介绍
这几天在编写一个数据驱动测试框架,其中一个核心模块是根据数据输入,自动转换为测试用例代码。测试数据格式固定,对应的用例代码结构也相对稳定。基于此场景,联想到web页面根据数据从template渲染页面,决定使用类似的方式,采用模版库动态生成测试用例代码。
Python库有两个常用的模版库:Jinja2和Mako。两个库功能都很齐全强大,Jinja2广泛用于各种语言环境如Java/Go,Mako主要用于Python语言环境。
Mako模板从一个包含各种类型的内容的文本流解析得到,包括XML、HTML、email文本等。模板还可以包含Mako指令,用来表示变量和表达式替换、控制结构、服务器端注释、整块Python代码,还有用来提供额外功能的各种标签。所有这些结构都被编译为实际的Python代码。
Mako能直接嵌套Python代码,更贴近python代码风格,项目使用的也是python语言环境,使用起来更加方便,网上也有说mako库解析速度更快,我们最终选择了mako库。
使用方式
下面总结一下mako使用方式。
使用Template
通过from mako.template import Template引入mako模板。
1)基本用法
from mako.template import Template
t = Template("Hello,${name}")
print(t.render(name = 'world'))
输出:
Hello,world
2)导入模版文件
Template函数还有一些常用的参数:
- filename:指定从文件中加载模板。最好用相对路径,否则缓存文件会包含在很长的路径下
- module_directory:缓存目录。从文件中加载模板,可以指定module_directory生成.py文件缓存,提高加载速度。
例如:
新建一个模版文件demo.tmpl,保存以下内容:
Hello,${name}
使用模版代码:
from mako.template import Template
t = Template(filename="demo.tmpl", module_directory="./")
print(t.render(name='world'))
代码执行以后,当前目录下会生成一个以模版文件名,再加上后缀“.py”的缓存文件。
rend()方法会创建一个Context对象,该对象会存储所有render()方法传递给模版的变量,并且会保存为buffer用于捕获output输出。
我们也可以自定义Context对象,然后用 render_context()方法渲染。
from mako.template import Template
from mako.runtime import Context
from io import StringIOmytemplate = Template("hello, ${name}")
buf = StringIO()
ctx = Context(buf, name="python")
mytemplate.render_context(ctx)
print(buf.getvalue())
使用TemplateLookup
实际项目中,通常会有多个模版文件,组合渲染一个页面。这种情况下,我们可以使用TemplateLookup,直接从指定的目录导入多个模版文件。
from mako.lookup import TemplateLookuplookup = TemplateLookup(directories=['./templates'], module_directory='./', collection_size=500, filesystem_checks=True)
"""
# 使用templateLookup,可以方便的设置模板目录,当模板中include别的模板时可以只写模板名
# collection_size设置加载到内存中的模板上限
# filesystem_checks为True会在每次加载模板缓存判断模板文件是否有改动,会重新编译。
"""
def serve_template(templatename, **kwargs):mytemplate = lookup.get_template(templatename) #get_template()方法根据文件名,获取指定的templateprint(mytemplate.render(**kwargs))serve_template("index.html", name="python")
异常处理
异常主要出现在查找并解析模版文件,以及渲染模版两个场合。渲染阶段的异常主要是python自带的异常。mako封装了异常类处理模版解析过程中的异常堆栈,将堆栈数据格式输出化为text或者html格式。
text_error_template() 输出text格式异常堆栈;html_error_template() 输出html格式异常堆栈。这两个方法本质上都是调用sys.exc_info()获取程序最近抛出的异常。
- text模版异常
from mako import exceptions
try:template = lookup.get_template(uri)print(template.render())
except:print(exceptions.text_error_template().render())
- html格式模版异常
from mako import exceptionstry:template = lookup.get_template(uri)print(template.render())
except:print(exceptions.html_error_template().render())
- 自定义异常:
exceptions类底层使用的RichTraceback对象。该对象也可以用来自定义异常。
from mako.exceptions import RichTracebacktry:template = lookup.get_template(uri)print(template.render())
except:traceback = RichTraceback()for (filename, lineno, function, line) in traceback.traceback:print("File %s, line %s, in %s" % (filename, lineno, function))print(line, "\n")print("%s: %s" % (str(traceback.error.__class__.__name__), traceback.error
语法
表达式替换
- 最简单的表达式是变量替换。语法为 ${var}
Hello, this is my name: ${var}
上面的例子会把 var 的字符串表示输出到模板的输出流。 var通常来自于传递给模板渲染函数的 Context 。如果没有传入x 给模板,并且也没有本地赋值,那么就等于一个特殊的值 UNDEFINED 。
例如,模版文件demo.tmpl包含以下内容:
Hello, this is my name: ${name}
print(${version})
但是render()方法没有传递version参数时,会抛出异常“NameError: Undefined”
from mako.template import Template
t = Template(filename="./templates/demo.tmpl", module_directory="./")
print(t.render(name='world'))
运行结果:
Traceback (most recent call last):File "/Users/bruce.xu/mako/basic_usage.py", line 19, in <module>print(t.render(name='world'))File "/Library/Frameworks/Python.framework/Versions/3.6/lib/python3.6/site-packages/mako/template.py", line 476, in renderreturn runtime._render(self, self.callable_, args, data)File "/Library/Frameworks/Python.framework/Versions/3.6/lib/python3.6/site-packages/mako/runtime.py", line 883, in _render**_kwargs_for_callable(callable_, data)File "/Library/Frameworks/Python.framework/Versions/3.6/lib/python3.6/site-packages/mako/runtime.py", line 920, in _render_context_exec_template(inherit, lclcontext, args=args, kwargs=kwargs)File "/Library/Frameworks/Python.framework/Versions/3.6/lib/python3.6/site-packages/mako/runtime.py", line 947, in _exec_templatecallable_(context, *args, **kwargs)File "/Users/bruce.xu/mako/templates/demo.tmpl.py", line 26, in render_body__M_writer(str(version))File "/Library/Frameworks/Python.framework/Versions/3.6/lib/python3.6/site-packages/mako/runtime.py", line 230, in __str__raise NameError("Undefined")
NameError: Undefined
- ${} 标签中的内容由Python直接计算,因此也可以使用完整的表达式。
Hello, sum is: ${a + b}
输出结果:
Hello, sum is: 3
表达式转义/过滤器
Mako有一组内建的转义机制,包括HTML、URI和XML转义,还有空白截断函数。
-
可以用 | 操作添加到表达式替换
${“this is some text” | u}
上面将URL转义应用到表达式上,生成 this+is+some+text 。 u 表示URL转义, h 表示HTML转义, x 表示XML转义, trim 为空白截断函数。
更多有关内建的过滤函数,包括如何编写自己的过滤函数,见 Filtering and Buffering 。 -
可以用逗号分割,使用多个转义
${" some value " | h,trim}
转义后输出:
<tag>some value</tag>
- 自定义转义
实际上就是自定义一个python函数,实现filter。
例如,自定义python代码块
<%!def myescape(text):return "<TAG>" + text + "</TAG>"
%>
Here's some tagged text: ${"text" | myescape}
输出:
Here's some tagged text: <TAG>text</TAG>
也可以从python代码中直接导入filter:
<%!import myfilters
%>
Here's some tagged text: ${"text" | myfilters.tagfilter}
页面可以通过expression_filter参数设置默认过滤器
<%page expression_filter="h"/>
Escaped text: ${"<html>some html</html>"}
Template和TemplateLookup可以通过default_filters参数指定默认过滤器。
t = TemplateLookup(directories=['/tmp'], default_filters=['unicode'])
也可以通过imports参数导入自定义的过滤器
t = TemplateLookup(directories=['/tmp'],default_filters=['unicode', 'myfilter'],imports=['from mypackage import myfilter'])
过滤器也可以用在defs和blocks上
<%def name="foo()" filter="h, trim"><b>this is bold</b>
</%def>
缓存buffering
缓冲区存储在 Context 中,通过 context.write() 方法可以写缓冲区。通常你不需要关注此方法,因为模板中的文本和 ${} 形式的表达式,都会自动将输出提交到该方法。只有在下列几个应用场景下你才可能需要用到它:1. 处理各种过滤/缓冲(详见 Filtering and Buffering),2. 用编程的方式将内容发送到输出流,比如在一个 <% %> 块中。
<%
context.write(“some programmatic text”)
%>
实际的缓冲区可能不是原来发送给 Context 对象的那个,因为在各种过滤/缓存的场景下,可能会 “push” 一个新的缓冲区到 context 内部的缓冲区栈上。正因为此,只要我们记住始终调用 context.write() 方法,就可以确保内容被发送到顶层的缓冲区。
Mako模版设计目的之一更快的执行效率。为了实现这个目标,template中的文本内容默认会直接通过管道pipe保存到Context对象的buffer缓冲区。这种设计,也带来一些副作用。其中之一,自定义defs函数之后,在模版中使用${somedef()}函数,该函数将会按照它在整个模版文件中首次定义的顺序显示。
例如:
<%def name="func()">func_data
</%def>
${"the result is:" + func()}
输出:
func_data
the result is:
为了避免这种问题,我们可以在def定义时设置buffered=“True”
<%def name="func()" buffered="True">func_data
</%def>${"the result is:" + func()}
输出:
the result is:func_data
以上定义等同于以下代码:
def func():context.push_buffer()try:context.write("func_data")finally:buf = context.pop_buffer()return buf.getvalue()
针对这种场景,我们也可以使用capture()功能。和buffer不同的是,capture在函数被调用时才执行。
<%def name="func()">func_data
</%def>${"the result is:" + capture(func)}
控制结构
控制结构用来控制程序流——条件(即 if/else )、循环(如 while 和 for )、还有 try/except 等。
- Mako中,控制结构写成 % 标记后面跟正常的Python控制表达式,用 % 加标签 end 结束, 为表达式的关键词。
需要注意的是:控制结构中,可以采用python方式直接通过变量名获取相应的值,不能采用普通文本${var}的方式。
例如,模版文件包含以下内容:
% if x==5:this is some output
% endif
执行render():
from mako.template import Template
t = Template(filename="./templates/demo.tmpl", module_directory="./")
print(t.render(x=5))
输出:
this is some output
- % 可以放在前面没有文本的行的任何地方,并且缩进是不敏感的。Python所有的“冒号”表达式都可以使用,包括if/elif/else 、 while 、 for ,甚至是 def ,不过对 def Mako有更好的内建标签。
% for a in ['one', 'two', 'three', 'four', 'five']:% if a[0] == 't':its two or three% elif a[0] == 'f':four/five% else:one% endif
% endfor
- % 符号也可以被转义,如果你想在行首使用百分比符号,可以用 %% 来转义:
%% some text%% some more text
上下文变量
Context 是模板被第一次执行前创建的一个核心对象,它负责和模板外部做所有的交互。它由两个主要的组件组成,
- 输出缓冲区,这是一个类似文件的对象,比如 Python 的 StringIO;
- 变量字典,其中的所有变量均可在模板中自由引用,该字典是由传递给 template.rener() 方法的参数,以及一些由 Mako 运行时环境提供的内建变量组成。
Context 的主要成员包括:
● context[key] / context.get(key, default=None) - 类似字典方式的访问器。通常你在模板中使用的变量,如果在局部没有定义,则会去上下文中获取。当你要使用一个在别处已经定义的(比如传递给 %def 调用的局部参数)变量时,可以用字典访问语法或 get 方法。如果没有提供 key, 则和字典类似,会引发 KeyError.
● keys() - 上下文中已定义的所有名称。
● kwargs - 这会返回一个上下文变量字典的副本。当你想把当前上下文中的变量传递到函数的关键字参数时,这样做很有用。例如:
${next.body(**context.kwargs)}
● write(text) - 向当前输出流中写一些文本。
● lookup - 返回当前执行中用于所有文件查找请求的 TemplateLookup 对象(尽管每个独立的 Template 实例可以有其不同的 TemplateLookup 实例,但只有最初调用到的那个 Template 的 TemplateLookup 会被使用)。
- 通过context[key] / context.get(key, default=None)可以获取变量val对应的值
例如,定义了模版文件
% for key in context.keys():
The key is <tt>${key}</tt>, the value is ${str(context.get(key))}. <br />
% endfor
使用render()传入参数
from mako.template import Template
t = Template(filename="./templates/demo.tmpl", module_directory="./")
print(t.render(a=5, b=4))
输出:
The key is <tt>a</tt>, the value is 5. <br />
The key is <tt>b</tt>, the value is 4. <br />
The key is <tt>capture</tt>, the value is functools.partial(<function capture at 0x105e30ea0>, <mako.runtime.Context object at 0x105e352b0>). <br />
The key is <tt>caller</tt>, the value is [None]. <br />
The key is <tt>self</tt>, the value is <mako.runtime.TemplateNamespace object at 0x105e352e8>. <br />
The key is <tt>local</tt>, the value is <mako.runtime.TemplateNamespace object at 0x105e352e8>. <br />
- render传递参数attributes={}。可以在模版文件中通过attributes字典赋值的方式,动态增加全局变量。
当模板被编译为 python 模块时,其页面内容被包含在 render_body 这个函数中。其他顶层的 defs, 会在其各自独立的函数中定义,函数名被附加了一个前缀 “render_”(比如 render_mydef)。在这些函数中,所有在本地没有定义的变量(比如通过赋值或模块导入的方式定义的),都会从 Context 对象的变量字典中提取。
● 如果引用当前上下文中不存在的变量会怎么样? - 你取得的值将是一个特殊的值 UNDEFINED. 它是 mako.runtime.Undefined 类的一个全局变量。UNDEFINED 对象会在你尝试调用 str() 时抛出错误。这会在尝试在表达式中使用它的时候发生。
● 为什么不直接返回 None 呢? UNDEFINED 更明确,可以和人为传递到 Context 中的 None 加以区分,以及和没有提供值的变量区分开来。
● 为什么对它调用 str() 时会引发异常,而不是返回空字符串呢? - Mako 一直在努力遵循 python 的哲学 “明确胜于隐晦”(explicit is better than implicit). 具体来说,模板作者应该处理值丢失的情况,而不是默默的任由其出错。因为 UNDEFINED 和 python 的 True 或 False 一样,是个单件(Singleton) 对象,你可以用 is 运算符来检查它:
% if someval is UNDEFINED:someval is: no value
% else:someval is: ${someval}
% endif
另一个值得注意的方面是,Context 的变量字典是不可变的。当然,因为是纯 python 的方式,你可以修改 context 的变量字典中的变量,但这恐怕不会如你想像。原因是,Mako 会在很多情况下会创建 Context 对象的副本,并将这些副本传递给模板中的各种元素,以及执行过程中可能用到的子模板。所以,修改本地 Context 中的值,不一定会在模板的其他部分生效。Mako 创建 Context 副本的一个例子是,在模板体中进行对顶层 def 的调用(context 被用于传递局部变量到 def 的范围中;因为在模板体内,他们以内联函数的形式出现,Mako 会尝试让他们用这种方式工作)。另一个例子是在继承链中(在链中的每个模板都有其不同的 parent 和 next,而这两个变量就保存在各自唯一的 Context 对象中)。
● 那么,我们如何设定相对于一个模板请求过程的全局变量呢? - 只要在模板初次运行时给 Context 提供一个字典即可,然后所有的地方就都可以向该字典中 get/set 变量了。比如叫做 attributes:
<%attributes['foo'] = 'bar'
%>
'foo' attribute is: ${attributes['foo']}
render()代码:
from mako.template import Template
t = Template(filename="./templates/demo.tmpl", module_directory="./")
print(t.render(attributes={}))
输出:
'foo' attribute is: bar
循环上下文
- loop.index 提供循环上下文的索引信息:
<ul>
% for a in ("one", "two", "three"):<li>Item ${loop.index}: ${a}</li>
% endfor
</ul>
输出:
<ul><li>Item 0: one</li><li>Item 1: two</li><li>Item 2: three</li>
</ul>
- loop.cycle同时遍历多个迭代对象
<ul>
% for item in ('spam', 'ham', 'eggs'):<li class="${loop.cycle('even', 'odd')}">${item}</li>
% endfor
</ul>
输出:
<ul><li class="even">spam</li><li class="odd">ham</li><li class="even">eggs</li>
</ul>
- loop.parent获取嵌套循环父循环上下文
例如:
<table>
% for consonant in 'pbj':<tr>% for vowel in 'iou':<td class="${'black' if (loop.parent.even == loop.even) else 'red'}">${consonant + vowel}t</td>% endfor</tr>
% endfor
</table>
输出:
<table><tr><td class="black">pit</td><td class="red">pot</td><td class="black">put</td></tr><tr><td class="red">bit</td><td class="black">bot</td><td class="red">but</td></tr><tr><td class="black">jit</td><td class="red">jot</td><td class="black">jut</td></tr>
</table>
其他内建属性
- local - 当前模板的名称空间, described in Built-in Namespaces
- self - 继承链顶层模板的名称空间 (如果有的话,没有则和 local 一样), mostly described in Inheritance
- parent - 继承链中父模板的名称空间(或者未定义); see Inheritance
- next - 继承链中下一个模板的名称空间(或未定义); see Inheritance
- caller - 当使用 <%call> 标签定义一个“带内容的调用”时创建的一个“迷你”名称空间。 described in Calling a def with embedded content and/or other defs
- capture - 一个函数,用于调用指定的 def 并捕获其输出内容,返回为字符串。 Usage is described in Buffering
- UNDEFINED - 一个全局的单件对象,用于在 Context 中找不到的变量的返回值。是 mako.runtime.Undefined 类的实例,调用其 str() 方法会引发异常。
- pageargs - 在没有在 <%page> 标签中定义任何关键字参数的模板中有效,是一个字典。所有传递给模板 body() 函数(当通过名称空间使用时)的关键字参数,都会被收集到这个字典中,其他则被定义为页面参数。(如果已经预先声明)。[原文:All keyword arguments sent to the body() function of a template (when used via namespaces) go here by default unless otherwise defined as a page argument.] If this makes no sense, it shouldn’t; read the section The “body()” method.
注释
有两种形式的注释。
- 单行注释在行首使用 ## :
##this is a comment.
…text … - 多行注释通过 <%doc> …text… </%doc> :
<%doc>
these are comments
more comments
</%doc> - 注意:若模板中存在中文应指点个编码,使用## coding=utf-8
python代码块
- 可以用 <% %> 标签引入任意Python代码块
在 <% %> 里面,可以写普通的Python代码块。代码的整体缩进不受限制,Mako编译器会根据生成的Python代码进行调节。
this is a template
<%x = db.get_resource('foo')y = [z.element for z in x if x.frobnizzle==5]
%>
% for elem in y:element: ${elem}
% endfor
- 用 <%! %> 表示模块级的块。
标签中的代码在模板的模块级别执行,而不是在模板的渲染函数中。因此,这些代码不能访问模板的上下文,并且只能在模板加载到内存时执行(一般每个应用一次,取决于运行环境)。使用 <%! %> 标签来声明模板的导入和纯Python函数:
<%!import mylibimport redef filter(text):return re.sub(r'^@', '', text)
%>
标签
Mako提供的其他东西以标签的形式出现。所有标签使用相同的语法,和XML标签类似,但是在标签名之前加上了 %字符。标签结束方式和XML类似:
<%include file="foo.txt"/>
<%def name="foo" buffered="True">this is a def
</%def>
每个标签都有一组属性。有些属性是必需的。很多属性支持运算,这意味着你可以在属性文本中嵌入一个表达式(使用 ${} ):
<%include file="/foo/bar/${myfile}.txt"/>
属性是否支持运行时运算取决于标签的类型和它编译到模板的方式。想知道能否添加表达式的最好方法就是试一下!词法分析器会告诉你是否有效。
下面是全部的标签的一个快速总结:
- <%page>
该标签定义了模板的一些通用特性,包括缓存参数和模板调用的参数的可选列表。
<%page args="x, y, z='default'"/>
也可以定义缓存特性:
<%page cached="True" cache_type="memory"/>
目前每个模板只有一个 <%page> 标签生效,其他的会被忽略。以后的版本中这会被改进,但是现在请确保你的模板中只用了一个 <%page> 标签,否则可能得不到你想要的结果。 <%page> 的用途参考 The body() Method 和 Caching
- <%include>
这是和其他模板语言类似的一个标签, %include 接受一个文件参数,调用那个文件的渲染结果:
<%include file="header.html"/>hello world
<%include file="footer.html"/>
它还接受 <%page> 标签的参数,应用到导入的模板上:
<%include file=“toolbar.html” args=“current_section=‘members’, username=‘ed’”/>
- <%def>
%def 标签定义一个Python函数,函数可以在模板的其他位置调用。
<%def name="myfunc(x)">this is myfunc, x is ${x}
</%def>
${myfunc(7)}
%def 标签比Python的 def 强大得多,因为Mako提供了很多额外的功能,比如能够将函数作为模板的“方法”,自动传递当前的 Context ,使用缓冲/过滤/缓存标志,作为参数传递给其他的函数调用。
- <%block>
<%block> 标签和 %def 类似,但它会在根作用域立即执行,而且可以是匿名的:
<%block filter="h">some <html> stuff.
</%block>
借鉴了Jinja2的块,有名字的块实现了一种很方便的继承方法:
<%block name="header"><%block name="title"/>
- <%namespace>
Mako中的 %namespace 和Python的 import 语句等价。通过它可以访问其他模板的所有的渲染函数和metadata,Python模块,还有本地定义的函数“包”。
<%namespace file="functions.html" import="*"/>
%namespace 生成的底层对象是一个 mako.runtime.Namespace 实例。它是模板中的一个核心结构,用来引用模板的特定信息,比如当前的URI、继承结构和其他一些东西。名字空间见 Namespaces 。
- <%inherit>
通过继承可以实现模板的继承链。它和其他模板语言的概念类似。
<%inherit file="base.html"/>
当使用 %inherit 标签时,控制首先被传递到继承模板的顶层模板,由它来决定如何处理调用部分。Mako在这部分实现的非常灵活,包括动态继承、内容封装、多态方法调用
- <%nsname:defname>
可以通过 <%:> 来在一个名字空间中自定义一个标签。它的单标签和双标签形式分别对应行内表达式和 <%call> 标签。
<%mynamespace:somedef param="some value">this is the body
</%mynamespace:somedef>
- <%text>
该标签使Mako词法分析器跳过该部分的处理,返回整个内容。主要用于写Mako的文档:
<%text filter="h">heres some fake mako ${syntax}<%def name="x()">${x}</%def>
</%text>
- 从模板中提前返回
有时你想在模板或 <%def> 方法的中间停止处理,只用当前得到的结果。可以在Python代码块中使用 return 语句来实现。
% if not len(records):No records found.<% return %>
% endif
或:
<%if not len(records):return
%>
实践
了解了mako的基本语法以后,实践代码如下:
- 定义模版文件code_template.tmpl
import pytest
from base import Basic
class ${cls_name}(Basic):device_type = "${context.get("device_type")}"device_info = Basic.get_device_info(device_type)device_id = device_info["device_id"]battery = device_info["battery_id"]
${gen_case_code()}
<%def name="gen_case_code()">
% for case in context.get("case_list"):<%case_keys = list(case.keys())case_name = case["case_name"]modes = case["tags"]case_info_list = case["case_info"]%>% for mode in modes:@pytest.mark.${mode}% endfordef test_${loop.index}_${case["case_name"]}(self, battery):% if "description" in case_keys:"""${case["description"]}"""% endif% for case_data in case_info_list:<%data_keys = list(case_data.keys())%>% if "sim_data" in data_keys:<% sim_data = case_data["sim_data"]%>simulator_data = ${sim_data}simulator_data["battery_id"] = batteryprint(simulator_data)pub_resp = self.dev_publish_msg(self.device_type, self.device_id, **simulator_data)if pub_resp.status_code == 200:print(pub_resp.json())% endifprint(battery)% if "api_name" in data_keys:api_info = self.get_api_with_name("${case_data["api_name"]}")print(api_info)resp = self.send_request(battery, **api_info)print(resp)assert resp.status_code == 200% if "expect" in data_keys:<%expect_data = case_data["expect"]%>if resp["result_code"] == "success":% for ex_k, ex_v in case_data["expect"].items():assert resp["data"]["${ex_k}"] == ${ex_v}% endfor% endif% endif% endfor
% endfor
</%def>
- render()渲染代码:
def code_generator(device_type, case_list, cls_name, case_file):t = Template(filename='code_template.tmpl')try:resp = t.render(device_type=device_type, case_list=case_list, cls_name=cls_name)with open(case_file, 'w') as tmp_f:tmp_f.writelines(resp)print(t.render(device_type=device_type, case_list=case_list, cls_name=cls_name))except Exception:print(exceptions.html_error_template().render())
参考文献:
https://docs.makotemplates.org/en/latest/usage.html
https://www.cnblogs.com/zhaojianwei/p/4666651.html
