sysbench的官网地址是：http：//sysbench.sourceforge.net
Step 1： 下载安装： sysbench-0.5.tar.gz 解压后展开目录如下
[root@localhost mnt]# cd sysbench-0.5
[root@localhost sysbench-0.5]# ls
aclocal.m4 autom4te.cache config config.status configure.ac doc libtool Makefile Makefile.in mkinstalldirs README-WIN.txt TODO
autogen.sh ChangeLog config.log configure COPYING install-sh m4 Makefile.am missing README sysbench
[root@localhost sysbench-0.5]#查看README文件可以看到安装方法：
./autogen.sh
./configure
make
make install
Sysbench --help可以看到具有以下功能
Compiled-in tests:
fileio - File I/O test IO性能测试
cpu - CPU performance test CPU性能测试
memory - Memory functions speed test 内存性能测试
threads - Threads subsystem performance test 线程子系统性能测试
mutex - Mutex performance test 互斥测试
Step2 Sysbench CPU性能测试：
Sysbench 测试CPU是通过计算素数的加法运算，它会自动生成素数，并进行相加；一般可以指定最大值，默认10000；
我们用命令：sysbench --test=cpu --cpu-max-prime=20000 run
[root@localhost sysbench-0.5]# sysbench --test=cpu --cpu-max-prime=20000 run
sysbench 0.5: multi-threaded system evaluation benchmark
--版本
Running the test with following options:
Number of threads: 1
--使用一个线程
Random number generator seed is 0 and will be ignored
随机数生成素数0将会被忽略Primer numbers limit: 20000
最大素数上线20000
Threads started!Test execution summary:total time: 29.5438s --总共花费时间total number of events: 10000 --一共计算10000次total time taken by event execution: 29.5402s --事件（一个素数计算做一个事件）执行时间per-request statistics:min: 2.48ms --最小计算花费时间avg: 2.95ms --平均max: 56.82ms --最大approx. 95 percentile: 3.85ms --95%的计算花费时间Threads fairness:events (avg/stddev): 10000.0000/0.00 计算事件总数execution time (avg/stddev): 29.5402/0.00 计算花费时间总数
可以看到压测的时候CPU被sysbench占满了；
Step3: IO测试：
sysbench --test=fileio helpfileio options:--file-num=N number of files to create [128] 创建文件数量，默认128--file-block-size=N block size to use in all IO operations [16384] 块儿大小，默认16384，即Innodb的存储引擎Page大小；如果要测试Innodb就用默认；--file-total-size=SIZE total size of files to create [2G] 生成测试文件的总大小--file-test-mode=STRING test mode {seqwr（顺序写）、seqrewr（顺序读写）、seqrd（顺序读）、rndrd（随机读）、rndwr（随机写）和rndrw（随机读写）}--file-io-mode=STRING 文件IO模式，同步/异步/快速映射/慢映射{sync,async,fastmmap,slowmmap} [sync]。--file-extra-flags=STRING additional flags to use on opening files {sync,dsync,direct} [] 打开文件的额外选项--file-fsync-freq=N do fsync() after this number of requests (0 - don't use fsync()) [100]执行写入fsync()的频率，fsync()用于写入数据导磁盘 默认100次请求就写入一次导磁盘--file-fsync-all=[on|off] do fsync() after each write operation [off] 每次写操作都同步到磁盘--file-fsync-end=[on|off] do fsync() at the end of test [on] 测试结束同步至磁盘--file-fsync-mode=STRING which method to use for synchronization {fsync, fdatasync} [fsync]使用哪种方法写入磁盘--file-merged-requests=N merge at most this number of IO requests if possible (0 - don't merge) [0] 合并改数量的IO请求--file-rw-ratio=N reads/writes ratio for combined test [1.5]。 写/读组合比测试，默认1:1.5sysbench的fileio测试需要经过prepare、run和clean三个阶段。
- prepare是准备阶段，生产我们需要的测试文件
- run是实际测试阶段
- cleanup是清理测试产生的文
sysbench --test=fileio --file-num=16 --file-total-size=2G prepare 生成16个测试文件，总大小2G
此时会生成测试文件，因为总大小2G，数量16个，所以每个文件约129M；
sysbench --test=fileio --file-num=16 --file-total-size=2G --file-test-mode=rndrw run 采用随机读写的方式测试：
[root@localhost mnt]# sysbench --test=fileio --file-num=16 --file-total-size=2G --file-test-mode=rndrw run --测试模式，随机读写
sysbench 0.5: multi-threaded system evaluation benchmarkRunning the test with following options:
Number of threads: 1 --线程1个
Random number generator seed is 0 and will be ignoredThreads started!Operations performed: 6000 reads, 4000 writes, 1600 Other = 11600 Total
6000次读，4000次写（因为默认1.5:1）1600次其他操作；
Read 93.75Mb Written 62.5Mb Total transferred 156.25Mb (276.57Mb/sec)
随机读了93.75M数据，写了62.5M数据 总IO 156.25M
17700.40 Requests/sec executed
每秒执行17700次
Test execution summary:total time: 0.5650s 总耗费时间total number of events: 10000 读写次数10000次total time taken by event execution: 0.3961s 读写花费时间per-request statistics:min: 0.00ms 最小时间avg: 0.04ms 平均时间max: 20.24ms 最大时间approx. 95 percentile: 0.08ms 95%读写花费时间Threads fairness:events (avg/stddev): 10000.0000/0.00execution time (avg/stddev): 0.3961/0.00sysbench --test=fileio --file-num=16 --file-total-size=2G --file-test-mode=rndrw cleanup 最后执行clearnup清除测试数据
Step 4: 线程测试：
sysbench --num-threads=64 --test=threads --thread-yields=2000 --thread-locks=2 run
并发线程64，采用线程测试方法，每个请求产生2000个线程，每个线程锁2个；
[root@localhost sysbench-0.5]# sysbench --test=threads --num-threads=64 --thread-yields=2000 --thread-locks=2 run
sysbench 0.5: multi-threaded system evaluation benchmarkRunning the test with following options:
Number of threads: 64 --并发线程64个
Random number generator seed is 0 and will be ignoredThreads started!Test execution summary:total time: 15.7261s total number of events: 10000 total time taken by event execution: 1004.5724sper-request statistics:min: 0.58msavg: 100.46msmax: 1049.29msapprox. 95 percentile: 246.15msThreads fairness:events (avg/stddev): 156.2500/7.99execution time (avg/stddev): 15.6964/0.02
Step5: 内存测试
sysbench --num-threads=64 --test=memory --memory-block-size=8k --memory-total-size=16G --memory-scope=global --memory-access-mode=rnd run
[root@localhost sysbench-0.5]# sysbench --num-threads=64 --test=memory --memory-block-size=8k --memory-total-size=16G --memory-scope=global --memory-access-mode=rnd run
sysbench 0.5: multi-threaded system evaluation benchmarkRunning the test with following options:
Number of threads: 64
Random number generator seed is 0 and will be ignoredThreads started!Operations performed: 2097152 (3690132.19 ops/sec)16384.00 MB transferred (28829.16 MB/sec)Test execution summary:total time: 0.5683stotal number of events: 2097152total time taken by event execution: 20.6291sper-request statistics:min: 0.00msavg: 0.01msmax: 351.43msapprox. 95 percentile: 0.00msThreads fairness:events (avg/stddev): 32768.0000/8682.67execution time (avg/stddev): 0.3223/0.06[root@localhost sysbench-0.5]#
