本文章介绍微信小程序调用高德地图API的过程,使用高德定位功能做演示。
微信小程序目前支持百度地图、高德地图、腾讯地图。用法可以说是基本完全一样,本文章以高德为例,简单说一下他们的区别,高德地图精度应该是最准确的,毕竟本来就是做地图出生的。百度地图的精度目前较高德而言,还是要稍稍欠缺一点,但是他的附近商家那些要比高德好一点。而关于腾讯地图,暂时来说还是只能表示呵呵,希望越来越好吧。
1.既然本章是介绍微信小程序如何使用高德地图API,那么第一件事肯定是进入高德地图开放平台(https://lbs.amap.com/)。此处需要注册,登录。
2.完成登陆后,进入控制台,在左边侧边栏里点击 应用管理->我的应用-> 创建新应用,会生成一个key,这个key在后面将会用到。记住绑定服务选择 微信小程序
3.登录微信开发者平台,在服务器域名设置里将高德地图的域名设置好
4.在你的项目中新建一个目录libs,将amap-wx.js文件放入此目录里(amap-wx.js下载地址:https://lbs.amap.com/api/wx/download,解压出来会有两个文件,此处只需要一个),结果如下:
5.在libs目录下创建配置文件config.js,写入第二步获取的key,例如
高德api配置到这儿就结束了,以下是我调用高德实现定位的demo
JS部分:
var amapFile = require('../../libs/amap-wx.js'); //引入高德js
var config = require('../../libs/config.js'); //引用我们的配置文件
Page({data: {markers: [],latitude: '',longitude: '',textData: {}},onLoad: function () {var that = this;var key = config.Config.key;var myAmapFun = new amapFile.AMapWX({ key: key });myAmapFun.getRegeo({iconPath: "../../img/marker.png",iconWidth: 22,iconHeight: 32,success: function (data) {console.log(data);var marker = [{id: data[0].id,latitude: data[0].latitude,longitude: data[0].longitude,iconPath: data[0].iconPath,width: data[0].width,height: data[0].height}]that.setData({markers: marker});that.setData({latitude: data[0].latitude});that.setData({longitude: data[0].longitude});that.setData({textData: {name: data[0].name,desc: data[0].desc}})},fail: function (info) {// wx.showModal({title:info.errMsg})}})}
})
WXML部分:
<view class="map_container"><map class="map" id="map" longitude="{{longitude}}" latitude="{{latitude}}" scale="16" markers="{{markers}}"></map>
</view>
<view class="map_text"><text class="h1">{{textData.name}}</text><text>{{textData.desc}}</text>
</view>
WXSS部分:
.map_container{position: absolute;top: 0;bottom: 80px;left: 0;right: 0;
}
.map{width: 100%;height: 100%;
}
.map_text{position: absolute;left: 0;right: 0;bottom: 0px;height: 80px;background: #fff;padding: 0 15px;
}
text{margin: 5px 0;display: block;font-size:12px;
}
.h1{margin: 15px 0;font-size:15px;
}
此页面大概长这样:
PS:
高德地图官方开发指南地址 https://lbs.amap.com/api/wx/guide/create-project/config-project
我的小程序demo地址 https://github.com/Yxiaogg/vioShop(star star star)
