nginx反向代理frps frpc穿透

article/2025/9/11 23:54:56

frps 和 nginx 在同一台机器，假设ip=192.168.166.17

1. frps服务器端配置

测试时，frps服务器跟nginx在同一台机器(192.168.166.17)，理论上可以不在同一台机器，nginx可以代理http请求，发给frps服务端。

frps.ini

  # frps.ini[common]bind_port = 7000vhost_http_port = 8080

启动frps

./frps -c http.ini

2. nginx设置tls负责接受连接解密https，转发到后端给 frps，frps转给frpc，frpc转给最终业务服务器

[root@localhost tstnginx]# cat conf/nginx.conf
user  nobody nobody;
worker_processes 2;error_log  /opt/frps-https-server/tstnginx/logs/error.log;
pid        /opt/frps-https-server/tstnginx/nginx.pid;events {use epoll;worker_connections  10240;
}http {include       mime.types;add_header X-Frame-Options SAMEORIGIN;default_type  application/octet-stream;log_format  main  '$remote_addr $connection/$connection_requests $remote_user [$time_local] $request_length "$request" $status ''"$request_time/$upstream_response_time" "$body_bytes_sent/$content_length" "$http_x_forwarded_for" $upstream_addr ''"$http_referer" "$http_user_agent"';sendfile        on;server_tokens off;keepalive_timeout  1800;keepalive_requests 99999;client_max_body_size 8000m;gzip  on;gzip_http_version 1.0;gzip_comp_level 6;gzip_types text/plain text/css application/x-javascript text/xml application/xml application/xml+rss text/javascript application/javascript application/json;gzip_disable msie6;aio threads;include /opt/frps-https-server/tstnginx/conf/conf.d/*.conf;
}

[root@localhost tstnginx]# cat conf/conf.d/ngx_ap.conf
server {listen      8443;server_name 192.168.166.17;access_log  /opt/frps-https-server/tstnginx/logs/access_1.log  main;aio threads;ssl on;ssl_certificate       /opt/frps-https-server/tstnginx/server-crt/server.crt;ssl_certificate_key   /opt/frps-https-server/tstnginx/server-crt/server.key;ssl_session_cache    shared:SSL:250m;ssl_session_timeout  30m; location / {proxy_set_header Host $host;proxy_set_header X-Real-IP $remote_addr;proxy_set_header X-Forwarded-For $proxy_add_x_forwarded_for;proxy_set_header X-Forwarded-Scheme  $scheme;proxy_pass http://127.0.0.1:8080; #会访问frpc代理的后端服务器 / 接口}location /vpre {proxy_set_header Host $host;proxy_set_header X-Real-IP $remote_addr;proxy_set_header X-Forwarded-For $proxy_add_x_forwarded_for;proxy_set_header X-Forwarded-Scheme  $scheme;proxy_pass http://127.0.0.1:8080/vpre; #会访问frpc代理的后端服务器 /vpre 接口}
}

3. 启动nginx

[root@localhost tstnginx]# sbin/fnginx -p /opt/frps-https-server/tstnginx/

4. 启动frpc和后端服务

假设frpc客户端+后端服务在 192.168.166.11 服务器。

配置 frpc 客户端连接 frps 服务端。# frpc.ini
[common]
server_addr = 192.168.166.17
server_port = 7000[web]
type = http
local_port = 8080
custom_domains = www.myhttp.com
