目录

一、前言

二、推荐开发及运行环境

三、项目基本结构

四、创建一个普通JAVAEE-WEB项目

 五、搭建数据库

 六、pom.xml引入依赖

七、创建实体类

 八、创建三层架构对应模块的类和接口

九、Spring和Mybatis的整合

1、spring的配置文件：

2、Spring和Mybatis的整合配置

3、整合测试

4、测试结果

九、Spring和SpringMVC整合

1、Spring的配置

2、SpringMVC的配置

3、SSM框架整合测试

十、注意事项及其BUG反馈

1、控制台中文乱码解决办法：

 2、Mysql数据库中文乱码解决办法：

 3、服务器日志中文乱码解决办法：

4、出现no appropriate protocal 异常报错

 5、出现java.lang.NoClassDefFoundError：javax/severlet/报错

十一、总结

---

---

一、前言

  最快的提升自己的编程水平以及对某个方向的理解和运用，必然是需要动手实践，在不断的Debug中自我折磨，然后放弃！！！（玩笑）

  本篇文章只是进行基础的SSM框架（Sping+SpringMVC+Mybatis）的整合的教程，以及其中可能遇到的问题的简单解决办法！因为刚开始起手一个项目，自然需要一个过渡阶段，否则前期将会异常艰难。

  废话不多说，开始吧！

全程干货不累赘，开始发车！！

Final Test Result：

二、推荐开发及运行环境

1、系统：Windows10

2、IDE：Interilj ideal 2021.3

3、服务器：Tomacat-8（用高版本对应的Severlet-4.0会启动报错，注意！！）

4、数据库：MySQL5.7

5、浏览器：FireFox

6、JavaKit：JDK18

三、项目基本结构

四、创建一个普通JAVAEE-WEB项目

1、点击File，new，project

 2、创建一个JavaEnterpri项目，选择对应JDK，命名为SSM，选择JavaEE8，然后Finish

 五、搭建数据库

1、创建SSM数据库和tb_book数据表

create database SSM;
create table tb_book(
id int(11) primary key,
name varchar(20) not null,
press varchar(20) not null,
author varchar(20) not null);

 2、插入数据

insert into tb_book(id,name,press,author) values(1,"Moving Earth","人民出版社","刘慈欣");

 六、pom.xml引入依赖

代码如下：（复制粘贴即可）

<?xml version="1.0" encoding="UTF-8"?>
<project xmlns="http://maven.apache.org/POM/4.0.0"xmlns:xsi="http://www.w3.org/2001/XMLSchema-instance"xsi:schemaLocation="http://maven.apache.org/POM/4.0.0 https://maven.apache.org/xsd/maven-4.0.0.xsd"><modelVersion>4.0.0</modelVersion><groupId>com.example</groupId><artifactId>SSM</artifactId><version>1.0-SNAPSHOT</version><name>SSM</name><packaging>war</packaging><properties><project.build.sourceEncoding>UTF-8</project.build.sourceEncoding><maven.compiler.target>1.8</maven.compiler.target><maven.compiler.source>1.8</maven.compiler.source><junit.version>5.8.1</junit.version></properties><dependencies><dependency><groupId>org.springframework</groupId><artifactId>spring-context</artifactId><version>5.2.8.RELEASE</version></dependency><!--Spring事务管理--><dependency><groupId>org.springframework</groupId><artifactId>spring-tx</artifactId><version>5.2.8.RELEASE</version></dependency><dependency><groupId>org.springframework</groupId><artifactId>spring-jdbc</artifactId><version>5.2.8.RELEASE</version></dependency><dependency><groupId>org.springframework</groupId><artifactId>spring-test</artifactId><version>5.2.8.RELEASE</version></dependency><!--Spring MVC的相关依赖--><dependency><groupId>org.springframework</groupId><artifactId>spring-webmvc</artifactId><version>5.2.8.RELEASE</version></dependency><!--MyBatis相关依赖--><dependency><groupId>org.mybatis</groupId><artifactId>mybatis</artifactId><version>3.5.2</version></dependency><!--MyBatis与Spring整合相关依赖--><dependency><groupId>org.mybatis</groupId><artifactId>mybatis-spring</artifactId><version>2.0.1</version></dependency><!--数据源--><dependency><groupId>com.alibaba</groupId><artifactId>druid</artifactId><version>1.1.20</version></dependency><dependency><groupId>javax.servlet</groupId><artifactId>javax.servlet-api</artifactId><version>4.0.1</version></dependency><dependency><groupId>org.apache.cxf</groupId><artifactId>cxf-rt-frontend-jaxrs</artifactId><version>3.4.5</version></dependency><dependency><groupId>org.junit.jupiter</groupId><artifactId>junit-jupiter-api</artifactId><version>${junit.version}</version><scope>test</scope></dependency><dependency><groupId>org.junit.jupiter</groupId><artifactId>junit-jupiter-engine</artifactId><version>${junit.version}</version><scope>test</scope></dependency><dependency><groupId>javax.servlet.jsp</groupId><artifactId>jsp-api</artifactId><version>2.2</version><scope>provided</scope></dependency><!-- 数据库驱动相关依赖--><dependency><groupId>mysql</groupId><artifactId>mysql-connector-java</artifactId><version>8.0.11</version></dependency><dependency><groupId>junit</groupId><artifactId>junit</artifactId><version>4.13</version><scope>test</scope></dependency></dependencies><build><finalName>SSM</finalName><pluginManagement><!-- lock down plugins versions to avoid using Maven defaults (may be moved to parent pom) --><plugins><plugin><artifactId>maven-clean-plugin</artifactId><version>3.1.0</version></plugin><!-- see http://maven.apache.org/ref/current/maven-core/default-bindings.html#Plugin_bindings_for_war_packaging --><plugin><artifactId>maven-resources-plugin</artifactId><version>3.0.2</version></plugin><plugin><artifactId>maven-compiler-plugin</artifactId><version>3.8.0</version></plugin><plugin><artifactId>maven-surefire-plugin</artifactId><version>2.22.1</version></plugin><plugin><artifactId>maven-war-plugin</artifactId><version>3.2.2</version></plugin><plugin><artifactId>maven-install-plugin</artifactId><version>2.5.2</version></plugin><plugin><artifactId>maven-deploy-plugin</artifactId><version>2.8.2</version></plugin></plugins></pluginManagement><plugins><plugin><groupId>org.apache.maven.plugins</groupId><artifactId>maven-war-plugin</artifactId><version>3.3.2</version></plugin></plugins><!-- 如果不添加此节点mybatis的mapper.xml文件都会被漏掉。 --><resources><resource><directory>src/main/java</directory><includes><include>**/*.properties</include><include>**/*.xml</include></includes><filtering>false</filtering></resource><resource><directory>src/main/resources</directory><includes><include>**/*.properties</include><include>**/*.xml</include></includes><filtering>false</filtering></resource></resources></build></project>

七、创建实体类

src/main/java下创建com.itheima.domain包，创建Book实体类

1-1Book.java

package com.itheima.domain;
public class Book {private Integer id;private String name;private  String press;private  String author;public Integer getId(){return id;}public void setId(Integer id){this.id=id;}public void setName(String name) {this.name = name;}public String getName() {return name;}public void setAuthor(String author) {this.author = author;}public String getAuthor() {return author;}public void setPress(String press) {this.press = press;}public String getPress() {return press;}
}

 八、创建三层架构对应模块的类和接口

src/main/java下创建com.itheima.dao包，创建BookMapper接口

1-2 BookMapper.java

package com.itheima.dao;
import com.itheima.domain.Book;
public interface BookMapper {public Book findBookById(Integer id);
}

同目录下创建其映射文件

1-3BookMapper.xml

<?xml version="1.0" encoding="utf-8" ?>
<!DOCTYPE mapperPUBLIC "-//mybatis.org//DTD Mapper 3.0//EN""http://mybatis.org/dtd/mybatis-3-mapper.dtd">
<mapper namespace="com.itheima.dao.BookMapper"><!--根据id查询图书信息 --><select id="findBookById" parameterType="int"resultType="com.itheima.domain.Book">select * from tb_book where id = #{id}</select>
</mapper>

     src/main/java下创建com.itheima.service包，创建BookService接口

        1-4 BookService.java

package com.itheima.service;
import com.itheima.domain.Book;
public interface BookService {Book findBookById(Integer id);
}

src/main/java下创建com.itheima.service.Impl包,创建实现类BookServiceImpl

1-5 BookServiceImpl.java

package com.itheima.service.impl;
import com.itheima.dao.BookMapper;
import com.itheima.domain.Book;
import com.itheima.service.BookService;
import org.springframework.beans.factory.annotation.Autowired;
import org.springframework.stereotype.Service;
@Service
public class BookServiceImpl implements BookService {@Autowiredprivate BookMapper bookMapper;public Book findBookById (Integer id){return bookMapper.findBookById(id);}
}

src/main/java下创建com.itheima.controller包,创建BookController处理器类

1-5 BookController.java

---

package com.itheima.controller;
import com.itheima.domain.Book;
import com.itheima.service.BookService;
import org.springframework.beans.factory.annotation.Autowired;
import org.springframework.stereotype.Controller;
import org.springframework.web.bind.annotation.RequestMapping;
import org.springframework.web.servlet.ModelAndView;
@Controller
public class BookController {@Autowiredprivate BookService bookService;@RequestMapping("/book")public ModelAndView findBookById(Integer id){Book book=bookService.findBookById(id);ModelAndView modelAndView=new ModelAndView();modelAndView.setViewName("book.jsp");modelAndView.addObject("book",book);return modelAndView;}
}

九、Spring和Mybatis的整合

1、spring的配置文件：

src/main/resources目录下创建application-service.xml配置文件

2-1 application-service.xml

<?xml version="1.0" encoding="UTF-8"?>
<beans xmlns="http://www.springframework.org/schema/beans"xmlns:xsi="http://www.w3.org/2001/XMLSchema-instance"xmlns:context="http://www.springframework.org/schema/context"xsi:schemaLocation="http://www.springframework.org/schema/beanshttp://www.springframework.org/schema/beans/spring-beans.xsdhttp://www.springframework.org/schema/contexthttp://www.springframework.org/schema/context/spring-context.xsd"><context:component-scan base-package="com.itheima.service"/>
</beans>

2、Spring和Mybatis的整合配置

src/main/resources目录下创建属性源文件jdbc.properties,用于配置MySQL数据库

2-2 jdbc.properties

jdbc.driverClassName=com.mysql.cj.jdbc.Driver
jdbc.url=jdbc:mysql://localhost:3306/ssm?useUnicode=true\&characterEncoding=utf-8&serverTimezone=Asia/Shanghai
jdbc.username=root
jdbc.password=123456

src/main/resources目录下创建application-dao.xml配置信息

2-3 application-dao.xml

<?xml version="1.0" encoding="UTF-8"?>
<beans xmlns="http://www.springframework.org/schema/beans"xmlns:xsi="http://www.w3.org/2001/XMLSchema-instance"xmlns:context="http://www.springframework.org/schema/context"xsi:schemaLocation="http://www.springframework.org/schema/beanshttp://www.springframework.org/schema/beans/spring-beans.xsdhttp://www.springframework.org/schema/contexthttp://www.springframework.org/schema/context/spring-context.xsd"><context:property-placeholder location="classpath:jdbc.properties"/><bean id="dataSource" class="com.alibaba.druid.pool.DruidDataSource"><property name="driverClassName" value="${jdbc.driverClassName}"/><property name="url" value="${jdbc.url}"/><property name="username" value="${jdbc.username}"/><property name="password" value="${jdbc.password}"/></bean><bean id="sqlSessionFactory"class="org.mybatis.spring.SqlSessionFactoryBean"><property name="dataSource" ref="dataSource"/></bean><bean class="org.mybatis.spring.mapper.MapperScannerConfigurer"><property name="basePackage" value="com.itheima.dao"/></bean>
</beans>

3、整合测试

src/test/java中创建BookServiceTest类

2-4BookServiceTest.java

import com.itheima.domain.Book;
import com.itheima.service.BookService;
import org.junit.Test;
import org.junit.runner.RunWith;
import org.springframework.beans.factory.annotation.Autowired;
import org.springframework.test.context.ContextConfiguration;
import org.springframework.test.context.junit4.SpringJUnit4ClassRunner;
@RunWith(SpringJUnit4ClassRunner.class)
@ContextConfiguration(locations = {"classpath:application-service.xml","classpath:application-dao.xml"})
public class BookServiceTest {
@Autowiredprivate BookService bookService;
@Testpublic void findBookById()
{Book book=bookService.findBookById(2);System.out.println("id:"+book.getId());System.out.println("name:"+book.getName());System.out.println("author:"+book.getAuthor());System.out.println("press:"+book.getPress());
}
}

4、测试结果

测试成功：

九、Spring和SpringMVC整合

1、Spring的配置

在项目webapp/WEB-INF的web.xml中输入以下代码

3-1 web.xml

<?xml version="1.0" encoding="UTF-8"?>
<web-app xmlns="http://xmlns.jcp.org/xml/ns/javaee"xmlns:xsi="http://www.w3.org/2001/XMLSchema-instance"xsi:schemaLocation="http://xmlns.jcp.org/xml/ns/javaee http://xmlns.jcp.org/xml/ns/javaee/web-app_4_0.xsd"version="4.0"><context-param><param-name>contextConfigLocation</param-name><param-value>classpath:application-*.xml</param-value></context-param><listener><listener-class>org.springframework.web.context.ContextLoaderListener</listener-class></listener><servlet><servlet-name>DispatcherServlet</servlet-name><servlet-class>org.springframework.web.servlet.DispatcherServlet</servlet-class><init-param><param-name>contextConfigLocation</param-name><param-value>classpath:spring-mvc.xml</param-value></init-param><load-on-startup>1</load-on-startup></servlet><servlet-mapping><servlet-name>DispatcherServlet</servlet-name><url-pattern>/</url-pattern></servlet-mapping>
</web-app>

2、SpringMVC的配置

src/main/resources目录下创建Spring-mvc.xml配置信息

 3-2 spring-mvc.xml

<?xml version="1.0" encoding="UTF-8"?>
<beans xmlns="http://www.springframework.org/schema/beans"xmlns:context="http://www.springframework.org/schema/context"xmlns:mvc="http://www.springframework.org/schema/mvc"xmlns:xsi="http://www.w3.org/2001/XMLSchema-instance"xsi:schemaLocation="http://www.springframework.org/schema/beanshttp://www.springframework.org/schema/beans/spring-beans.xsdhttp://www.springframework.org/schema/mvchttp://www.springframework.org/schema/mvc/spring-mvc.xsdhttp://www.springframework.org/schema/contexthttp://www.springframework.org/schema/context/spring-context.xsd"><context:component-scan base-package="com.itheima.controller"/><mvc:annotation-driven/>
</beans>

3、SSM框架整合测试

src/main/webapp下创建book.jsp文件

3-4 book.jsp

<%@ page contentType="text/html;charset=UTF-8" language="java" %>
<html>
<head><title>图书信息查询</title>
</head>
<body>
<table border="1">
<tr><th>图书id</th><th>图书名称</th><th>出版社</th><th>作者</th>
</tr>
<tr><td>${book.id}</td><td>${book.name}</td><td>${book.press}</td><td>${book.author}</td>
</tr>
</table>
</body>
</html>

启动Tomcat8，在浏览器输入

http://localhost:8082/SSM_war_exploded/book?id=1

 其中8082为端口号，我的填的是8082，默认是8080，根据自己的配置改就行！

 结果：

十、注意事项及其BUG反馈

1、控制台中文乱码解决办法：

Settings->Editor->File Encodings->三个部分如图都改为GBK即可

 2、Mysql数据库中文乱码解决办法：

修改数据库字符集 :

alter database SSM default convert to character set utf8;

 3、服务器日志中文乱码解决办法：

找到对应的Tomcat-8存储地址，在conf中找到

logging.properties文件，将全部GBk替换成UTF-8即可



4、出现no appropriate protocal 异常报错

找到对应位置jdk，把java.security中的

dk.tls.disabledAlgorithms=后的SSLv3，TLSv1，TLSv1.1删除，

如图大概在724行，删除后如图：



 5、出现java.lang.NoClassDefFoundError：javax/severlet/报错

是由于Tomcat高版本不支持4.0版本的Sevrlet导致，更换低版本Tomcat即可

十一、总结

  总体来说，当开始着手一个WEB项目时，总会由于各种原因导致各种BUG，需要花费大量的时间去排查和调试，才能一步步把最后的项目运行出来，因此需要考虑的方面有很多，重要的是必须看懂编译器报错的原因，从而分析出可行的解决办法。

 只有不断的鞭策自己去实践和学习，积累Debug的能力和经验，才能慢慢获得进步！
