CROSSWALK入门

Crosswalk是一款开源的web引擎。目前Crosswalk正式支持的移动操作系统包括Android和Tizen，在Android 4.0及以上的系统中使用Crosswalk的Web应用程序在HTML5方面可以有一致的体验，同时和系统的整合交互方面（比如启动画面、权限管理、应用切换、社交分享等等）可以做到类似原生应用。现在Crosswalk已经成为众多知名HTML5平台和应用的推荐引擎，包括Google Mobile Chrome App、Intel XDK、Famo.us和Construct2等等，未来的Cordova 4.0也计划集成Crosswalk。

Crosswalk官方地址

下载的时候有些小迷茫，不知道应该下载哪个，入门的话，还是使用下图的稳定版本好了。
CrossViewDownload

集成到应用中

1.下载zip包，然后参考 Android Studio如何Import Module 即项目依赖（针对非Gradle项目，以Crosswalk为例）中的介绍，建立Android Studio工程，并且导入到项目中。

2.在AndroidManifest.xml中增加如下权限


 1
2
3
4
5
6
7
8
9
 <uses-permission android : name = "android.permission.ACCESS_FINE_LOCATION"  />
 <uses-permission android : name = "android.permission.ACCESS_NETWORK_STATE"  />
 <uses-permission android : name = "android.permission.ACCESS_WIFI_STATE"  />
 <uses-permission android : name = "android.permission.CAMERA"  />
 <uses-permission android : name = "android.permission.INTERNET"  />
 <uses-permission android : name = "android.permission.MODIFY_AUDIO_SETTINGS"  />
 <uses-permission android : name = "android.permission.RECORD_AUDIO"  />
 <uses-permission android : name = "android.permission.WAKE_LOCK"  />
 <uses-permission android : name = "android.permission.WRITE_EXTERNAL_STORAGE"  />


使用XWalkView必须开启硬件加速，修改AndroidManifest.xml


 1
2
3
4
 <application
android : name = "android.app.Application"
android : label = "XWalkUsers"
android : hardwareAccelerated = "true" >


基本使用

Crosswalk中用来替代WebView的控件叫XWalkView

1.layout文件写法


 1
2
3
4
5
6
 <org.xwalk.core.XWalkView
  android : id = "@+id/activity_main"
xmlns : android = "http://schemas.android.com/apk/res/android"
android : layout_width = "fill_parent"
android : layout_height = "fill_parent" >
 </org.xwalk.core.XWalkView>


2.代码中使用
和其他Android的控件不同，这个类需要监听系统事件。例如：生命周期、intent、Activity result。
控件内置的Web引擎需要获取并处理这些信息。并且当XWalkView 不再需要使用的时候，在onDestroy方法中XWalkView必须显式的调用destroy方法，否则容易造成Web引擎的内存泄漏。

点击展开代码

3.loadUrl去哪了？

上面的代码中其实已经剧透了，使用load方法即可。


 1
2
3
4
5
 // url
 mXWalkView . load ( "http://crosswalk-project.org/" ,   null ) ;
 // this loads a file from the assets/ directory
 mXWalkView . load ( "file:///android_asset/index.html" ,   null ) ;


4.WebViewClient？

对应WebView的WebViewClient，XWalkView中有XWalkResourceClient。


 1
2
3
4
5
6
7
8
9
10
 mXWalkView . setResourceClient ( new   XWalkResourceClient ( mXWalkView ) {
   @Override
   public   void   onLoadFinished ( XWalkView  view ,   String   url )   {
   super . onLoadFinished ( view ,   url ) ;
   }
   @Override
   public   void   onLoadStarted ( XWalkView  view ,   String   url )   {
   super . onLoadStarted ( view ,   url ) ;
   }
 } ) ;


调用JavaScript

不像WebView一样获取setting设置setJavaScriptEnabled为true才能执行。
Crosswalk可以直接执行js。


 1
 mXWalkView . load ( "javascript:document.body.contentEditable=true;" ,   null ) ;

当然，按照Kitkat引入的方式，使用evaluateJavascript方法也是可以的。（大神们推荐）

JavaScript回调Java

定义js回调接口


 1
2
3
4
5
6
7
8
 public   class   JsInterface   {
      public   JsInterface ( )   {
      }
      @ JavascriptInterface
      public   String   sayHello ( )   {
          return   "Hello World!" ;
      }
 }


Caution: If you've set your targetSdkVersion to 17 or higher, you must add the @JavascriptInterface annotation to any method that you want available to your JavaScript (the method must also be public). If you do not provide the annotation, the method is not accessible by your web page when running on Android 4.2 or higher.
From developer.android.com

备注：这里的


 1
 @JavaScriptInterface

所在的包是


 1
 import   org . xwalk . core . JavascriptInterface ;

XWalkView设置JavaScript可用且绑定对象

1

2

/ /绑定

mXWalkView .addJavascriptInterface ( new JsInterface ( ) , "NativeInterface" ) ;
调用html执行JavaScript或直接执行Javascript调用Java

1

mXWalkView . load ( "file:///android_asset/index.html" , null ) ;

index.html源码：

1

2

3

4

5

<a href = "#" onclick = "clicked()" > Say Hello </a> <script>

function clicked ( ) {

alert ( NativeInterface . sayHello ( ) ) ;

}

</script>

高级使用

调试

Kitkat开始，Android提供了和Chrome联调功能。可以很方便的在Chrome中调试WebView中的代码。
Crosswalk使用Chromium内核当然也具备这个功能。
开启调试的语句如下：


 1
2
 // turn on debugging
 XWalkPreferences . setValue ( XWalkPreferences . REMOTE_DEBUGGING ,   true ) ;


对于Crosswalk来说，这个设置是全局的。

使用动画或者设置隐藏可见注意

默认XWalkView不能使用动画，甚至setVisibility也不行。

XWalkView represents an Android view for web apps/pages. Thus most of attributes for Android view are valid for this class. Since it internally uses android.view.SurfaceView for rendering web pages by default, it can't be resized, rotated, transformed and animated due to the limitations of SurfaceView. Alternatively, if the preference key ANIMATABLE_XWALK_VIEW is set to True, XWalkView can be transformed and animated because TextureView is intentionally used to render web pages for animation support. Besides, XWalkView won't be rendered if it's invisible.

开启动画模式：


 1
2
3
4
5
6
7
8
9
10
11
12
13
14
15
16
 @Override
 protected   void   onCreate ( Bundle  savedInstanceState )   {
      super . onCreate ( savedInstanceState ) ;
      // ANIMATABLE_XWALK_VIEW preference key MUST be set before XWalkView creation.
      XWalkPreferences . setValue ( XWalkPreferences . ANIMATABLE_XWALK_VIEW ,   true ) ;
      setContentView ( R . layout . animatable_xwview_layout ) ;
 }
 @Override
 public   void   onDestroy ( )   {
      super . onDestroy ( ) ;
      // Reset the preference for animatable XWalkView.
      XWalkPreferences . setValue ( XWalkPreferences . ANIMATABLE_XWALK_VIEW ,   false ) ;
 }


由于设置也像调试一样是全局的，在onDestroy时记得关闭。

暂停JS timer

html代码


 1
2
3
4
5
6
7
8
9
10
11
12
13
14
15
16
17
18
19
20
 <!DOCTYPE html>
 <html>
 <body>
 <p> A script on this page starts this clock: </p>
 <p  id = "demo" > </p>
 <script>
    var   myVar   =   setInterval ( function ( ) {   myTimer ( ) ;   } ,   1000 ) ;
    function   myTimer ( )
    {
      var   d   =   new   Date ( ) ;
      var   t   =   d . toLocaleTimeString ( ) ;
      document . getElementById ( "demo" ) . innerHTML   =   t ;
    }
 </script>
 </body>
 </html>


XWalkView对应方法：


 1
2
3
4
5
6
7
8
9
10
11
12
13
14
15
16
17
18
 mButton . setOnClickListener ( new   OnClickListener ( )   {
      @Override
      public   void   onClick ( View   v )   {
          if   ( mXWalkView   !=   null )   {
              if   ( ! isPaused )   {
                  // Pause JS timer
                  mXWalkView . pauseTimers ( ) ;
                  isPaused   =   true ;
                  mButton . setImageResource ( android . R . drawable . ic_media_play ) ;
              }   else   {
                  // Resume JS timer
                  mXWalkView . resumeTimers ( ) ;
                  isPaused   =   false ;
                  mButton . setImageResource ( android . R . drawable . ic_media_pause ) ;
              }
          }
      }
 } ) ;


这也在防止内存泄漏，监听系统事件示例代码中提到过：


 1
2
3
4
5
6
7
8
9
10
11
12
13
14
15
16
17
 @Override
 protected   void   onPause ( )   {
     super . onPause ( ) ;
     if   ( mXWalkView   !=   null )   {
         mXWalkView . pauseTimers ( ) ;
         mXWalkView . onHide ( ) ;
     }
 }
 @Override
 protected   void   onResume ( )   {
     super . onResume ( ) ;
     if   ( mXWalkView   !=   null )   {
         mXWalkView . resumeTimers ( ) ;
         mXWalkView . onShow ( ) ;
     }
 }


历史记录


 1
2
3
4
5
6
7
8
9
10
11
12
13
14
15
16
17
18
19
20
21
22
23
24
25
26
27
28
29
30
31
32
33
34
35
36
37
 mPrevButton . setOnClickListener ( new   OnClickListener ( )   {
      @Override
      public   void   onClick ( View   v )   {
          // Go backward
          if   ( mXWalkView   !=   null   &&
                  mXWalkView . getNavigationHistory ( ) . canGoBack ( ) )   {
              mXWalkView . getNavigationHistory ( ) . navigate (
                      XWalkNavigationHistory . Direction . BACKWARD ,   1 ) ;
          }
          XWalkNavigationItem  navigationItem   =   mXWalkView . getNavigationHistory ( ) . getCurrentItem ( ) ;
          showNavigationItemInfo ( navigationItem ) ;
      }
 } ) ;
 mNextButton . setOnClickListener ( new   OnClickListener ( )   {
      @Override
      public   void   onClick ( View   v )   {
          // Go forward
          if   ( mXWalkView   !=   null   &&
                  mXWalkView . getNavigationHistory ( ) . canGoForward ( ) )   {
              mXWalkView . getNavigationHistory ( ) . navigate (
                      XWalkNavigationHistory . Direction . FORWARD ,   1 ) ;
          }
          XWalkNavigationItem  navigationItem   =   mXWalkView . getNavigationHistory ( ) . getCurrentItem ( ) ;
          showNavigationItemInfo ( navigationItem ) ;
      }
 } ) ;
 private   void   showNavigationItemInfo ( XWalkNavigationItem  navigationItem ) {
      url   =   navigationItem . getUrl ( ) ; // Get the url of current navigation item.
      originalUrl   =   navigationItem . getOriginalUrl ( ) ; // Get the original url of current navigation item
      title   =   navigationItem . getTitle ( ) ;
      text1 . setText ( title ) ;
      text2 . setText ( url ) ;
      text3 . setText ( originalUrl ) ;
 }


自动视频暂停


 1
2
3
 // The web page below will display a video.
 // When home button is pressed, the activity will be in background, and the video will be paused.
 mXWalkView . load ( "http://www.w3.org/2010/05/video/mediaevents.html" ,   null ) ;


loadAppFromManifest


 1
 mXWalkView . loadAppFromManifest ( "file:///android_asset/manifest.json" ,   null ) ;

manifest.json


 1
2
3
4
5
6
 {
    "name" :   "ManifestTest" ,
    "start_url" :   "index.html" ,
    "description" :   "Manifest test" ,
    "version" :   "1.0.0"
 }
