rtmpdump 是一个用来处理 RTMP 流媒体的工具包，支持 rtmp://, rtmpt://, rtmpe://, rtmpte://, and rtmps:// 等。之前在学习RTMP协议的时候，发现没有讲它源代码的，只好自己分析，现在打算把自己学习的成果写出来，可能结果不一定都对，先暂且记录一下。
函数调用结构图
RTMPDump (libRTMP)的整体的函数调用结构图如下图所示。
单击查看大图
详细分析
使用RTMPdump下载一个流媒体的大致流程是这样的：
RTMP_Init();//初始化结构体
InitSockets();//初始化Socket
RTMP_ParseURL();//解析输入URL
RTMP_SetupStream();//一些设置
fopen();//打开文件，准备写入
RTMP_Connect();//建立NetConnection
RTMP_ConnectStream()//建立NetStream
Download();//下载函数
RTMP_Close();//关闭连接
fclose();//关闭文件
CleanupSockets();//清理Socket其中Download()主要是使用RTMP_Read()进行下载的。
注：可以参考：RTMP流媒体播放过程
下面贴上自己注释的RTMPDump源代码。注意以下几点：
1.此RTMPDump已经被移植进VC 2010 的 MFC的工程，所以main()函数已经被改名为rtmpdump()，而且参数也改了，传进来一个MFC窗口的句柄。不过功能没怎么改（控制台程序移植到MFC以后，main()就不是程序的入口了，所以main()名字改成什么是无所谓的）
2.里面有很多提取信息的代码形如：rtmp.dlg->AppendCInfo("开始初始化Socket...");这些代码是我为了获取RTMP信息而自己加的，并不影响程序的执行。
int rtmpdump(LPVOID lpParam,int argc,char **argv)
{extern char *optarg;//一定要设置，否则只能运行一次extern int optind;optind=0;int nStatus = RD_SUCCESS;double percent = 0;double duration = 0.0;int nSkipKeyFrames = DEF_SKIPFRM; // skip this number of keyframes when resumingint bOverrideBufferTime = FALSE; // if the user specifies a buffer time override this is trueint bStdoutMode = TRUE; // if true print the stream directly to stdout, messages go to stderrint bResume = FALSE; // true in resume modeuint32_t dSeek = 0; // seek position in resume mode, 0 otherwiseuint32_t bufferTime = DEF_BUFTIME;// meta header and initial frame for the resume mode (they are read from the file and compared with// the stream we are trying to continuechar *metaHeader = 0;uint32_t nMetaHeaderSize = 0;// video keyframe for matchingchar *initialFrame = 0;uint32_t nInitialFrameSize = 0;int initialFrameType = 0; // tye: audio or videoAVal hostname = { 0, 0 };AVal playpath = { 0, 0 };AVal subscribepath = { 0, 0 };int port = -1;int protocol = RTMP_PROTOCOL_UNDEFINED;int retries = 0;int bLiveStream = FALSE; // 是直播流吗? then we can't seek/resumeint bHashes = FALSE; // display byte counters not hashes by defaultlong int timeout = DEF_TIMEOUT; // timeout connection after 120 secondsuint32_t dStartOffset = 0; // 非直播流搜寻点seek position in non-live modeuint32_t dStopOffset = 0;RTMP rtmp = { 0 };AVal swfUrl = { 0, 0 };AVal tcUrl = { 0, 0 };AVal pageUrl = { 0, 0 };AVal app = { 0, 0 };AVal auth = { 0, 0 };AVal swfHash = { 0, 0 };uint32_t swfSize = 0;AVal flashVer = { 0, 0 };AVal sockshost = { 0, 0 };#ifdef CRYPTOint swfAge = 30; /* 30 days for SWF cache by default */int swfVfy = 0;unsigned char hash[RTMP_SWF_HASHLEN];
#endifchar *flvFile = 0;signal(SIGINT, sigIntHandler);signal(SIGTERM, sigIntHandler);
#ifndef WIN32signal(SIGHUP, sigIntHandler);signal(SIGPIPE, sigIntHandler);signal(SIGQUIT, sigIntHandler);
#endifRTMP_debuglevel = RTMP_LOGINFO;//首先搜寻“ --quiet”选项int index = 0;while (index < argc){if (strcmp(argv[index], "--quiet") == 0|| strcmp(argv[index], "-q") == 0)RTMP_debuglevel = RTMP_LOGCRIT;index++;}
#define RTMPDUMP_VERSION "1.0"RTMP_LogPrintf("RTMP流媒体下载 %s\n", RTMPDUMP_VERSION);RTMP_LogPrintf("2012 雷霄骅 中国传媒大学/信息工程学院/通信与信息系统/数字电视技术\n");//RTMP_LogPrintf("输入 -h 获取命令选项\n");RTMP_Init(&rtmp);//句柄-----------------------------rtmp.dlg=(CSpecialPRTMPDlg *)lpParam;//---------------------------------//----------------------rtmp.dlg->AppendCInfo("开始初始化Socket...");//-----------------------------if (!InitSockets()){//----------------------rtmp.dlg->AppendCInfo("初始化Socket失败！");//-----------------------------RTMP_Log(RTMP_LOGERROR,"Couldn't load sockets support on your platform, exiting!");return RD_FAILED;}//----------------------rtmp.dlg->AppendCInfo("成功初始化Socket");//-----------------------------/* sleep(30); */int opt;
/* struct option longopts[] = {{"help", 0, NULL, 'h'},{"host", 1, NULL, 'n'},{"port", 1, NULL, 'c'},{"socks", 1, NULL, 'S'},{"protocol", 1, NULL, 'l'},{"playpath", 1, NULL, 'y'},{"playlist", 0, NULL, 'Y'},{"rtmp", 1, NULL, 'r'},{"swfUrl", 1, NULL, 's'},{"tcUrl", 1, NULL, 't'},{"pageUrl", 1, NULL, 'p'},{"app", 1, NULL, 'a'},{"auth", 1, NULL, 'u'},{"conn", 1, NULL, 'C'},
#ifdef CRYPTO{"swfhash", 1, NULL, 'w'},{"swfsize", 1, NULL, 'x'},{"swfVfy", 1, NULL, 'W'},{"swfAge", 1, NULL, 'X'},
#endif{"flashVer", 1, NULL, 'f'},{"live", 0, NULL, 'v'},{"flv", 1, NULL, 'o'},{"resume", 0, NULL, 'e'},{"timeout", 1, NULL, 'm'},{"buffer", 1, NULL, 'b'},{"skip", 1, NULL, 'k'},{"subscribe", 1, NULL, 'd'},{"start", 1, NULL, 'A'},{"stop", 1, NULL, 'B'},{"token", 1, NULL, 'T'},{"hashes", 0, NULL, '#'},{"debug", 0, NULL, 'z'},{"quiet", 0, NULL, 'q'},{"verbose", 0, NULL, 'V'},{0, 0, 0, 0}};*///分析命令行参数，注意用法。//选项都是一个字母，后面有冒号的代表该选项还有相关参数//一直循环直到获取所有的optwhile ((opt =getopt/*_long*/(argc, argv,"hVveqzr:s:t:p:a:b:f:o:u:C:n:c:l:y:Ym:k:d:A:B:T:w:x:W:X:S:#"/*,longopts, NULL*/)) != -1){//不同的选项做不同的处理switch (opt){case 'h':usage(argv[0]);return RD_SUCCESS;
#ifdef CRYPTOcase 'w':{int res = hex2bin(optarg, &swfHash.av_val);if (res != RTMP_SWF_HASHLEN){swfHash.av_val = NULL;RTMP_Log(RTMP_LOGWARNING,"Couldn't parse swf hash hex string, not hexstring or not %d bytes, ignoring!", RTMP_SWF_HASHLEN);}swfHash.av_len = RTMP_SWF_HASHLEN;break;}case 'x':{int size = atoi(optarg);if (size <= 0){RTMP_Log(RTMP_LOGERROR, "SWF Size must be at least 1, ignoring\n");}else{swfSize = size;}break;}case 'W':STR2AVAL(swfUrl, optarg);swfVfy = 1;break;case 'X':{int num = atoi(optarg);if (num < 0){RTMP_Log(RTMP_LOGERROR, "SWF Age must be non-negative, ignoring\n");}else{swfAge = num;}}break;
#endifcase 'k':nSkipKeyFrames = atoi(optarg);if (nSkipKeyFrames < 0){RTMP_Log(RTMP_LOGERROR,"Number of keyframes skipped must be greater or equal zero, using zero!");nSkipKeyFrames = 0;}else{RTMP_Log(RTMP_LOGDEBUG, "Number of skipped key frames for resume: %d",nSkipKeyFrames);}break;case 'b':{int32_t bt = atol(optarg);if (bt < 0){RTMP_Log(RTMP_LOGERROR,"Buffer time must be greater than zero, ignoring the specified value %d!",bt);}else{bufferTime = bt;bOverrideBufferTime = TRUE;}break;}//直播流case 'v'://----------------rtmp.dlg->AppendCInfo("该RTMP的URL是一个直播流");//----------------bLiveStream = TRUE; // no seeking or resuming possible!break;case 'd':STR2AVAL(subscribepath, optarg);break;case 'n':STR2AVAL(hostname, optarg);break;case 'c':port = atoi(optarg);break;case 'l':protocol = atoi(optarg);if (protocol < RTMP_PROTOCOL_RTMP || protocol > RTMP_PROTOCOL_RTMPTS){RTMP_Log(RTMP_LOGERROR, "Unknown protocol specified: %d", protocol);return RD_FAILED;}break;case 'y':STR2AVAL(playpath, optarg);break;case 'Y':RTMP_SetOpt(&rtmp, &av_playlist, (AVal *)&av_true);break;//路径参数-rcase 'r':{AVal parsedHost, parsedApp, parsedPlaypath;unsigned int parsedPort = 0;int parsedProtocol = RTMP_PROTOCOL_UNDEFINED;//解析URL。注optarg指向参数（URL）RTMP_LogPrintf("RTMP URL : %s\n",optarg);//----------------rtmp.dlg->AppendCInfo("解析RTMP的URL...");//----------------if (!RTMP_ParseURL(optarg, &parsedProtocol, &parsedHost, &parsedPort,&parsedPlaypath, &parsedApp)){//----------------rtmp.dlg->AppendCInfo("解析RTMP的URL失败！");//----------------RTMP_Log(RTMP_LOGWARNING, "无法解析 url (%s)!",optarg);}else{//----------------rtmp.dlg->AppendCInfo("解析RTMP的URL成功");//----------------//把解析出来的数据赋值if (!hostname.av_len)hostname = parsedHost;if (port == -1)port = parsedPort;if (playpath.av_len == 0 && parsedPlaypath.av_len){playpath = parsedPlaypath;}if (protocol == RTMP_PROTOCOL_UNDEFINED)protocol = parsedProtocol;if (app.av_len == 0 && parsedApp.av_len){app = parsedApp;}}break;}case 's':STR2AVAL(swfUrl, optarg);break;case 't':STR2AVAL(tcUrl, optarg);break;case 'p':STR2AVAL(pageUrl, optarg);break;case 'a':STR2AVAL(app, optarg);break;case 'f':STR2AVAL(flashVer, optarg);break;//指定输出文件case 'o':flvFile = optarg;if (strcmp(flvFile, "-"))bStdoutMode = FALSE;break;case 'e':bResume = TRUE;break;case 'u':STR2AVAL(auth, optarg);break;case 'C': {AVal av;STR2AVAL(av, optarg);if (!RTMP_SetOpt(&rtmp, &av_conn, &av)){RTMP_Log(RTMP_LOGERROR, "Invalid AMF parameter: %s", optarg);return RD_FAILED;}}break;case 'm':timeout = atoi(optarg);break;case 'A':dStartOffset = (int) (atof(optarg) * 1000.0);break;case 'B':dStopOffset = (int) (atof(optarg) * 1000.0);break;case 'T': {AVal token;STR2AVAL(token, optarg);RTMP_SetOpt(&rtmp, &av_token, &token);}break;case '#':bHashes = TRUE;break;case 'q':RTMP_debuglevel = RTMP_LOGCRIT;break;case 'V':RTMP_debuglevel = RTMP_LOGDEBUG;break;case 'z':RTMP_debuglevel = RTMP_LOGALL;break;case 'S':STR2AVAL(sockshost, optarg);break;default:RTMP_LogPrintf("unknown option: %c\n", opt);usage(argv[0]);return RD_FAILED;break;}}if (!hostname.av_len){RTMP_Log(RTMP_LOGERROR,"您必须指定 主机名(hostname) (--host) 或 url (-r \"rtmp://host[:port]/playpath\") 包含 a hostname");return RD_FAILED;}if (playpath.av_len == 0){RTMP_Log(RTMP_LOGERROR,"您必须指定 播放路径(playpath) (--playpath) 或 url (-r \"rtmp://host[:port]/playpath\") 包含 a playpath");return RD_FAILED;}if (protocol == RTMP_PROTOCOL_UNDEFINED){RTMP_Log(RTMP_LOGWARNING,"您没有指定 协议(protocol) (--protocol) 或 rtmp url (-r), 默认协议 RTMP");protocol = RTMP_PROTOCOL_RTMP;}if (port == -1){RTMP_Log(RTMP_LOGWARNING,"您没有指定 端口(port) (--port) 或 rtmp url (-r), 默认端口 1935");port = 0;}if (port == 0){if (protocol & RTMP_FEATURE_SSL)port = 443;else if (protocol & RTMP_FEATURE_HTTP)port = 80;elseport = 1935;}if (flvFile == 0){RTMP_Log(RTMP_LOGWARNING,"请指定一个输出文件 (-o filename), using stdout");bStdoutMode = TRUE;}if (bStdoutMode && bResume){RTMP_Log(RTMP_LOGWARNING,"Can't resume in stdout mode, ignoring --resume option");bResume = FALSE;}if (bLiveStream && bResume){RTMP_Log(RTMP_LOGWARNING, "Can't resume live stream, ignoring --resume option");bResume = FALSE;}#ifdef CRYPTOif (swfVfy){if (RTMP_HashSWF(swfUrl.av_val, (unsigned int *)&swfSize, hash, swfAge) == 0){swfHash.av_val = (char *)hash;swfHash.av_len = RTMP_SWF_HASHLEN;}}if (swfHash.av_len == 0 && swfSize > 0){RTMP_Log(RTMP_LOGWARNING,"Ignoring SWF size, supply also the hash with --swfhash");swfSize = 0;}if (swfHash.av_len != 0 && swfSize == 0){RTMP_Log(RTMP_LOGWARNING,"Ignoring SWF hash, supply also the swf size with --swfsize");swfHash.av_len = 0;swfHash.av_val = NULL;}
#endifif (tcUrl.av_len == 0){char str[512] = { 0 };tcUrl.av_len = snprintf(str, 511, "%s://%.*s:%d/%.*s",RTMPProtocolStringsLower[protocol], hostname.av_len,hostname.av_val, port, app.av_len, app.av_val);tcUrl.av_val = (char *) malloc(tcUrl.av_len + 1);strcpy(tcUrl.av_val, str);}int first = 1;// User defined seek offsetif (dStartOffset > 0){//直播流if (bLiveStream){RTMP_Log(RTMP_LOGWARNING,"Can't seek in a live stream, ignoring --start option");dStartOffset = 0;}}//----------------rtmp.dlg->AppendCInfo("开始初始化RTMP连接的参数...");//----------------//设置RTMP_SetupStream(&rtmp, protocol, &hostname, port, &sockshost, &playpath,&tcUrl, &swfUrl, &pageUrl, &app, &auth, &swfHash, swfSize,&flashVer, &subscribepath, dSeek, dStopOffset, bLiveStream, timeout);//此处设置参数-----------------rtmp.dlg->AppendCInfo("成功初始化RTMP连接的参数");//-----------------------------char *temp=(char *)malloc(MAX_URL_LENGTH);memcpy(temp,rtmp.Link.hostname.av_val,rtmp.Link.hostname.av_len);temp[rtmp.Link.hostname.av_len]='\0';rtmp.dlg->AppendB_R_L_Info("主机名",temp);itoa(rtmp.Link.port,temp,10);rtmp.dlg->AppendB_R_L_Info("端口号",temp);memcpy(temp,rtmp.Link.app.av_val,rtmp.Link.app.av_len);temp[rtmp.Link.app.av_len]='\0';rtmp.dlg->AppendB_R_L_Info("应用程序",temp);memcpy(temp,rtmp.Link.playpath.av_val,rtmp.Link.playpath.av_len);temp[rtmp.Link.playpath.av_len]='\0';rtmp.dlg->AppendB_R_L_Info("路径",temp);//-----------------------------/* Try to keep the stream moving if it pauses on us */if (!bLiveStream && !(protocol & RTMP_FEATURE_HTTP))rtmp.Link.lFlags |= RTMP_LF_BUFX;off_t size = 0;// ok,我们必须获得timestamp of the last keyframe (only keyframes are seekable) / last audio frame (audio only streams)if (bResume){//打开文件，输出的文件(Resume)nStatus =OpenResumeFile(flvFile, &file, &size, &metaHeader, &nMetaHeaderSize,&duration);if (nStatus == RD_FAILED)goto clean;if (!file){// file does not exist, so go back into normal modebResume = FALSE; // we are back in fresh file mode (otherwise finalizing file won't be done)}else{//获取最后一个关键帧nStatus = GetLastKeyframe(file, nSkipKeyFrames,&dSeek, &initialFrame,&initialFrameType, &nInitialFrameSize);if (nStatus == RD_FAILED){RTMP_Log(RTMP_LOGDEBUG, "Failed to get last keyframe.");goto clean;}if (dSeek == 0){RTMP_Log(RTMP_LOGDEBUG,"Last keyframe is first frame in stream, switching from resume to normal mode!");bResume = FALSE;}}}//如果输出文件不存在if (!file){if (bStdoutMode){//直接输出到stdoutfile = stdout;SET_BINMODE(file);}else{//打开一个文件//w+b 读写打开或建立一个二进制文件，允许读和写。//-----------------rtmp.dlg->AppendCInfo("创建输出文件...");//-----------------------------file = fopen(flvFile, "w+b");if (file == 0){//-----------------rtmp.dlg->AppendCInfo("创建输出文件失败！");//-----------------------------RTMP_LogPrintf("Failed to open file! %s\n", flvFile);return RD_FAILED;}rtmp.dlg->AppendCInfo("成功创建输出文件");}}#ifdef _DEBUGnetstackdump = fopen("netstackdump", "wb");netstackdump_read = fopen("netstackdump_read", "wb");
#endifwhile (!RTMP_ctrlC){RTMP_Log(RTMP_LOGDEBUG, "Setting buffer time to: %dms", bufferTime);//设置Buffer时间//-----------------rtmp.dlg->AppendCInfo("设置缓冲(Buffer)的时间");//-----------------------------RTMP_SetBufferMS(&rtmp, bufferTime);//第一次执行if (first){first = 0;RTMP_LogPrintf("开始建立连接！\n");//-----------------rtmp.dlg->AppendCInfo("开始建立连接（NetConnection）...");//-----------------------------//建立连接(Connect)if (!RTMP_Connect(&rtmp, NULL)){//-----------------rtmp.dlg->AppendCInfo("建立连接（NetConnection）失败！");//-----------------------------nStatus = RD_FAILED;break;}//-----------------rtmp.dlg->AppendCInfo("成功建立连接（NetConnection）");//-----------------------------//RTMP_Log(RTMP_LOGINFO, "已链接...");// User defined seek offsetif (dStartOffset > 0){// Don't need the start offset if resuming an existing fileif (bResume){RTMP_Log(RTMP_LOGWARNING,"Can't seek a resumed stream, ignoring --start option");dStartOffset = 0;}else{dSeek = dStartOffset;}}// Calculate the length of the stream to still playif (dStopOffset > 0){// Quit if start seek is past required stop offsetif (dStopOffset <= dSeek){RTMP_LogPrintf("Already Completed\n");nStatus = RD_SUCCESS;break;}}//创建流(Stream)（发送connect命令消息后处理传来的数据）itoa(rtmp.m_inChunkSize,temp,10);rtmp.dlg->AppendB_R_Info("输入Chunk大小",temp);itoa(rtmp.m_outChunkSize,temp,10);rtmp.dlg->AppendB_R_Info("输出Chunk大小",temp);itoa(rtmp.m_stream_id,temp,10);rtmp.dlg->AppendB_R_Info("Stream ID",temp);itoa(rtmp.m_nBufferMS,temp,10);rtmp.dlg->AppendB_R_Info("Buffer时长（ms）",temp);itoa(rtmp.m_nServerBW,temp,10);rtmp.dlg->AppendB_R_Info("ServerBW",temp);itoa(rtmp.m_nClientBW,temp,10);rtmp.dlg->AppendB_R_Info("ClientBW",temp);itoa((int)rtmp.m_fEncoding,temp,10);rtmp.dlg->AppendB_R_Info("命令消息编码方法",temp);itoa((int)rtmp.m_fDuration,temp,10);rtmp.dlg->AppendB_R_Info("时长（s）",temp);rtmp.dlg->ShowBInfo();free(temp);//-----------------rtmp.dlg->AppendCInfo("开始建立网络流（NetStream）");//-----------------------------if (!RTMP_ConnectStream(&rtmp, dSeek)){//-----------------rtmp.dlg->AppendCInfo("建立网络流（NetStream）失败！");//-----------------nStatus = RD_FAILED;break;}//-----------------rtmp.dlg->AppendCInfo("成功建立网络流（NetStream）！");//-----------------}else{nInitialFrameSize = 0;if (retries){RTMP_Log(RTMP_LOGERROR, "Failed to resume the stream\n\n");if (!RTMP_IsTimedout(&rtmp))nStatus = RD_FAILED;elsenStatus = RD_INCOMPLETE;break;}RTMP_Log(RTMP_LOGINFO, "Connection timed out, trying to resume.\n\n");/* Did we already try pausing, and it still didn't work? */if (rtmp.m_pausing == 3){/* Only one try at reconnecting... */retries = 1;dSeek = rtmp.m_pauseStamp;if (dStopOffset > 0){if (dStopOffset <= dSeek){RTMP_LogPrintf("Already Completed\n");nStatus = RD_SUCCESS;break;}}if (!RTMP_ReconnectStream(&rtmp, dSeek)){RTMP_Log(RTMP_LOGERROR, "Failed to resume the stream\n\n");if (!RTMP_IsTimedout(&rtmp))nStatus = RD_FAILED;elsenStatus = RD_INCOMPLETE;break;}}else if (!RTMP_ToggleStream(&rtmp)){RTMP_Log(RTMP_LOGERROR, "Failed to resume the stream\n\n");if (!RTMP_IsTimedout(&rtmp))nStatus = RD_FAILED;elsenStatus = RD_INCOMPLETE;break;}bResume = TRUE;}//-----------------//-----------------rtmp.dlg->AppendCInfo("开始将媒体数据写入文件");//-----------------//下载,写入文件nStatus = Download(&rtmp, file, dSeek, dStopOffset, duration, bResume,metaHeader, nMetaHeaderSize, initialFrame,initialFrameType, nInitialFrameSize,nSkipKeyFrames, bStdoutMode, bLiveStream, bHashes,bOverrideBufferTime, bufferTime, &percent);free(initialFrame);initialFrame = NULL;/* If we succeeded, we're done.*/if (nStatus != RD_INCOMPLETE || !RTMP_IsTimedout(&rtmp) || bLiveStream)break;}//当下载完的时候if (nStatus == RD_SUCCESS){//-----------------rtmp.dlg->AppendCInfo("写入文件完成");//-----------------RTMP_LogPrintf("Download complete\n");}//没下载完的时候else if (nStatus == RD_INCOMPLETE){//-----------------rtmp.dlg->AppendCInfo("写入文件可能不完整");//-----------------RTMP_LogPrintf("Download may be incomplete (downloaded about %.2f%%), try resuming\n",percent);}//后续清理工作
clean://-----------------rtmp.dlg->AppendCInfo("关闭连接");//-----------------RTMP_Log(RTMP_LOGDEBUG, "Closing connection.\n");RTMP_Close(&rtmp);rtmp.dlg->AppendCInfo("关闭文件");if (file != 0)fclose(file);rtmp.dlg->AppendCInfo("关闭Socket");CleanupSockets();#ifdef _DEBUGif (netstackdump != 0)fclose(netstackdump);if (netstackdump_read != 0)fclose(netstackdump_read);
#endifreturn nStatus;
}
其中InitSocket()代码很简单，初始化了Socket，如下：
// 初始化 sockets
int
InitSockets()
{
#ifdef WIN32WORD version;WSADATA wsaData;version = MAKEWORD(1, 1);return (WSAStartup(version, &wsaData) == 0);
#elsereturn TRUE;
#endif
}CleanupSockets()则更简单：
inline void
CleanupSockets()
{
#ifdef WIN32WSACleanup();
#endif
}Download()函数则比较复杂：
int
Download(RTMP * rtmp, // connected RTMP objectFILE * file, uint32_t dSeek, uint32_t dStopOffset, double duration, int bResume, char *metaHeader, uint32_t nMetaHeaderSize, char *initialFrame, int initialFrameType, uint32_t nInitialFrameSize, int nSkipKeyFrames, int bStdoutMode, int bLiveStream, int bHashes, int bOverrideBufferTime, uint32_t bufferTime, double *percent) // percentage downloaded [out]
{int32_t now, lastUpdate;int bufferSize = 64 * 1024;char *buffer = (char *) malloc(bufferSize);int nRead = 0;//long ftell(FILE *stream);//返回当前文件指针RTMP_LogPrintf("开始下载！\n");off_t size = ftello(file);unsigned long lastPercent = 0;//时间戳rtmp->m_read.timestamp = dSeek;*percent = 0.0;if (rtmp->m_read.timestamp){RTMP_Log(RTMP_LOGDEBUG, "Continuing at TS: %d ms\n", rtmp->m_read.timestamp);}//是直播if (bLiveStream){RTMP_LogPrintf("直播流\n");}else{// print initial status// Workaround to exit with 0 if the file is fully (> 99.9%) downloadedif (duration > 0){if ((double) rtmp->m_read.timestamp >= (double) duration * 999.0){RTMP_LogPrintf("Already Completed at: %.3f sec Duration=%.3f sec\n",(double) rtmp->m_read.timestamp / 1000.0,(double) duration / 1000.0);return RD_SUCCESS;}else{*percent = ((double) rtmp->m_read.timestamp) / (duration * 1000.0) * 100.0;*percent = ((double) (int) (*percent * 10.0)) / 10.0;RTMP_LogPrintf("%s download at: %.3f kB / %.3f sec (%.1f%%)\n",bResume ? "Resuming" : "Starting",(double) size / 1024.0, (double) rtmp->m_read.timestamp / 1000.0,*percent);}}else{RTMP_LogPrintf("%s download at: %.3f kB\n",bResume ? "Resuming" : "Starting",(double) size / 1024.0);}}if (dStopOffset > 0)RTMP_LogPrintf("For duration: %.3f sec\n", (double) (dStopOffset - dSeek) / 1000.0);//各种设置参数到rtmp连接if (bResume && nInitialFrameSize > 0)rtmp->m_read.flags |= RTMP_READ_RESUME;rtmp->m_read.initialFrameType = initialFrameType;rtmp->m_read.nResumeTS = dSeek;rtmp->m_read.metaHeader = metaHeader;rtmp->m_read.initialFrame = initialFrame;rtmp->m_read.nMetaHeaderSize = nMetaHeaderSize;rtmp->m_read.nInitialFrameSize = nInitialFrameSize;now = RTMP_GetTime();lastUpdate = now - 1000;do{//从rtmp中把bufferSize（64k）个数据读入buffernRead = RTMP_Read(rtmp, buffer, bufferSize);//RTMP_LogPrintf("nRead: %d\n", nRead);if (nRead > 0){//函数：size_t fwrite(const void* buffer,size_t size,size_t count,FILE* stream);//向文件读入写入一个数据块。返回值：返回实际写入的数据块数目//（1）buffer：是一个指针，对fwrite来说，是要输出数据的地址。//（2）size：要写入内容的单字节数； //（3）count:要进行写入size字节的数据项的个数； //（4）stream:目标文件指针。 //（5）返回实际写入的数据项个数count。//关键。把buffer里面的数据写成文件if (fwrite(buffer, sizeof(unsigned char), nRead, file) !=(size_t) nRead){RTMP_Log(RTMP_LOGERROR, "%s: Failed writing, exiting!", __FUNCTION__);free(buffer);return RD_FAILED;}//记录已经写入的字节数size += nRead;//RTMP_LogPrintf("write %dbytes (%.1f kB)\n", nRead, nRead/1024.0);if (duration <= 0) // if duration unknown try to get it from the stream (onMetaData)duration = RTMP_GetDuration(rtmp);if (duration > 0){// make sure we claim to have enough buffer time!if (!bOverrideBufferTime && bufferTime < (duration * 1000.0)){bufferTime = (uint32_t) (duration * 1000.0) + 5000; // 再加5s以确保buffertime足够长RTMP_Log(RTMP_LOGDEBUG,"Detected that buffer time is less than duration, resetting to: %dms",bufferTime);//重设Buffer长度RTMP_SetBufferMS(rtmp, bufferTime);//给服务器发送UserControl消息通知Buffer改变RTMP_UpdateBufferMS(rtmp);}//计算百分比*percent = ((double) rtmp->m_read.timestamp) / (duration * 1000.0) * 100.0;*percent = ((double) (int) (*percent * 10.0)) / 10.0;if (bHashes){if (lastPercent + 1 <= *percent){RTMP_LogStatus("#");lastPercent = (unsigned long) *percent;}}else{//设置显示数据的更新间隔200msnow = RTMP_GetTime();if (abs(now - lastUpdate) > 200){RTMP_LogStatus("\r%.3f kB / %.2f sec (%.1f%%)",(double) size / 1024.0,(double) (rtmp->m_read.timestamp) / 1000.0, *percent);lastUpdate = now;}}}else{//现在距离开机的毫秒数now = RTMP_GetTime();//每间隔200ms刷新一次数据if (abs(now - lastUpdate) > 200){if (bHashes)RTMP_LogStatus("#");else//size为已写入文件的字节数RTMP_LogStatus("\r%.3f kB / %.2f sec", (double) size / 1024.0,(double) (rtmp->m_read.timestamp) / 1000.0);lastUpdate = now;}}}
#ifdef _DEBUGelse{RTMP_Log(RTMP_LOGDEBUG, "zero read!");}
#endif}while (!RTMP_ctrlC && nRead > -1 && RTMP_IsConnected(rtmp) && !RTMP_IsTimedout(rtmp));free(buffer);if (nRead < 0)//nRead是读取情况nRead = rtmp->m_read.status;/* Final status update */if (!bHashes){if (duration > 0){*percent = ((double) rtmp->m_read.timestamp) / (duration * 1000.0) * 100.0;*percent = ((double) (int) (*percent * 10.0)) / 10.0;//输出RTMP_LogStatus("\r%.3f kB / %.2f sec (%.1f%%)",(double) size / 1024.0,(double) (rtmp->m_read.timestamp) / 1000.0, *percent);}else{RTMP_LogStatus("\r%.3f kB / %.2f sec", (double) size / 1024.0,(double) (rtmp->m_read.timestamp) / 1000.0);}}RTMP_Log(RTMP_LOGDEBUG, "RTMP_Read returned: %d", nRead);//读取错误if (bResume && nRead == -2){RTMP_LogPrintf("Couldn't resume FLV file, try --skip %d\n\n",nSkipKeyFrames + 1);return RD_FAILED;}//读取正确if (nRead == -3)return RD_SUCCESS;//没读完...if ((duration > 0 && *percent < 99.9) || RTMP_ctrlC || nRead < 0|| RTMP_IsTimedout(rtmp)){return RD_INCOMPLETE;}return RD_SUCCESS;
}以上内容是我能理解到的rtmpdump.c里面的内容。
rtmpdump源代码（Linux）：http://download.csdn.net/detail/leixiaohua1020/6376561
rtmpdump源代码（VC 2005 工程）：http://download.csdn.net/detail/leixiaohua1020/6563163
