sklearn官方例子——用半监督学习做数字识别
什么是半监督学习
半监督学习很重要,为什么呢?因为人工标注数据成本太高,现在大家参加比赛的数据都是标注好的了,那么如果老板给你一份没有标注的数据,而且有几百万条,让你做个分类什么的,你怎么办?不可能等标注好数据再去训练模型吧,所以你得会半监督学习算法。
不过我在这里先打击大家一下,用sklearn的包做不了大数据量的半监督学习,我用的数据量大概在15000条以上就要报MemoryError错误了,这个是我最讨厌的错误。暂时我还没有解决的办法,如果同志们是小数据量,那就用这个做着玩玩吧
算法流程假设我们有一份数据集,共330个数字,其中前十个是已知的,已经标注好了,后320个是未知的,需要我们预测出来的。
- 首先把这330个数据全部都放到半监督学习算法里,训练模型,预测那320个标签
- 然后用某种方法(看下面代码的操作)得知这320个数据里最不确定的前5个数据,对它进行人工标注,然后把它放到之前的10个数据里,现在就有15个已知数据了
- 这样循环个几次,已标注的数据就变多了,那么分类器的效果肯定也就变好了
即
- 一共330个点,都是已经标注好的了,我们把其中的320个点赋值为-1,这样就可以假装这320个点都是没有标注的了
- 训练一个只有10个标记点的标签传播模型
- 然后从所有数据中选择要标记的前五个最不确定的点,把它们(带有正确标签)放到原来的10个点中
- 接下来可以训练15个标记点(原始10个 + 5个新点)
- 重复这个过程四次,就可以使用30个标记好的点来训练模型
- 可以通过改变max_iterations将这个值增加到30以上
LabelSpreading是一个半监督学习模型
import numpy as np import matplotlib.pyplot as plt from scipy import stats from sklearn import datasets from sklearn.semi_supervised import label_propagation from sklearn.metrics import classification_report,confusion_matrix# 再加下面这个,不然会报错 from scipy.sparse.csgraph import *digits = datasets.load_digits() rng = np.random.RandomState(0)# indices是随机产生的0-1796个数字,且打乱 #indices:[1081 1707 927 ... 1653 559 684] indices = np.arange(len(digits.data)) rng.shuffle(indices)# 取前330个数字来玩 X = digits.data[indices[:330]] y = digits.target[indices[:330]] images = digits.images[indices[:330]]n_total_samples = len(y) # 330 n_labeled_points = 10 # 标注好的数据共10条 max_iterations = 5 # 迭代5次#未标注的数据320条 #即[10 11 12 ... 329] unlabeled_indices = np.arange(n_total_samples)[n_labeled_points:] f = plt.figure() # 画图用的for i in range(max_iterations):if len(unlabeled_indices) == 0:print("no unlabeled items left to label") # 没有未标记的标签了,全部标注好了breaky_train = np.copy(y)y_train[unlabeled_indices] = -1 #把未标注的数据全部标记为-1,也就是后320条数据lp_model = label_propagation.LabelSpreading(gamma=0.25,max_iter=5) # 训练模型lp_model.fit(X,y_train)predicted_labels = lp_model.transduction_[unlabeled_indices] # 预测的标签true_labels = y[unlabeled_indices] # 真实的标签print('**************************')print(predicted_labels)print(true_labels)print('**************************')cm = confusion_matrix(true_labels,predicted_labels,labels = lp_model.classes_)print("iteration %i %s" % (i,70 * "_")) # 打印迭代次数print("Label Spreading model: %d labeled & %d unlabeled (%d total)"% (n_labeled_points,n_total_samples-n_labeled_points,n_total_samples))print(classification_report(true_labels,predicted_labels))print("Confusion matrix")print(cm)# 计算转换标签分布的熵# lp_model.label_distributions_作用是Categorical distribution for each itempred_entropies = stats.distributions.entropy(lp_model.label_distributions_.T)# 选择分类器最不确定的前5位数字的索引# 首先计算出所有的熵,也就是不确定性,然后从320个中选择出前5个熵最大的# numpy.argsort(A)提取排序后各元素在原来数组中的索引。具体情况可看下面# np.in1d 用于测试一个数组中的值在另一个数组中的成员资格,返回一个布尔型数组。具体情况可看下面uncertainty_index = np.argsort(pred_entropies)[::1]uncertainty_index = uncertainty_index[np.in1d(uncertainty_index,unlabeled_indices)][:5] # 这边可以确定每次选前几个作为不确定的数,最终都会加回到训练集# 跟踪我们获得标签的索引delete_indices = np.array([])# 可视化前5次的结果if i < 5:f.text(.05,(1 - (i + 1) * .183),'model %d\n\nfit with\n%d labels' %((i + 1),i*5+10),size=10)for index,image_index in enumerate(uncertainty_index):# image_index是前5个不确定标签# index就是0-4image = images[image_index]# 可视化前5次的结果if i < 5:sub = f.add_subplot(5,5,index + 1 + (5*i))sub.imshow(image,cmap=plt.cm.gray_r)sub.set_title("predict:%i\ntrue: %i" % (lp_model.transduction_[image_index],y[image_index]),size=10)sub.axis('off')# 从320条里删除要那5个不确定的点# np.where里面的参数是条件,返回的是满足条件的索引delete_index, = np.where(unlabeled_indices == image_index)delete_indices = np.concatenate((delete_indices,delete_index))unlabeled_indices = np.delete(unlabeled_indices,delete_indices)# n_labeled_points是前面不确定的点有多少个被标注了n_labeled_points += len(uncertainty_index)f.suptitle("Active learning with label propagation.\nRows show 5 most""uncertain labels to learn with the next model") plt.subplots_adjust(0.12,0.03,0.9,0.8,0.2,0.45) plt.show()
参考:
https://www.jianshu.com/p/a21817a81890
