GridView概述

article/2025/9/10 8:34:20

一、使用GridView以表格形式显示多张图片
GridView用于在界面上按行、列分布的方式来显示多个组件

二、使用GridView
1、java代码

import android.support.v7.app.AppCompatActivity;
import android.os.Bundle;
import android.view.View;
import android.widget.AdapterView;
import android.widget.GridView;
import android.widget.SimpleAdapter;
import android.widget.Toast;import java.util.ArrayList;
import java.util.HashMap;
import java.util.List;
import java.util.Map;public class MainActivity extends AppCompatActivity implements AdapterView.OnItemClickListener{private GridView gridView;private List<Map<String,Object>>dataList;private int[]icon = {R.drawable.calendar,R.drawable.address_book,R.drawable.camera,R.drawable.clock,R.drawable.games_control,R.drawable.messenger,R.drawable.settings};private String[]iconName = {"日历","电话簿","照相机","闹钟","游戏控制","信息","设置"};private SimpleAdapter adapter;@Overrideprotected void onCreate(Bundle savedInstanceState) {super.onCreate(savedInstanceState);setContentView(R.layout.main);gridView = (GridView) findViewById(R.id.gridView);//1、准备数据源//2、新建适配器（SimpleAdapter）//3、GridView加载适配器//4、GridView配置事件监听器（OnItemClickListener）//新建数据源的集合dataList = new ArrayList<Map<String,Object>>();//getData();//新建适配器adapter = new SimpleAdapter(this,getData(),R.layout.item,new String[]{"image","text"},new int[]{R.id.image,R.id.text});//加载适配器gridView.setAdapter(adapter);//加载监听器gridView.setOnItemClickListener(this);}public List<Map<String,Object>> getData() {//填充数据源for(int i=0;i<icon.length;i++) {Map<String, Object> map = new HashMap<String, Object>();map.put("image",icon[i]);map.put("text",iconName[i]);dataList.add(map);}return dataList;}@Overridepublic void onItemClick(AdapterView<?> adapterView, View view, int i, long l) {Toast.makeText(this,"我是"+iconName[i],Toast.LENGTH_SHORT).show();}
}

2、xml文件

<?xml version="1.0" encoding="utf-8"?>
<LinearLayout xmlns:android="http://schemas.android.com/apk/res/android"android:layout_width="match_parent"android:layout_height="match_parent"android:orientation="vertical"android:gravity="center"android:background="#000000"><ImageView
        android:src="@drawable/ic_launcher"android:layout_width="60dp"android:layout_height="60dp"android:id="@+id/image"/><TextView
        android:layout_marginTop="5dp"android:layout_width="wrap_content"android:layout_height="wrap_content"android:textColor="#ffffff"android:text="文字"android:id="@+id/text"/>
</LinearLayout>

   <!--android:numColumns="" 每一行显示多少列android:horizontalSpacing="" 两列之间的间距android:verticalSpacing="" 两行之间的间距--><GridView
        android:layout_marginTop="10dp"android:id="@+id/gridView"android:layout_width="wrap_content"android:layout_height="wrap_content"android:numColumns="3"android:horizontalSpacing="10dp"android:verticalSpacing="10dp"></GridView>
