前言

对于生在智能时代的我们，对关机和重启这两个概念肯定不会陌生，尤其经历早期Android智能机的人们，印象最深恐怕就是重启，当然现在不会了，还没有改过来的都被淘汰了。在Linux系统中我们使用reboot完成这个动作,下面以rk px30 linux4.4.194为例，分析这个过程。

应用层

重启reboot基本上都是通过一条命令实现，之所以聊一下应用层，主要是新的系统中reboot shutdown halt 等，这些操作被systemd统一管理了，也就是说reboot，shutdown，halt等命令是指向systemctl的软链接，执行reboot相当于执行 systemctl reboot,systemctl reboot 会切换到 reboot.target.

下面使用systemd进行系统关闭/重启的依赖关系图：

                                  (conflicts with  (conflicts withall system     all file systemservices)     mounts, swaps,|           cryptsetup|          devices, ...)|                |v                vshutdown.target    umount.target|                |\_______   ______/\ /v(various low-levelservices)|vfinal.target|_____________________________________/ \_________________________________/                         |                        |                      \|                         |                        |                      |v                         v                        v                      v
systemd-reboot.service   systemd-poweroff.service   systemd-halt.service   systemd-kexec.service|                         |                        |                      |v                         v                        v                      vreboot.target             poweroff.target            halt.target           kexec.target

下面是reboot的service

#  SPDX-License-Identifier: LGPL-2.1+
#
#  This file is part of systemd.
#
#  systemd is free software; you can redistribute it and/or modify it
#  under the terms of the GNU Lesser General Public License as published by
#  the Free Software Foundation; either version 2.1 of the License, or
#  (at your option) any later version.[Unit]
Description=Reboot
Documentation=man:systemd-halt.service(8)
DefaultDependencies=no
Requires=shutdown.target umount.target final.target
After=shutdown.target umount.target final.target
SuccessAction=reboot-force

conflicts with all system services：指那些定义了Conflicts=shutdown.target 和 Before=shutdown.target 依赖关系（除非明确设置了 DefaultDependencies=no ，否则 service 单元将会自动添加这些依赖）的服务，这些服务在shutdown.target运行之前会停止。

实际执行过程从上到下，以reboot为例：

1.停止和shutdown.target、umount.target冲突的服务。

2.shutdown.target、umount.target

3.various low-level services

4.final.target

5.systemd-reboot.service
该服务执行的命令行：ExecStart=/bin/systemctl --force reboot，这条命令会调用systemd-shutdown，它将以简单而强大的方式卸载任何剩余的文件系统，杀死任何剩余的进程并释放任何其他剩余的资源，而不再考虑任何服务或单元概念。一般这是最后执行的服务。

6.reboot.target

目标单元的功能仅仅是通过依赖关系将一组单元汇聚在一起，形成一个同步点，并给这个同步点取一个众所周知的名称，以便用作启动目标或其他单元的依赖。对于shutdown.target、umount.target、final.target、reboot.target这些目标单元，其组内的单元（.wants/、.requires/）实际的启动顺序取决于单元自身的依赖关系。
最后通过系统调用，通过内核完成相关操作。

kernel

如下为reboot的系统调用代码kernel/reboot.c：

/** Reboot system call: for obvious reasons only root may call it,* and even root needs to set up some magic numbers in the registers* so that some mistake won't make this reboot the whole machine.* You can also set the meaning of the ctrl-alt-del-key here.** reboot doesn't sync: do that yourself before calling this.*/
SYSCALL_DEFINE4(reboot, int, magic1, int, magic2, unsigned int, cmd,void __user *, arg)
{struct pid_namespace *pid_ns = task_active_pid_ns(current);char buffer[256];int ret = 0;#检测权限/* We only trust the superuser with rebooting the system. */if (!ns_capable(pid_ns->user_ns, CAP_SYS_BOOT))return -EPERM;//加入一些验证，防止误操作/* For safety, we require "magic" arguments. */if (magic1 != LINUX_REBOOT_MAGIC1 ||(magic2 != LINUX_REBOOT_MAGIC2 &&magic2 != LINUX_REBOOT_MAGIC2A &&magic2 != LINUX_REBOOT_MAGIC2B &&magic2 != LINUX_REBOOT_MAGIC2C))return -EINVAL;//调用reboot_pid_ns接口，检查是否需要由该接口处理reboot请求。这是一个有关pid namespaces的新特性，也是Linux内核重要的知识点/** If pid namespaces are enabled and the current task is in a child* pid_namespace, the command is handled by reboot_pid_ns() which will* call do_exit().*/ret = reboot_pid_ns(pid_ns, cmd);if (ret)return ret;//如果是POWER_OFF命令，且没有注册power off的machine处理函数（pm_power_off），把该命令转换为HALT命令；/* Instead of trying to make the power_off code look like* halt when pm_power_off is not set do it the easy way.*/if ((cmd == LINUX_REBOOT_CMD_POWER_OFF) && !pm_power_off)cmd = LINUX_REBOOT_CMD_HALT;mutex_lock(&reboot_mutex);switch (cmd) {case LINUX_REBOOT_CMD_RESTART:kernel_restart(NULL);break;/*省略不相干代码*/default:ret = -EINVAL;break;}mutex_unlock(&reboot_mutex);return ret;
}

1、内核根据不同的表现形式把重启分为下面几类：

/** Commands accepted by the _reboot() system call.** RESTART     Restart system using default command and mode.* HALT        Stop OS and give system control to ROM monitor, if any.* CAD_ON      Ctrl-Alt-Del sequence causes RESTART command.* CAD_OFF     Ctrl-Alt-Del sequence sends SIGINT to init task.* POWER_OFF   Stop OS and remove all power from system, if possible.* RESTART2    Restart system using given command string.* SW_SUSPEND  Suspend system using software suspend if compiled in.* KEXEC       Restart system using a previously loaded Linux kernel*/#define LINUX_REBOOT_CMD_RESTART        0x01234567
#define LINUX_REBOOT_CMD_HALT           0xCDEF0123
#define LINUX_REBOOT_CMD_CAD_ON         0x89ABCDEF
#define LINUX_REBOOT_CMD_CAD_OFF        0x00000000
#define LINUX_REBOOT_CMD_POWER_OFF      0x4321FEDC
#define LINUX_REBOOT_CMD_RESTART2       0xA1B2C3D4
#define LINUX_REBOOT_CMD_SW_SUSPEND     0xD000FCE2
#define LINUX_REBOOT_CMD_KEXEC          0x45584543

RESTART，正常的重启，也是我们平时使用的重启。执行该动作后，系统会重新启动。

HALT，停止操作系统，然后把控制权交给其它代码（如果有的话）。具体的表现形式，依赖于系统的具体实现。

CAD_ON/CAD_OFF，允许/禁止通过Ctrl-Alt-Del组合按键触发重启（RESTART）动作。
注1：Ctrl-Alt-Del组合按键的响应是由具体的Driver（如Keypad）实现的。

POWER_OFF，正常的关机。执行该动作后，系统会停止操作系统，并去除所有的供电。

RESTART2，重启的另一种方式。可以在重启时，携带一个字符串类型的cmd，该cmd会在重启前，发送给任意一个关心重启事件的进程，同时会传递给最终执行重启动作的machine相关的代码。内核并没有规定该cmd的形式，完全由具体的machine自行定义。

SW_SUSPEND，即前一篇文章中描述的Hibernate操作。

KEXEC，重启并执行已经加载好的其它Kernel Image（需要CONFIG_KEXEC的支持），暂不涉及。

上面已经注释过一些，下面我们重点看一下 LINUX_REBOOT_CMD_RESTART 命令的处理函数kernel_restart

/***	kernel_restart - reboot the system*	@cmd: pointer to buffer containing command to execute for restart*		or %NULL**	Shutdown everything and perform a clean reboot.*	This is not safe to call in interrupt context.*/
void kernel_restart(char *cmd)
{kernel_restart_prepare(cmd);migrate_to_reboot_cpu();syscore_shutdown();if (!cmd)pr_emerg("Restarting system\n");elsepr_emerg("Restarting system with command '%s'\n", cmd);kmsg_dump(KMSG_DUMP_RESTART);machine_restart(cmd);
}

kernel_restart_prepare

void kernel_restart_prepare(char *cmd)
{blocking_notifier_call_chain(&reboot_notifier_list, SYS_RESTART, cmd);system_state = SYSTEM_RESTART;usermodehelper_disable();device_shutdown();
}

进行restart/halt/power_off前的准备工作，包括，
      调用blocking_notifier_call_chain接口，向关心reboot事件的进程，发送SYS_RESTART将cmd参数一并发送出去。驱动需要关注该事件需要调用register_reboot_notifier注册，
      将系统状态设置为相应的状态（SYS_RESTART）。
      调用usermodehelper_disable接口，禁止User mode helper。
      调用device_shutdown，关闭所有的设备

migrate_to_reboot_cpu

void migrate_to_reboot_cpu(void)
{/* The boot cpu is always logical cpu 0 */int cpu = reboot_cpu;cpu_hotplug_disable();/* Make certain the cpu I'm about to reboot on is online */if (!cpu_online(cpu))cpu = cpumask_first(cpu_online_mask);/* Prevent races with other tasks migrating this task */current->flags |= PF_NO_SETAFFINITY;/* Make certain I only run on the appropriate processor */set_cpus_allowed_ptr(current, cpumask_of(cpu));
}

该函数主要是把当前调用重启接口的任务，绑定到固定的一个CPU上，通常为当前online的序号排第一的CPU。此处不用纠结为什么绑定到第一个online的而不是第二个第三个，主要原因一是为了简单，二是防止在重启时再有什么任务迁移。

syscore_shutdown

/*** syscore_shutdown - Execute all the registered system core shutdown callbacks.*/
void syscore_shutdown(void)
{struct syscore_ops *ops;mutex_lock(&syscore_ops_lock);list_for_each_entry_reverse(ops, &syscore_ops_list, node)if (ops->shutdown) {if (initcall_debug)pr_info("PM: Calling %pF\n", ops->shutdown);ops->shutdown();}mutex_unlock(&syscore_ops_lock);
}

回调所有注册syscore shutdown回调的回调函数，通常注册syscore的回调有3个：suspend\resume\shutdown，其中suspend和resume在低功耗流程中调用，shutdown则在此处调用。

machine_restart

/** Restart requires that the secondary CPUs stop performing any activity* while the primary CPU resets the system. Systems with multiple CPUs must* provide a HW restart implementation, to ensure that all CPUs reset at once.* This is required so that any code running after reset on the primary CPU* doesn't have to co-ordinate with other CPUs to ensure they aren't still* executing pre-reset code, and using RAM that the primary CPU's code wishes* to use. Implementing such co-ordination would be essentially impossible.*/
void machine_restart(char *cmd)
{/* Disable interrupts first */local_irq_disable();smp_send_stop();do_kernel_i2c_restart(cmd);/** UpdateCapsule() depends on the system being reset via* ResetSystem().*/if (efi_enabled(EFI_RUNTIME_SERVICES))efi_reboot(reboot_mode, NULL);/* Now call the architecture specific reboot code. */if (arm_pm_restart)arm_pm_restart(reboot_mode, cmd);elsedo_kernel_restart(cmd);/** Whoops - the architecture was unable to reboot.*/printk("Reboot failed -- System halted\n");while (1);
}

复位cpu会通过smp_send_stop接口把其他cpu停下来，接着调用复位命令，看一下这个do_kernel_restart，也是回调函数列表，主要处理通过register_restart_handler注册到register_restart_handler的设备，其中比较关键的clk函数下面贴出来看一下

static int rockchip_restart_notify(struct notifier_block *this,unsigned long mode, void *cmd)
{if (cb_restart)cb_restart();writel(0xfdb9, rst_base + reg_restart);return NOTIFY_DONE;
}

参考一下px30的datasheet《2.3 System Reset Solution》
