概述

tessera是quorum的一种隐私管理器实现，使用Java语言编写，用于对quorum隐私交易的加密、解密和分发。
原理参考:Quorum工作原理

1. 项目结构

tessera
├── argon2 hash函数库,类似的函数还有pbkdf2、bcrypt、 scrypt
├── cli 使用picocli实现的命令行tessera（包含子命令keygen|keyupdate|admin）
├── config 配置数据模型,给各个模块使用的配置
├── config-migration 提供命令行可以将Constellation TOML转换成Tessera JSON
├── data-migration 创建表结构
├── ddls ddl语句,包含两张表(支持mysq、oracle、postgresql、h2、hsql、sqllite)
├── enclave 提供加密、解密接口/Restful api(调用encryption模块)
├── encryption 生成主密钥、共享密钥、加密解密payload、生成随机数等.实现有ec、jnacl、kalium三种
├── key-generation 公钥私钥生成,包含aws、azure、hashcorp三种实现
├── key-vault 密钥保险箱 ,有aws、azure、hashcorp三种实现,可将密钥保存在这些在线服务上
├── security ssl通信相关工具
├── server 包含两个TesseraServer的实现:1、使用Jersey和Jetty 实现的RestServer;2 WebSocketServer
├── service-locator 获取服务实例,默认使用spring 配置文件 tessera-spring.xml中的定义(不使用注解?)
├── shared 大杂烩,包含一些工具类:控制台密码读取、ReflectCallback、JaxbCallback等CallBack
├── tessera-context 上下文,见下面的RuntimeContext
├── tessera-core 主要包含TransactionManager
├── tessera-data 主要包含EncryptedTransactionDAO、EncryptedRawTransactionDAO的实现
├── tessera-dist 系统launcher入口,包含tessera-spring.xml配置文件
├── tessera-jaxrs 系统RESTful API(OpenAPI)定义
├── tessera-partyinfo 参与者之间的服务发现、p2p连接、推送EncodedPayload到其他节点
├── tessera-sync peer节点之间Transaction的同步
├── test-utils 测试mock工具
└── tests 测试用例
参考下面的接口和类

2. 数据库结构

存储hash和加密playload对应关系

CREATE TABLE ENCRYPTED_TRANSACTION (
ENCODED_PAYLOAD BLOB NOT NULL,
HASH VARBINARY(100) NOT NULL,
TIMESTAMP BIGINT, PRIMARY KEY (HASH)
);CREATE TABLE ENCRYPTED_RAW_TRANSACTION (
ENCRYPTED_KEY BLOB NOT NULL,
ENCRYPTED_PAYLOAD BLOB NOT NULL,
NONCE BLOB NOT NULL,
SENDER BLOB NOT NULL,
TIMESTAMP BIGINT,
HASH VARBINARY(100) NOT NULL, PRIMARY KEY (HASH)
);

3. 主要流程

3.1 服务启动

a. 首先通过cli从配置文件tessera-config.json读取配置，根据配置创建运行时上下文（上下文持有当前节点公私钥对，peers列表等引用）
b. 再将当前partyInfo保存到集合中(内存)
c. 根据的serverConfigs循环创建ThirdPartyRestApp、P2PRestApp、Q2TRestApp(未包含EnclaveApplication)Restful服务
d 启动服务监听

顺序图：

主要代码：
main方法

 PicoCliDelegate picoCliDelegate = new PicoCliDelegate();LOGGER.debug("Execute PicoCliDelegate with args [{}]",String.join(",",args));final CliResult cliResult = picoCliDelegate.execute(args);LOGGER.debug("Executed PicoCliDelegate with args [{}].",String.join(",",args));CliDelegate.instance().setConfig(cliResult.getConfig().orElse(null));if (cliResult.isSuppressStartup()) {System.exit(0);}if (cliResult.getStatus() != 0) {System.exit(cliResult.getStatus());}final Config config =cliResult.getConfig().orElseThrow(() -> new NoSuchElementException("No config found. Tessera will not run."));RuntimeContext runtimeContext = RuntimeContextFactory.newFactory().create(config);LOGGER.debug("Creating service locator");ServiceLocator serviceLocator = ServiceLocator.create();LOGGER.debug("Created service locator {}",serviceLocator);Set<Object> services = serviceLocator.getServices();LOGGER.debug("Created {} services",services.size());services.forEach(o -> LOGGER.debug("Service : {}",o));services.stream().filter(PartyInfoService.class::isInstance).map(PartyInfoService.class::cast).findAny().ifPresent(p -> p.populateStore());runWebServer(config);

runWebServer

final List<TesseraServer> servers =config.getServerConfigs().stream().filter(server -> !AppType.ENCLAVE.equals(server.getApp())).map(conf -> {Object app =TesseraAppFactory.create(conf.getCommunicationType(), conf.getApp()).orElseThrow(() ->new IllegalStateException("Cant create app for " + conf.getApp()));return TesseraServerFactory.create(conf.getCommunicationType()).createServer(conf, Collections.singleton(app));}).filter(Objects::nonNull).collect(Collectors.toList());for (TesseraServer ts : servers) {ts.start();
}

3.2 交易处理

a.收到交易请求后，将请求交给TransactionManager处理，TransactionManager调用Enclave加密tx(详见下一个流程【加密交易】)，根据加密的payload，调用MessageHashFactory生成tx Hash，
b. 调用DAO将数据保存到数据库
c. 循环接收者列表，将加密了的playload推送给其他Tessera节点处理
d.将tx hash使用base64编码后返回给quorum几点

主要代码：

public SendResponse send(SendRequest sendRequest) {final String sender = sendRequest.getFrom();final PublicKey senderPublicKey =Optional.ofNullable(sender).map(base64Decoder::decode).map(PublicKey::from).orElseGet(enclave::defaultPublicKey);final byte[][] recipients =Stream.of(sendRequest).filter(sr -> Objects.nonNull(sr.getTo())).flatMap(s -> Stream.of(s.getTo())).map(base64Decoder::decode).toArray(byte[][]::new);final List<PublicKey> recipientList = Stream.of(recipients).map(PublicKey::from).collect(Collectors.toList());recipientList.add(senderPublicKey);recipientList.addAll(enclave.getForwardingKeys());final List<PublicKey> recipientListNoDuplicate =recipientList.stream().distinct().collect(Collectors.toList());final byte[] raw = sendRequest.getPayload();final EncodedPayload payload = enclave.encryptPayload(raw, senderPublicKey, recipientListNoDuplicate);final MessageHash transactionHash =Optional.of(payload).map(EncodedPayload::getCipherText).map(messageHashFactory::createFromCipherText).get();final EncryptedTransaction newTransaction =new EncryptedTransaction(transactionHash, this.payloadEncoder.encode(payload));this.encryptedTransactionDAO.save(newTransaction);recipientListNoDuplicate.forEach(recipient -> {final EncodedPayload outgoing = payloadEncoder.forRecipient(payload, recipient);partyInfoService.publishPayload(outgoing, recipient);});final byte[] key = transactionHash.getHashBytes();final String encodedKey = base64Decoder.encodeToString(key);return new SendResponse(encodedKey);}

3.3 加密交易

a. 生成随机主密钥（RMK：NonceMasterKey）和随机数Nonce、接收者随机数Nonce
b.使用步骤a的随机数Nonce和RMK加密message(Transaction Payload)。
c. 根据发送者的公钥从keymanager中获取发送者私钥
d.遍历接收者列表：根据发送者的私钥和接收者的公钥生成共享秘钥，根据共享密钥和接收者随机数加密RMK，最后返回RMK列表
e.返回加密的playload、随机数、RMKs给Transaction Manager

注：图中使用的Encryptor实现是EllipticalCurveEncryptor

主要代码：

 public EncodedPayload encryptPayload(final RawTransaction rawTransaction, final List<PublicKey> recipientPublicKeys) {final MasterKey masterKey =this.getMasterKey(rawTransaction.getFrom(), rawTransaction.getFrom(),rawTransaction.getNonce(), rawTransaction.getEncryptedKey());final Nonce recipientNonce = encryptor.randomNonce();final List<byte[]> encryptedMasterKeys =buildRecipientMasterKeys(rawTransaction.getFrom(), recipientPublicKeys, recipientNonce, masterKey);return EncodedPayload.Builder.create().withSenderKey(rawTransaction.getFrom()).withCipherText(rawTransaction.getEncryptedPayload()).withCipherTextNonce(rawTransaction.getNonce()).withRecipientBoxes(encryptedMasterKeys).withRecipientNonce(recipientNonce).withRecipientKeys(recipientPublicKeys).build();}private List<byte[]> buildRecipientMasterKeys(final PublicKey senderPublicKey,final List<PublicKey> recipientPublicKeys,final Nonce recipientNonce,final MasterKey masterKey) {final PrivateKey privateKey = keyManager.getPrivateKeyForPublicKey(senderPublicKey);return recipientPublicKeys.stream().map(publicKey -> encryptor.computeSharedKey(publicKey, privateKey)).map(sharedKey -> encryptor.sealAfterPrecomputation(masterKey.getKeyBytes(), recipientNonce, sharedKey)).collect(Collectors.toList());}

4. Restful API

4.1 Q2TRestApp

quorum节点和tessera之间的数据交换

api	method	功能
send	post	Send private transaction payload
sendRaw	post	Send private transaction payload
sendsignedtx	post	Send private raw transaction payload
receive	get	Submit keys to retrieve payload and decrypt it
receiveRaw	get	Submit keys to retrieve payload and decrypt it
transaction/{hash}	get	Returns decrypted payload back to Quorum
transaction/{key}	delete	Delete single transaction from P2PRestApp node
upcheck	get	Node is up?
version	get	Node’s version
storeraw	post	Store raw private transaction payload

4.2 ThirdPartyRestApp

api	method	功能
key	get	Fetch local public keys managed by the enclave
partyinfo/key	get	Fetch network/peer public keys
storeraw	post	Store raw private transaction payload

4.3 P2PRestApp

tessera节点之间的数据交换

api	method	功能
resend	post	Resend transactions for given key or message hash/recipient
push	post	Transmit encrypted payload between P2PRestApp Nodes
partyinfo	post	Request public key/url of other nodes
partyinfo	get	Fetch network/peer information
partyinfo/validate	post	validate network/peer

4.4 EnclaveApplication

提供main方法,可以独立启动成web服务提供Restful API,也可以走内部调用(默认)

api	method	功能
ping	get	获取Encalve服务状态
default	get	获取默认的公钥(第一个)
forwarding	get	获取要转发的公钥列表
public	get	获取公钥
encrypt	post	加密playload
encrypt/raw	post	加密rawplayload
encrypt/toraw	post	playload转换成rawplayload
unencrypt	post	解密Payload
addRecipient	post	添加收件人

5. 一些核心接口

App、Enclave相关的类图：

某些接口手工加了成员变量

com.quorum.tessera.server.TesseraServer

public interface TesseraServer {void start() throws Exception;void stop() throws Exception;
}

com.quorum.tessera.key.generation.KeyGenerator

public interface KeyGenerator {ConfigKeyPair generate(String filename, ArgonOptions encryptionOptions, KeyVaultOptions keyVaultOptions);
}

com.quorum.tessera.encryption.Encryptor

/*** The API provided to the application that all implementation of this API* module should extend* <p>* Provides all function relating to encrypting and decrypting messages* using public/private and symmetric keys.*/
public interface Encryptor {/*** Compute the shared key from a public/private key combination* The keys must be from different keysets.* Providing the public key for the corresponding private key (and vice versa) results in an error* <p>* The shared key for a public/private key combo is the same as if the private/public corresponding keys* were provided.* i.e. public1/private2 == private1/public2** @param publicKey  A public key from the first keyset* @param privateKey A private key from the second keyset* @return The shared key for this key pair.*/SharedKey computeSharedKey(PublicKey publicKey, PrivateKey privateKey);/*** Encrypt a payload directly using the given public/private key pair for the sender/recipient** @param message    The payload to be encrypted* @param nonce      A unique nonce for this public/private pair* @param publicKey  The key from either sender or recipient* @param privateKey The other key from either sender or recipient* @return The encrypted payload*/byte[] seal(byte[] message, Nonce nonce, PublicKey publicKey, PrivateKey privateKey);/*** Decrypt a payload directly using the given public/private key pair for the sender/recipient** @param cipherText The payload to be encrypted* @param nonce      A unique nonce for this public/private pair* @param publicKey  The key from either sender or recipient* @param privateKey The other key from either sender or recipient* @return The encrypted payload*/byte[] open(byte[] cipherText, Nonce nonce, PublicKey publicKey, PrivateKey privateKey);/*** Encrypt a payload using the given public/private key pair for the sender/recipient** @param message   The payload to be encrypted* @param nonce     A unique nonce for this public/private pair* @param sharedKey The shared key between the sender and recipient of the payload* @return The encrypted payload*/byte[] sealAfterPrecomputation(byte[] message, Nonce nonce, SharedKey sharedKey);default byte[] sealAfterPrecomputation(byte[] message, Nonce nonce, MasterKey masterKey) {SharedKey sharedKey = SharedKey.from(masterKey.getKeyBytes());return sealAfterPrecomputation(message, nonce, sharedKey);}/*** Decrypts a payload using the shared key between the sender and recipient** @param cipherText The encrypted payload* @param nonce      The nonce that was used to encrypt this payload* @param sharedKey  The shared key for the sender and recipient* @return The decrypted payload*/byte[] openAfterPrecomputation(byte[] cipherText, Nonce nonce, SharedKey sharedKey);/*** Generates a new random nonce of the correct size** @return a {@link Nonce} containing random data to be used as a nonce*/Nonce randomNonce();/*** Generates a new public and private keypair** @return A pair of public and private keys*/KeyPair generateNewKeys();/*** Creates a single standalone key** @return The randomly generated key*/SharedKey createSingleKey();/*** Create a randomly generated {@link MasterKey}** @return a random {@link MasterKey}*/default MasterKey createMasterKey() {SharedKey sharedKey = createSingleKey();return MasterKey.from(sharedKey.getKeyBytes());}/*** Decrypts a payload using the given {@link MasterKey}** @param cipherText      the ciphertext to decrypt* @param cipherTextNonce the nonce that was used to encrypt the payload* @param masterKey       the key used to encrypt the payload* @return the decrypted payload* @see Encryptor#openAfterPrecomputation(byte[], Nonce, SharedKey)*/default byte[] openAfterPrecomputation(byte[] cipherText, Nonce cipherTextNonce, MasterKey masterKey) {SharedKey sharedKey = SharedKey.from(masterKey.getKeyBytes());return openAfterPrecomputation(cipherText, cipherTextNonce, sharedKey);}}

com.quorum.tessera.enclave.Enclave

/*** An {@link Enclave} provides encryption/decryption functions and keeps hold* of all the nodes private keys so the do not leak into other services.*/
public interface Enclave extends Service {private final Encryptor encryptor;private final KeyManager keyManager;/*** Retrieves the public key to use if no key is specified for an operation* There is no guarantee this key remains the same between runs of the Enclave.** @return the public key that has been assigned as the default*/PublicKey defaultPublicKey();/*** Returns a set of public keys that should be included as recipients to* all transactions produced by this node. The keys are not be managed by* this node.** @return the set of public keys to be added to transactions*/Set<PublicKey> getForwardingKeys();/*** Returns all the public keys that are managed by this Enclave.** @return all public keys managed by this Enclave*/Set<PublicKey> getPublicKeys();/*** Encrypts a message using the specified sender and a list of recipients.* Returns a {@link EncodedPayload} which contains all the encrypted* information, including the recipients and their encrypted master keys.** @param message             the message to be encrypted* @param senderPublicKey     the public key which this enclave manages* @param recipientPublicKeys the recipients to encrypt this message for* @return the encrypted information, represented by an {@link EncodedPayload}*/EncodedPayload encryptPayload(byte[] message, PublicKey senderPublicKey, List<PublicKey> recipientPublicKeys);/*** Decrypts a {@link RawTransaction} so that it can be re-encrypted into a* {@link EncodedPayload} with the given recipient list** @param rawTransaction      the transactiopn to decrypt and re-encrypt with recipients* @param recipientPublicKeys the recipients to encrypt the transaction for* @return the encrypted information, represented by an {@link EncodedPayload}*/EncodedPayload encryptPayload(RawTransaction rawTransaction, List<PublicKey> recipientPublicKeys);/*** Encrypt a payload without any recipients that can be retrieved later.* The payload is encrypted using the private key that is related to the* given public key.** @param message the message to be encrypted* @param sender  the sender's public key to encrypt the transaction with* @return the encrypted transaction*/RawTransaction encryptRawPayload(byte[] message, PublicKey sender);/*** Decrypt a transaction and fetch the original message using the given* public key. Throws an {@link com.quorum.tessera.nacl.NaclException} if* the provided public key OR one of the Enclave's managed keys cannot be* used to decrypt the payload** @param payload     the encrypted payload* @param providedKey the key to use for decryption, if the payload wasn't sent by this Enclave* @return the original, decrypted message*/byte[] unencryptTransaction(EncodedPayload payload, PublicKey providedKey);/*** Creates a new recipient box for the payload, for which we must be the originator.* At least one recipient must already be available to be able to decrypt the master key.** @param payload      the payload to add a recipient to* @param recipientKey the new recipient key to add*/byte[] createNewRecipientBox(EncodedPayload payload, PublicKey recipientKey);@Overridedefault void start() {}@Overridedefault void stop() {}
}

com.quorum.tessera.context.RuntimeContext

public interface RuntimeContext {List<KeyPair> getKeys();KeyEncryptor getKeyEncryptor();List<PublicKey> getAlwaysSendTo();List<URI> getPeers();Client getP2pClient();boolean isRemoteKeyValidation();URI getP2pServerUri();static RuntimeContext getInstance() {return ContextHolder.INSTANCE.getContext().get();}boolean isDisablePeerDiscovery();default Set<PublicKey> getPublicKeys() {return getKeys().stream().map(KeyPair::getPublicKey).collect(Collectors.toSet());}boolean isUseWhiteList();
}

com.quorum.tessera.partyinfo.PartyInfoService

public interface PartyInfoService {/*** Request PartyInfo data from all remote nodes that this node is aware of** @return PartyInfo object*/PartyInfo getPartyInfo();/*** Update the PartyInfo data store with the provided encoded data.This can happen when endpoint /partyinfo is* triggered, or by a response from this node hitting another node /partyinfo endpoint** @param partyInfo* @return updated PartyInfo object*/PartyInfo updatePartyInfo(PartyInfo partyInfo);// Set<String> getUrlsForKey(PublicKey key);PartyInfo removeRecipient(String uri);/*** Formats, encodes and publishes encrypted messages using the target public key as the identifier, instead of the* URL** @param payload the pre-formatted payload object (i.e. with all recipients still present)* @param recipientKey the target public key to publish the payload to* @throws com.quorum.tessera.encryption.KeyNotFoundException if the target public key is not known*/void publishPayload(EncodedPayload payload, PublicKey recipientKey);// TODO: Added as lifecycle call once RuntimeContext has been created.void populateStore();
}

com.quorum.tessera.transaction.TransactionManager

	public interface TransactionManager {private final PayloadEncoder payloadEncoder;private final Base64Decoder base64Decoder;private final EncryptedTransactionDAO encryptedTransactionDAO;private final EncryptedRawTransactionDAO encryptedRawTransactionDAO;private final PartyInfoService partyInfoService;private final Enclave enclave;private final ResendManager resendManager;private final MessageHashFactory messageHashFactory = MessageHashFactory.create();private int resendFetchSize;SendResponse send(SendRequest sendRequest);SendResponse sendSignedTransaction(SendSignedRequest sendRequest);void delete(DeleteRequest request);ResendResponse resend(ResendRequest request);MessageHash storePayload(byte[] toByteArray);ReceiveResponse receive(ReceiveRequest request);StoreRawResponse store(StoreRawRequest storeRequest);
}

com.quorum.tessera.config.AppType

public enum AppType {P2P(CommunicationType.REST),Q2T(CommunicationType.REST),THIRD_PARTY(CommunicationType.REST),ENCLAVE(CommunicationType.REST),ADMIN(CommunicationType.REST);
}

6. 主要配置文件

tessera-config.json 示例

 {"useWhiteList": false,"jdbc": {"username": "sa","password": "","url": "jdbc:h2:test/db;MODE=Oracle;TRACE_LEVEL_SYSTEM_OUT=0","autoCreateTables": true},"serverConfigs":[{"app":"ThirdParty","enabled": true,"serverAddress": "http://$$(hostname -i):9080","communicationType" : "REST"},{"app":"Q2T","enabled": true,"serverAddress": "unix:$${DDIR}/tm.ipc","communicationType" : "REST"},{"app":"P2P","enabled": true,"serverAddress": "http://$$(hostname -i):9000","sslConfig": {"tls": "OFF"},"communicationType" : "REST"}],"peer": [{"url": "http://txmanager1:9000"},{"url": "http://txmanager2:9000"},{"url": "http://txmanager3:9000"},{"url": "http://txmanager4:9000"},{"url": "http://txmanager5:9000"},{"url": "http://txmanager6:9000"},{"url": "http://txmanager7:9000"}],"keys": {"passwords": [],"keyData": [{"config": "tm.key","publicKey": "tm.pub"}]},"alwaysSendTo": []}

tessera-dist/tessera-app/src/main/resources/tessera-spring.xml

<?xml version="1.0" encoding="UTF-8"?>
<beans xmlns="http://www.springframework.org/schema/beans"xmlns:xsi="http://www.w3.org/2001/XMLSchema-instance"xsi:schemaLocation="http://www.springframework.org/schema/beans http://www.springframework.org/schema/beans/spring-beans.xsd"><import resource="classpath:/tessera-core-spring.xml" /><import resource="classpath:/tessera-partyinfo-spring.xml" /></beans>

tessera-core/src/main/resources/tessera-core-spring.xml

<?xml version="1.0" encoding="UTF-8"?>
<beans xmlns="http://www.springframework.org/schema/beans"xmlns:xsi="http://www.w3.org/2001/XMLSchema-instance"xmlns:tx="http://www.springframework.org/schema/tx"xmlns:context="http://www.springframework.org/schema/context"xsi:schemaLocation="http://www.springframework.org/schema/beans http://www.springframework.org/schema/beans/spring-beans.xsdhttp://www.springframework.org/schema/tx http://www.springframework.org/schema/tx/spring-tx.xsdhttp://www.springframework.org/schema/context http://www.springframework.org/schema/context/spring-context.xsd"><tx:annotation-driven transaction-manager="jpaTransactionManager"/><context:component-scan base-package="com.quorum.tessera"/><bean id="enclaveFactory" class="com.quorum.tessera.enclave.EnclaveFactory" factory-method="create" /><bean id="enclave" factory-bean="enclaveFactory" factory-method="create"><constructor-arg ref="config" /></bean><bean class="com.quorum.tessera.service.ServiceContainer"><constructor-arg ref="enclave" /></bean><bean id="transactionManager" class="com.quorum.tessera.transaction.TransactionManagerImpl"><constructor-arg ref="encryptedTransactionDAO" /><constructor-arg ref="enclave" /><constructor-arg ref="encryptedRawTransactionDAO" /><constructor-arg ref="resendManager" /><constructor-arg ref="partyInfoService" /><constructor-arg value="#{config.getJdbcConfig().getFetchSize() > 0 ? config.getJdbcConfig().getFetchSize() : 1000}"/></bean><bean id="cliDelegate" class="com.quorum.tessera.cli.CliDelegate" factory-method="instance"/><bean id="config" factory-bean="cliDelegate" factory-method="getConfig"/><bean name="encryptedTransactionDAO" class="com.quorum.tessera.data.EncryptedTransactionDAOImpl"/><bean name="encryptedRawTransactionDAO" class="com.quorum.tessera.data.EncryptedRawTransactionDAOImpl"/><bean id="dataSource" class="com.zaxxer.hikari.HikariDataSource"><property name="jdbcUrl" value="#{ config.getJdbcConfig().getUrl() }" /><property name="username" value="#{ config.getJdbcConfig().getUsername() }" /><property name="password" value="#{ resolver.resolve(config.getJdbcConfig().getPassword()) }" /></bean><bean id="jpaTransactionManager" class="org.springframework.orm.jpa.JpaTransactionManager"><property name="entityManagerFactory" ref="entityManagerFactory"/></bean><bean id="entityManagerFactory" class="org.springframework.orm.jpa.LocalContainerEntityManagerFactoryBean"><property name="dataSource" ref="dataSource"/><property name="persistenceUnitName" value="tessera"/><property name="jpaVendorAdapter"><bean class="org.springframework.orm.jpa.vendor.EclipseLinkJpaVendorAdapter" /></property><property name="jpaDialect"><bean class="org.springframework.orm.jpa.vendor.EclipseLinkJpaDialect"/></property><property name="jpaPropertyMap"><props><prop key="eclipselink.weaving">false</prop><prop key="eclipselink.session-name">tessera</prop><prop key="eclipselink.logging.logger">org.eclipse.persistence.logging.slf4j.SLF4JLogger</prop><prop key="eclipselink.logging.session">false</prop><prop key="javax.persistence.schema-generation.database.action">#{config.getJdbcConfig().isAutoCreateTables() ? 'create' : 'none'}</prop></props></property></bean><bean id="resolver" class="com.quorum.tessera.config.util.EncryptedStringResolver"/>
</beans>

tessera-partyinfo/src/main/resources/tessera-partyinfo-spring.xml

<?xml version="1.0" encoding="UTF-8"?>
<beans xmlns="http://www.springframework.org/schema/beans"xmlns:xsi="http://www.w3.org/2001/XMLSchema-instance"xsi:schemaLocation="http://www.springframework.org/schema/beans http://www.springframework.org/schema/beans/spring-beans.xsd"><bean id="p2pClientFactory" class="com.quorum.tessera.partyinfo.P2pClientFactory" factory-method="newFactory"><constructor-arg ref="config" /></bean><bean id="p2pClient" factory-bean="p2pClientFactory" factory-method="create"><constructor-arg ref="config"/></bean><bean id="resendClientFactory" class="com.quorum.tessera.sync.ResendClientFactory" factory-method="newFactory"><constructor-arg ref="config"/></bean><bean id="resendClient" factory-bean="resendClientFactory" factory-method="create"><constructor-arg ref="config"/></bean><bean id="payloadPublisherFactory" class="com.quorum.tessera.partyinfo.PayloadPublisherFactory" factory-method="newFactory"><constructor-arg ref="config" /></bean><bean id="payloadPublisher" class="com.quorum.tessera.partyinfo.PayloadPublisher" factory-bean="payloadPublisherFactory" factory-method="create"><constructor-arg ref="config" /></bean><!-- Party Info management --><bean name="partyInfoStore" class="com.quorum.tessera.partyinfo.PartyInfoStore"><constructor-arg value="#{config.getP2PServerConfig().getServerUri()}"/></bean><bean name="partyInfoService" class="com.quorum.tessera.partyinfo.PartyInfoServiceImpl"><constructor-arg ref="partyInfoStore"/><constructor-arg ref="enclave"/><constructor-arg ref="payloadPublisher"/></bean><bean name="partyInfoPoller" class="com.quorum.tessera.partyinfo.PartyInfoPoller"><constructor-arg ref="partyInfoService"/><constructor-arg ref="p2pClient"/></bean><bean name="propertyHelper" class="com.quorum.tessera.config.util.IntervalPropertyHelper"><constructor-arg value="#{config.getP2PServerConfig().getProperties()}"/></bean><bean name="partyInfoPollExecutor" class="com.quorum.tessera.threading.TesseraScheduledExecutor"><constructor-arg><bean class="java.util.concurrent.Executors" factory-method="newSingleThreadScheduledExecutor"/></constructor-arg><constructor-arg ref="partyInfoPoller"/><constructor-arg value="#{propertyHelper.partyInfoInterval()}"/><constructor-arg value="5000"/></bean><bean id="resendManager" class="com.quorum.tessera.partyinfo.ResendManagerImpl"><constructor-arg ref="encryptedTransactionDAO" /><constructor-arg ref="enclave" /></bean><!-- Local key sync --><bean name="enclaveKeySynchroniser" class="com.quorum.tessera.partyinfo.EnclaveKeySynchroniser"><constructor-arg ref="enclave" /><constructor-arg ref="partyInfoStore" /><constructor-arg value="#{config.getP2PServerConfig().getServerUri()}" /></bean><bean name="enclaveKeySynchroniserExecutor" class="com.quorum.tessera.threading.TesseraScheduledExecutor"><constructor-arg><bean class="java.util.concurrent.Executors" factory-method="newSingleThreadScheduledExecutor"/></constructor-arg><constructor-arg ref="enclaveKeySynchroniser"/><constructor-arg value="#{propertyHelper.enclaveKeySyncInterval()}"/><constructor-arg value="5000"/></bean><!-- Node synchronization management--><beans profile="enable-sync-poller"><bean name="resendPartyStore" class="com.quorum.tessera.sync.ResendPartyStoreImpl"/><bean name="transactionRequester" class="com.quorum.tessera.sync.TransactionRequesterImpl"><constructor-arg ref="enclave" /><constructor-arg ref="resendClient" /></bean><bean name="syncPoller" class="com.quorum.tessera.sync.SyncPoller"><constructor-arg ref="resendPartyStore" /><constructor-arg ref="transactionRequester" /><constructor-arg ref="partyInfoService"/><constructor-arg ref="p2pClient"/></bean><bean class="com.quorum.tessera.threading.TesseraScheduledExecutor"><constructor-arg><bean class="java.util.concurrent.Executors" factory-method="newSingleThreadScheduledExecutor"/></constructor-arg><constructor-arg ref="syncPoller"/><constructor-arg value="#{propertyHelper.syncInterval()}"/><constructor-arg value="5000"/></bean></beans></beans>
