卷积神经网络被大规模的应用在分类任务中，输出的结果是整个图像的类标签。但是UNet是像素级分类，输出的则是每个像素点的类别，且不同类别的像素会显示不同颜色，UNet常常用在生物医学图像上，而该任务中图片数据往往较少。所以，Ciresan等人训练了一个卷积神经网络，用滑动窗口提供像素的周围区域（patch）作为输入来预测每个像素的类标签。这个网络有两个优点：（1）输出结果可以定位出目标类别的位置；（2）由于输入的训练数据是patches，这样就相当于进行了数据增强，从而解决了生物医学图像数量少的问题。

但是，采用该方法的神经网络也有两个很明显的缺点：（1）它很慢，因为这个网络必须训练每个patch，并且因为patch之间的重叠有很多冗余，这样会导致同样特征被多次训练，造成资源的浪费，导致训练时间的加长且效率也会有所降低，也有人会问神经网络经过多次训练这个特征后，会对这个特征的印象加深，从而准确率也会上升，但是举个例子一个图片复制50张，用这50张图片去训练网络，虽说数据集增大了，可是导致的后果是神经网络会出现过拟合，也就是说神经网络对训练图片很熟悉，可是换了一张图片，神经网络就有可能分辨不出来了。（2）定位准确性和获取上下文信息不可兼得，大的patches需要更多的max-pooling，这样会减少定位准确性，因为最大池化会丢失目标像素和周围像素之间的空间关系，而小patches只能看到很小的局部信息，包含的背景信息不够。

UNet主要贡献是在U型结构上，该结构可以使它使用更少的训练图片的同时，且分割的准确度也不会差，UNet的网络结构如下图：

在这里插入图片描述
（1）UNet采用全卷积神经网络。
（2）左边网络为特征提取网络：使用conv和pooling
（3）右边网络为特征融合网络：使用上采样产生的特征图与左侧特征图进行concatenate操作。（pooling层会丢失图像信息和降低图像分辨率且是永久性的，对于图像分割任务有一些影响，对图像分类任务的影响不大，为什么要做上采样呢？上采样可以让包含高级抽象特征低分辨率图片在保留高级抽象特征的同时变为高分辨率，然后再与左边低级表层特征高分辨率图片进行concatenate操作）
（4）最后再经过两次卷积操作，生成特征图，再用两个卷积核大小为1*1的卷积做分类得到最后的两张heatmap，例如第一张表示第一类的得分，第二张表示第二类的得分heatmap，然后作为softmax函数的输入，算出概率比较大的softmax，然后再进行loss，反向传播计算。

Unet模型的代码实现（基于keras）：

def get_unet():inputs = Input((img_rows, img_cols, 1))conv1 = Conv2D(32, (3, 3), activation='relu', padding='same')(inputs)conv1 = Conv2D(32, (3, 3), activation='relu', padding='same')(conv1)pool1 = MaxPooling2D(pool_size=(2, 2))(conv1)# pool1 = Dropout(0.25)(pool1)# pool1 = BatchNormalization()(pool1)conv2 = Conv2D(64, (3, 3), activation='relu', padding='same')(pool1)conv2 = Conv2D(64, (3, 3), activation='relu', padding='same')(conv2)pool2 = MaxPooling2D(pool_size=(2, 2))(conv2)# pool2 = Dropout(0.5)(pool2)# pool2 = BatchNormalization()(pool2)conv3 = Conv2D(128, (3, 3), activation='relu', padding='same')(pool2)conv3 = Conv2D(128, (3, 3), activation='relu', padding='same')(conv3)pool3 = MaxPooling2D(pool_size=(2, 2))(conv3)# pool3 = Dropout(0.5)(pool3)# pool3 = BatchNormalization()(pool3)conv4 = Conv2D(256, (3, 3), activation='relu', padding='same')(pool3)conv4 = Conv2D(256, (3, 3), activation='relu', padding='same')(conv4)pool4 = MaxPooling2D(pool_size=(2, 2))(conv4)# pool4 = Dropout(0.5)(pool4)# pool4 = BatchNormalization()(pool4)conv5 = Conv2D(512, (3, 3), activation='relu', padding='same')(pool4)conv5 = Conv2D(512, (3, 3), activation='relu', padding='same')(conv5)up6 = concatenate([Conv2DTranspose(256, (2, 2), strides=(2, 2), padding='same')(conv5), conv4], axis=3)# up6 = Dropout(0.5)(up6)# up6 = BatchNormalization()(up6)conv6 = Conv2D(256, (3, 3), activation='relu', padding='same')(up6)conv6 = Conv2D(256, (3, 3), activation='relu', padding='same')(conv6)up7 = concatenate([Conv2DTranspose(128, (2, 2), strides=(2, 2), padding='same')(conv6), conv3], axis=3)# up7 = Dropout(0.5)(up7)# up7 = BatchNormalization()(up7)conv7 = Conv2D(128, (3, 3), activation='relu', padding='same')(up7)conv7 = Conv2D(128, (3, 3), activation='relu', padding='same')(conv7)up8 = concatenate([Conv2DTranspose(64, (2, 2), strides=(2, 2), padding='same')(conv7), conv2], axis=3)# up8 = Dropout(0.5)(up8)# up8 = BatchNormalization()(up8)conv8 = Conv2D(64, (3, 3), activation='relu', padding='same')(up8)conv8 = Conv2D(64, (3, 3), activation='relu', padding='same')(conv8)up9 = concatenate([Conv2DTranspose(32, (2, 2), strides=(2, 2), padding='same')(conv8), conv1], axis=3)# up9 = Dropout(0.5)(up9)# up9 = BatchNormalization()(up9)conv9 = Conv2D(32, (3, 3), activation='relu', padding='same')(up9)conv9 = Conv2D(32, (3, 3), activation='relu', padding='same')(conv9)# conv9 = Dropout(0.5)(conv9)conv10 = Conv2D(1, (1, 1), activation='sigmoid')(conv9)model = Model(inputs=[inputs], outputs=[conv10])model.compile(optimizer=Adam(lr=1e-5),loss=dice_coef_loss, metrics=[dice_coef])return model

Unet的代码实现（pytorch版）

"""
这是根据UNet模型搭建出的一个基本网络结构
输入和输出大小是一样的，可以根据需求进行修改
"""
import torch
import torch.nn as nn
from torch.nn import functional as F# 基本卷积块
class Conv(nn.Module):def __init__(self, C_in, C_out):super(Conv, self).__init__()self.layer = nn.Sequential(nn.Conv2d(C_in, C_out, 3, 1, 1),nn.BatchNorm2d(C_out),# 防止过拟合nn.Dropout(0.3),nn.LeakyReLU(),nn.Conv2d(C_out, C_out, 3, 1, 1),nn.BatchNorm2d(C_out),# 防止过拟合nn.Dropout(0.4),nn.LeakyReLU(),)def forward(self, x):return self.layer(x)# 下采样模块
class DownSampling(nn.Module):def __init__(self, C):super(DownSampling, self).__init__()self.Down = nn.Sequential(# 使用卷积进行2倍的下采样，通道数不变nn.Conv2d(C, C, 3, 2, 1),nn.LeakyReLU())def forward(self, x):return self.Down(x)# 上采样模块
class UpSampling(nn.Module):def __init__(self, C):super(UpSampling, self).__init__()# 特征图大小扩大2倍，通道数减半self.Up = nn.Conv2d(C, C // 2, 1, 1)def forward(self, x, r):# 使用邻近插值进行下采样up = F.interpolate(x, scale_factor=2, mode="nearest")x = self.Up(up)# 拼接，当前上采样的，和之前下采样过程中的return torch.cat((x, r), 1)# 主干网络
class UNet(nn.Module):def __init__(self):super(UNet, self).__init__()# 4次下采样self.C1 = Conv(3, 64)self.D1 = DownSampling(64)self.C2 = Conv(64, 128)self.D2 = DownSampling(128)self.C3 = Conv(128, 256)self.D3 = DownSampling(256)self.C4 = Conv(256, 512)self.D4 = DownSampling(512)self.C5 = Conv(512, 1024)# 4次上采样self.U1 = UpSampling(1024)self.C6 = Conv(1024, 512)self.U2 = UpSampling(512)self.C7 = Conv(512, 256)self.U3 = UpSampling(256)self.C8 = Conv(256, 128)self.U4 = UpSampling(128)self.C9 = Conv(128, 64)self.Th = torch.nn.Sigmoid()self.pred = torch.nn.Conv2d(64, 3, 3, 1, 1)def forward(self, x):# 下采样部分R1 = self.C1(x)R2 = self.C2(self.D1(R1))R3 = self.C3(self.D2(R2))R4 = self.C4(self.D3(R3))Y1 = self.C5(self.D4(R4))# 上采样部分# 上采样的时候需要拼接起来O1 = self.C6(self.U1(Y1, R4))O2 = self.C7(self.U2(O1, R3))O3 = self.C8(self.U3(O2, R2))O4 = self.C9(self.U4(O3, R1))# 输出预测，这里大小跟输入是一致的# 可以把下采样时的中间抠出来再进行拼接，这样修改后输出就会更小return self.Th(self.pred(O4))if __name__ == '__main__':a = torch.randn(2, 3, 256, 256)net = UNet()print(net(a).shape)

Unet的代码实现（TensorFlow版）

# -*-coding: utf-8 -*-
