AllTableColumns) selectItem;columnName = allTableColumns.toString();if (columnName.indexOf(".") > -1) {tblAlias = columnName.substring(0, columnName.indexOf(".")).trim();
