vue+科大讯飞语音听写功能(解决针对vue new Worker报错问题)

参考1：vue+科大讯飞语音听写功能(解决针对vue new Worker报错问题)_Other world的博客-CSDN博客

参考2：vue中使用web worker - Gerryli - 博客园

参考3：将PC浏览器、ZOOM等软件正在播放的音频实时转成文字！讯飞语音输入法的妙用 - 知乎

1.查看node版本，本人如下：

本人项目目录，主要用到的画红色圈圈的三个文件

2.添加 package.json 文件版本：

"dependencies": {enc": "^0.4.0","jquery": "^3.4.1",},
"devDependencies": {"crypto-js": "^4.0.0","vconsole": "^3.3.4","vue-template-compiler": "2.6.12","worker-loader": "^2.0.0"
}

3. 配置 vue.config.js 文件

不配置会报错 TypeError: _transcodeWorker.default is not a constructor

vue.config.js要添加以下配置：

configureWebpack: config => {config.module.rules.push({test: /\.worker.js$/,use: {loader: 'worker-loader',options: { inline: true, name: 'workerName.[hash].js' }}})},或（因本人配置不是函数模式，采用的是以下对象模式配置）：chainWebpack(config) {config.output.globalObject('this')config.module.rule('worker').test(/\.worker.js$/).use('worker-loader').loader('worker-loader').options({ inline: true, name: 'workerName.[hash].js' })}

在你运行时候,会发现控制台会报错，“window is undefined”，这个是因为worker线程中不存在window对象，因此不能直接使用，要用this代替，要在vue.config.js中添加以下配置

chainWebpack: config => {config.output.globalObject('this')}

打包的时候报错就加上:

parallel: false

合成一起就是

module.exports = {configureWebpack: config => {config.module.rules.push({test: /\.worker.js$/,use: {loader: 'worker-loader',options: { inline: true, name: 'workerName.[hash].js' }}})},parallel: false,chainWebpack: config => {config.output.globalObject('this')}
}

配置完后你会发现不会报错了，然后就可以正常运行了!

3. 创建 transcode.worker.js 文件，（在语音听写流式API demo js语言讯飞源文件中取）

// (function(){
self.onmessage = function(e){transAudioData.transcode(e.data)
}
let transAudioData = {transcode(audioData) {let output = transAudioData.to16kHz(audioData)output = transAudioData.to16BitPCM(output)output = Array.from(new Uint8Array(output.buffer))self.postMessage(output)// return output},to16kHz(audioData) {var data = new Float32Array(audioData)var fitCount = Math.round(data.length * (16000 / 44100))var newData = new Float32Array(fitCount)var springFactor = (data.length - 1) / (fitCount - 1)newData[0] = data[0]for (let i = 1; i < fitCount - 1; i++) {var tmp = i * springFactorvar before = Math.floor(tmp).toFixed()var after = Math.ceil(tmp).toFixed()var atPoint = tmp - beforenewData[i] = data[before] + (data[after] - data[before]) * atPoint}newData[fitCount - 1] = data[data.length - 1]return newData},to16BitPCM(input) {var dataLength = input.length * (16 / 8)var dataBuffer = new ArrayBuffer(dataLength)var dataView = new DataView(dataBuffer)var offset = 0for (var i = 0; i < input.length; i++, offset += 2) {var s = Math.max(-1, Math.min(1, input[i]))dataView.setInt16(offset, s < 0 ? s * 0x8000 : s * 0x7fff, true)}return dataView},
}
// })()

4. 创建 translation.js 文件，（在语音听写流式API demo js语言讯飞源文件中取 src\pages\index\index.js）


import CryptoJS from 'crypto-js'
import Enc from 'enc'
import VConsole from 'vconsole'
import $ from 'jquery'
import TransWorker from './js/transcode.worker.js'
import './index.css'let transWorker = new TransWorker()
//APPID，APISecret，APIKey在控制台-我的应用-语音听写（流式版）页面获取
const APPID = 'd7b51bcb'
const API_SECRET = 'ZTNmZjk3N2FkZTljZjg0YTYzMGZiNmZj'
const API_KEY = '4bc26e6fd3868195919a8c14054eac66'/*** 获取websocket url* 该接口需要后端提供，这里为了方便前端处理*/
function getWebSocketUrl() {return new Promise((resolve, reject) => {// 请求地址根据语种不同变化var url = 'wss://iat-api.xfyun.cn/v2/iat'var host = 'iat-api.xfyun.cn'var apiKey = API_KEYvar apiSecret = API_SECRETvar date = new Date().toGMTString()var algorithm = 'hmac-sha256'var headers = 'host date request-line'var signatureOrigin = `host: ${host}\ndate: ${date}\nGET /v2/iat HTTP/1.1`var signatureSha = CryptoJS.HmacSHA256(signatureOrigin, apiSecret)var signature = CryptoJS.enc.Base64.stringify(signatureSha)var authorizationOrigin = `api_key="${apiKey}", algorithm="${algorithm}", headers="${headers}", signature="${signature}"`var authorization = btoa(authorizationOrigin)url = `${url}?authorization=${authorization}&date=${date}&host=${host}`resolve(url)})
}
class IatRecorder {constructor({ language, accent, appId } = {}) {let self = thisthis.status = 'null'this.language = language || 'zh_cn'this.accent = accent || 'mandarin'this.appId = appId || APPID// 记录音频数据this.audioData = []// 记录听写结果this.resultText = ''// wpgs下的听写结果需要中间状态辅助记录this.resultTextTemp = ''transWorker.onmessage = function (event) {self.audioData.push(...event.data)}}// 修改录音听写状态setStatus(status) {this.onWillStatusChange && this.status !== status && this.onWillStatusChange(this.status, status)this.status = status}setResultText({ resultText, resultTextTemp } = {}) {this.onTextChange && this.onTextChange(resultTextTemp || resultText || '')resultText !== undefined && (this.resultText = resultText)resultTextTemp !== undefined && (this.resultTextTemp = resultTextTemp)}// 修改听写参数setParams({ language, accent } = {}) {language && (this.language = language)accent && (this.accent = accent)}// 连接websocketconnectWebSocket() {return getWebSocketUrl().then(url => {console.log(url)let iatWSif ('WebSocket' in window) {iatWS = new WebSocket(url)} else if ('MozWebSocket' in window) {iatWS = new MozWebSocket(url)} else {alert('浏览器不支持WebSocket')return}this.webSocket = iatWSthis.setStatus('init')iatWS.onopen = e => {this.setStatus('ing')// 重新开始录音setTimeout(() => {this.webSocketSend()}, 100)}iatWS.onmessage = e => {this.result(e.data)}iatWS.onerror = e => {this.recorderStop()}iatWS.onclose = e => {this.recorderStop()}})}// 初始化浏览器录音recorderInit() {navigator.getUserMedia =navigator.getUserMedia ||navigator.webkitGetUserMedia ||navigator.mozGetUserMedia ||navigator.msGetUserMedia// 创建音频环境try {this.audioContext = new (window.AudioContext || window.webkitAudioContext)()this.audioContext.resume()if (!this.audioContext) {alert('浏览器不支持webAudioApi相关接口')return}} catch (e) {if (!this.audioContext) {alert('浏览器不支持webAudioApi相关接口')return}}// 获取浏览器录音权限if (navigator.mediaDevices && navigator.mediaDevices.getUserMedia) {navigator.mediaDevices.getUserMedia({audio: true,video: false,}).then(stream => {getMediaSuccess(stream)}).catch(e => {getMediaFail(e)})} else if (navigator.getUserMedia) {navigator.getUserMedia({audio: true,video: false,},stream => {getMediaSuccess(stream)},function(e) {getMediaFail(e)})} else {if (navigator.userAgent.toLowerCase().match(/chrome/) && location.origin.indexOf('https://') < 0) {alert('chrome下获取浏览器录音功能，因为安全性问题，需要在localhost或127.0.0.1或https下才能获取权限')} else {alert('无法获取浏览器录音功能，请升级浏览器或使用chrome')}this.audioContext && this.audioContext.close()return}// 获取浏览器录音权限成功的回调let getMediaSuccess = stream => {console.log('getMediaSuccess')// 创建一个用于通过JavaScript直接处理音频this.scriptProcessor = this.audioContext.createScriptProcessor(0, 1, 1)this.scriptProcessor.onaudioprocess = e => {// 去处理音频数据if (this.status === 'ing') {transWorker.postMessage(e.inputBuffer.getChannelData(0))}}// 创建一个新的MediaStreamAudioSourceNode 对象，使来自MediaStream的音频可以被播放和操作this.mediaSource = this.audioContext.createMediaStreamSource(stream)// 连接this.mediaSource.connect(this.scriptProcessor)this.scriptProcessor.connect(this.audioContext.destination)this.connectWebSocket()}let getMediaFail = (e) => {alert('请求麦克风失败')console.log(e)this.audioContext && this.audioContext.close()this.audioContext = undefined// 关闭websocketif (this.webSocket && this.webSocket.readyState === 1) {this.webSocket.close()}}}recorderStart() {if (!this.audioContext) {console.log("11111111")this.recorderInit()} else {console.log("22222222")this.audioContext.resume()this.connectWebSocket()}}// 暂停录音recorderStop() {// safari下suspend后再次resume录音内容将是空白，设置safari下不做suspendif (!(/Safari/.test(navigator.userAgent) && !/Chrome/.test(navigator.userAgen))){this.audioContext && this.audioContext.suspend()}this.setStatus('end')}// 处理音频数据// transAudioData(audioData) {//   audioData = transAudioData.transaction(audioData)//   this.audioData.push(...audioData)// }// 对处理后的音频数据进行base64编码，toBase64(buffer) {var binary = ''var bytes = new Uint8Array(buffer)var len = bytes.byteLengthfor (var i = 0; i < len; i++) {binary += String.fromCharCode(bytes[i])}return window.btoa(binary)}// 向webSocket发送数据webSocketSend() {if (this.webSocket.readyState !== 1) {return}let audioData = this.audioData.splice(0, 1280)console.log(audioData)var params = {common: {app_id: this.appId,},business: {language: this.language, //小语种可在控制台--语音听写（流式）--方言/语种处添加试用domain: 'iat',accent: this.accent, //中文方言可在控制台--语音听写（流式）--方言/语种处添加试用vad_eos: 60*60*1000,dwa: 'wpgs', //为使该功能生效，需到控制台开通动态修正功能（该功能免费）},data: {status: 0,format: 'audio/L16;rate=16000',encoding: 'raw',audio: this.toBase64(audioData),},}this.webSocket.send(JSON.stringify(params))this.handlerInterval = setInterval(() => {// websocket未连接if (this.webSocket.readyState !== 1) {console.log("websocket未连接")this.audioData = []clearInterval(this.handlerInterval)return}if (this.audioData.length === 0) {console.log("自动关闭",this.status)if (this.status === 'end') {this.webSocket.send(JSON.stringify({data: {status: 2,format: 'audio/L16;rate=16000',encoding: 'raw',audio: '',},}))this.audioData = []clearInterval(this.handlerInterval)}return false}audioData = this.audioData.splice(0, 1280)// 中间帧this.webSocket.send(JSON.stringify({data: {status: 1,format: 'audio/L16;rate=16000',encoding: 'raw',audio: this.toBase64(audioData),},}))}, 40)}result(resultData) {// 识别结束let jsonData = JSON.parse(resultData)if (jsonData.data && jsonData.data.result) {let data = jsonData.data.resultlet str = ''let resultStr = ''let ws = data.wsfor (let i = 0; i < ws.length; i++) {str = str + ws[i].cw[0].w}console.log("识别的结果为：",str)// 开启wpgs会有此字段(前提：在控制台开通动态修正功能)// 取值为 "apd"时表示该片结果是追加到前面的最终结果；取值为"rpl" 时表示替换前面的部分结果，替换范围为rg字段if (data.pgs) {if (data.pgs === 'apd') {// 将resultTextTemp同步给resultTextthis.setResultText({resultText: this.resultTextTemp,})}// 将结果存储在resultTextTemp中this.setResultText({resultTextTemp: this.resultText + str,})} else {this.setResultText({resultText: this.resultText + str,})}}if (jsonData.code === 0 && jsonData.data.status === 2) {this.webSocket.close()}if (jsonData.code !== 0) {this.webSocket.close()console.log(`${jsonData.code}:${jsonData.message}`)}}start() {this.recorderStart()this.setResultText({ resultText: '', resultTextTemp: '' })}stop() {this.recorderStop()}
}// ======================开始调用=============================
var vConsole = new VConsole()
let iatRecorder = new IatRecorder()
let countInterval
// 状态改变时处罚
iatRecorder.onWillStatusChange = function(oldStatus, status) {// 可以在这里进行页面中一些交互逻辑处理：倒计时（听写只有60s）,录音的动画，按钮交互等// 按钮中的文字let text = {null: '开始识别', // 最开始状态init: '开始识别', // 初始化状态ing: '结束识别', // 正在录音状态end: '开始识别', // 结束状态}let senconds = 0$('.taste-button').removeClass(`status-${oldStatus}`).addClass(`status-${status}`).text(text[status])if (status === 'ing') {$('hr').addClass('hr')$('.taste-content').css('display', 'none')$('.start-taste').addClass('flex-display-1')// 倒计时相关countInterval = setInterval(()=>{senconds++console.log("==========="+senconds)$('.used-time').text(`0${Math.floor(senconds/60)}：${Math.floor(senconds/10)}${senconds%10}`)/*if (senconds >= 60) {this.stop()clearInterval(countInterval)}*/}, 1000)} else if (status === 'init') {$('.time-box').show()$('.used-time').text('00：00')} else {$('.time-box').hide()$('hr').removeClass('hr')clearInterval(countInterval)}
}$(function () {
// 监听识别结果的变化iatRecorder.onTextChange = function(text) {$('#result_output').text(text)}$('#taste_button, .taste-button').click(function() {if (iatRecorder.status === 'ing') {iatRecorder.stop()} else {iatRecorder.start()}})});

5. 创建 translation.vue 文件，（在语音听写流式API demo js语言讯飞源文件中取 src\pages\index\index.html）

<template><div class="service-item service-item-taste"><h2 class="service-item-title">产品体验-语音听写（流式版）WebAPI</h2><a href="/doc" target="_blank">demo文档说明</a><div class="service-item-content service-item-taste-content"><div class="taste-content"><button class="taste-button ready-button" id="taste_button">开始识别</button></div><div class="start-taste"><div class="start-taste-left"><div class="time-box"><span class="start-taste-line"><hr class="hr hr1"><hr class="hr hr2"><hr class="hr hr3"><hr class="hr hr4"><hr class="hr hr5"><hr class="hr hr6"><hr class="hr hr7"><hr class="hr hr8"><hr class="hr hr9"><hr class="hr hr10"></span><span class="total-time"><span class="used-time">00: 00</span> / 01: 00</span></div><div class="start-taste-button"><button class="taste-button start-button">结束识别</button></div></div><div class="output-box" id="result_output"></div></div></div></div></template>
<script>import translation from './translation.js'export default {name: 'translation',data() {return {phone: '',}},// mixins: [translation],created() {// transWorker// translation.transW},mounted() {},methods: {},destroyed() {},
}</script><style >
.service-item-taste button {cursor: pointer;
}.service-item-taste .taste-button {background: #187cff;border: 1px solid;border-color: #478eea;color: #fff;text-align: center;border-radius: 3px;
}.service-item-taste .taste-header .dialect-select {margin-left: 20px;height: 26px;
}.service-item-taste .taste-header .dialect {margin-left: 20px;height: 26px;line-height: 26px;display: none;
}.service-item-taste .taste-header a {border: none;border-radius: 4px;color: #fff;height: 26px;width: 100px;float: right;text-align: center;line-height: 26px;
}.service-item-taste .taste-content {display: -ms-flexbox;display: flex;-ms-flex-align: center;align-items: center;margin-top: 100px;
}.service-item-taste .start-taste {margin-top: 30px;display: none;-ms-flex-pack: justify;justify-content: space-between;
}
.service-item-taste .start-taste.flex-display-1{display: flex;
}.service-item-taste .start-taste .start-taste-left {width: 40%;margin-left: 30px;
}.service-item-taste .start-taste .start-taste-left .time-box {margin-top: 40px;display: -ms-flexbox;display: flex;-ms-flex-pack: center;justify-content: center;
}.service-item-taste .start-taste .start-taste-left .time-box .total-time {margin-left: 20px;
}.service-item-taste .start-taste .start-taste-left .time-box .start-taste-line {display: inline-block;margin-right: 20px;
}.service-item-taste .start-taste .start-taste-left .time-box .start-taste-line hr {background-color: #187cff;width: 3px;height: 10px;margin: 0 5px;display: inline-block;border: none;
}.service-item-taste .start-taste .start-taste-left .start-taste-button {display: -ms-flexbox;display: flex;margin-top: 70px;
}.service-item-taste .start-taste .output-box {height: 200px;overflow: auto;background: #f0f0f0;width: 50%;line-height: 1.5;padding-left: 10px;padding-top: 10px;
}.hr {animation: note 0.2s ease-in-out;animation-iteration-count: infinite;animation-direction: alternate;
}.hr1 {animation-delay: -1s;
}.hr2 {animation-delay: -0.9s;
}.hr3 {animation-delay: -0.8s;
}.hr4 {animation-delay: -0.7s;
}.hr5 {animation-delay: -0.6s;
}.hr6 {animation-delay: -0.5s;
}.hr7 {animation-delay: -0.4s;
}.hr8 {animation-delay: -0.3s;
}.hr9 {animation-delay: -0.2s;
}.hr10 {animation-delay: -0.1s;
}@keyframes note {from {transform: scaleY(1);}to {transform: scaleY(4);}
}.ready-button,
.start-button {margin: 0 auto;height: 40px;width: 160px;font-size: 16px;letter-spacing: 6px;
}.taste-button:hover {background: #0b99ff;
}
</style>
