场景：在进行压力测试时，需要判断图片的某一块区域是否是黑色

这里使用的是OpenCV库对图片进行颜色的识别，几乎可以识别所有常见的颜色

直接上代码

import cv2
import numpy as np
import collectionsclass colorList:def getColorList(self):dict = collections.defaultdict(list)# 黑色lower_black = np.array([0, 0, 0])upper_black = np.array([180, 255, 46])color_list = []color_list.append(lower_black)color_list.append(upper_black)dict['黑色'] = color_list# 灰色lower_gray = np.array([0, 0, 46])upper_gray = np.array([180, 43, 220])color_list = []color_list.append(lower_gray)color_list.append(upper_gray)dict['灰色'] = color_list# 白色lower_white = np.array([0, 0, 221])upper_white = np.array([180, 30, 255])color_list = []color_list.append(lower_white)color_list.append(upper_white)dict['白色'] = color_list# 红色lower_red = np.array([156, 43, 46])upper_red = np.array([180, 255, 255])color_list = []color_list.append(lower_red)color_list.append(upper_red)dict['红色'] = color_list# 红色2lower_red = np.array([0, 43, 46])upper_red = np.array([10, 255, 255])color_list = []color_list.append(lower_red)color_list.append(upper_red)dict['红色2'] = color_list# 橙色lower_orange = np.array([11, 43, 46])upper_orange = np.array([25, 255, 255])color_list = []color_list.append(lower_orange)color_list.append(upper_orange)dict['橙色'] = color_list# 黄色lower_yellow = np.array([26, 43, 46])upper_yellow = np.array([34, 255, 255])color_list = []color_list.append(lower_yellow)color_list.append(upper_yellow)dict['黄色'] = color_list# 绿色lower_green = np.array([35, 43, 46])upper_green = np.array([77, 255, 255])color_list = []color_list.append(lower_green)color_list.append(upper_green)dict['绿色'] = color_list# 青色lower_cyan = np.array([78, 43, 46])upper_cyan = np.array([99, 255, 255])color_list = []color_list.append(lower_cyan)color_list.append(upper_cyan)dict['青色'] = color_list# 蓝色lower_blue = np.array([100, 43, 46])upper_blue = np.array([124, 255, 255])color_list = []color_list.append(lower_blue)color_list.append(upper_blue)dict['蓝色'] = color_list# 紫色lower_purple = np.array([125, 43, 46])upper_purple = np.array([155, 255, 255])color_list = []color_list.append(lower_purple)color_list.append(upper_purple)dict['紫色'] = color_listreturn dict# 处理图片def get_color(self):print('颜色对比')img = cv2.imread('D:\sdcard\XiaLa.png')hsv = cv2.cvtColor(img, cv2.COLOR_BGR2HSV)maxsum = -100color = Nonecolor_dict = colorList().getColorList()for d in color_dict:mask = cv2.inRange(hsv, color_dict[d][0], color_dict[d][1])binary = cv2.threshold(mask, 127, 255, cv2.THRESH_BINARY)[1]binary = cv2.dilate(binary, None, iterations=2)img, cnts = cv2.findContours(binary.copy(), cv2.RETR_EXTERNAL, cv2.CHAIN_APPROX_SIMPLE)sum = 0for c in img:sum += cv2.contourArea(c)if sum > maxsum:maxsum = sumcolor = dreturn colorif __name__ == '__main__':print(colorList().get_color())

运行结果如下：



颜色可以判断出来了，可以做的事情就方便很多了

比如在尽行压力测试时，去判断截图区域是否是黑色，是黑色就停止运行，不是则继续。

OK！方便易懂，代码可直接用
