Host服务

这也是看网上的例子自己跟着配置做的一个小demo，这里记录一下。

一、创建一个空的控制台应用程序

二、安装所需dll　

　　1.Quartz
　　　　Install-Package Quartz -Version 2.3.3
　　2.Owin
　　　　Install-Package Owin -Version 1.0.0（这个暂时装上）
　　3.TopShelf
　　　　Install-Package TopShelf -Version 3.3.1
　　4.log4net
　　　　Install-Package log4net -Version 2.0.8
　　5.TopShelf.log4net
　　　　Install-Package Topshelf.Log4Net -Version 3.3.1

这里我把版本都标记出来是因为NuGet安装的时候有可能最新的版本会不兼容的问题，如果出现请降版本安装。

三、手动创建

　　1.log4net.config

<?xml version="1.0" encoding="utf-8" ?>
<configuration><configSections><section name="log4net" type="log4net.Config.Log4NetConfigurationSectionHandler, log4net"/></configSections><log4net><appender name="RollingLogFileAppender" type="log4net.Appender.RollingFileAppender"><!--日志路径--><param name= "File" value= "Log\"/><!--是否是向文件中追加日志--><param name= "AppendToFile" value= "true"/><!--log保留天数--><param name= "MaxSizeRollBackups" value= "10"/><!--日志文件名是否是固定不变的--><param name= "StaticLogFileName" value= "false"/><!--日志文件名格式为:2008-08-31.log--><param name= "DatePattern" value= "yyyy-MM-dd&quot;.read.log&quot;"/><!--日志根据日期滚动--><param name= "RollingStyle" value= "Date"/><layout type="log4net.Layout.PatternLayout"><param name="ConversionPattern" value="%date{HH:mm:ss,fff} %-5p-%m%n" /></layout></appender><!-- 控制台前台显示日志 --><appender name="ColoredConsoleAppender" type="log4net.Appender.ColoredConsoleAppender"><mapping><level value="ERROR" /><foreColor value="Red, HighIntensity" /></mapping><mapping><level value="Info" /><foreColor value="Green" /></mapping><layout type="log4net.Layout.PatternLayout"><conversionPattern value="%n%date{HH:mm:ss,fff} [%-5level] %m" /></layout><filter type="log4net.Filter.LevelRangeFilter"><param name="LevelMin" value="Info" /><param name="LevelMax" value="Fatal" /></filter></appender><root><!--(高) OFF > FATAL > ERROR > WARN > INFO > DEBUG > ALL (低) --><level value="all" /><appender-ref ref="ColoredConsoleAppender"/><appender-ref ref="RollingLogFileAppender"/></root></log4net>
</configuration>

View Code

　　2.quartz.config

# You can configure your scheduler in either <quartz> configuration section
# or in quartz properties file
# Configuration section has precedencequartz.scheduler.instanceName = QuartzTest# configure thread pool info
quartz.threadPool.type = Quartz.Simpl.SimpleThreadPool, Quartz
quartz.threadPool.threadCount = 10
quartz.threadPool.threadPriority = Normal# job initialization plugin handles our xml reading, without it defaults are used
quartz.plugin.xml.type = Quartz.Plugin.Xml.XMLSchedulingDataProcessorPlugin, Quartz
quartz.plugin.xml.fileNames = ~/quartz_jobs.xml# export this server to remoting context
#quartz.scheduler.exporter.type = Quartz.Simpl.RemotingSchedulerExporter, Quartz
#quartz.scheduler.exporter.port = 560
#quartz.scheduler.exporter.bindName = QuartzScheduler
#quartz.scheduler.exporter.channelType = tcp
#quartz.scheduler.exporter.channelName = httpQuartz

View Code

　　3.quartz_jobs.xml

<?xml version="1.0" encoding="utf-8" ?>
<!-- This file contains job definitions in schema version 2.0 format --><job-scheduling-data xmlns="http://quartznet.sourceforge.net/JobSchedulingData" xmlns:xsi="http://www.w3.org/2001/XMLSchema-instance" version="2.0"><processing-directives><overwrite-existing-data>true</overwrite-existing-data></processing-directives><schedule><!--TestJob测试 任务配置 --><job><name>TestJob</name><group>Test</group><description>TestJob测试</description><job-type>HostProject.QuartzJobs.TestJob,HostProject</job-type><durable>true</durable><recover>false</recover></job><trigger><cron><name>TestJobTrigger</name><group>Test</group><job-name>TestJob</job-name><job-group>Test</job-group><!-- 从start-time起，每5s执行一次IJob.Execute --><start-time>2012-01-22T00:00:00+08:00</start-time><cron-expression>0/5 * * * * ?</cron-expression></cron></trigger></schedule>
</job-scheduling-data>

View Code

四、创建 ServiceRunner.cs

 public class ServiceRunner : ServiceControl, ServiceSuspend{private readonly IScheduler _IScheduler;public ServiceRunner(){_IScheduler = StdSchedulerFactory.GetDefaultScheduler();}public bool Start(HostControl hostControl){_IScheduler.Start();return true;}public bool Stop(HostControl hostControl){_IScheduler.Shutdown();return true;}public bool Continue(HostControl hostControl){_IScheduler.ResumeAll();return true;}public bool Pause(HostControl hostControl){_IScheduler.PauseAll();return true;}}

View Code

五、TestJob

  public sealed class TestJob:IJob{public void Execute(IJobExecutionContext context){CommonHelper.AppLogger.InfoFormat("TestJob测试");try{//模拟调用存储过程，更新商品库存string connStr = "Data Source=.;Initial Catalog=test;User Id=sa;Password=p@ss!123;";using (SqlConnection conn = new SqlConnection(connStr)){using (SqlCommand cmd = new SqlCommand()){conn.Open();cmd.Connection = conn;cmd.CommandType = CommandType.StoredProcedure;cmd.CommandText = "proc_UpdateInventory";Random random = new Random();SqlParameter[] paras = new SqlParameter[]{new SqlParameter(){ParameterName = "@GoodsId",SqlDbType = SqlDbType.Int,Value =  random.Next(1, 4)},new SqlParameter(){ParameterName = "@Inventory",SqlDbType = SqlDbType.Int,Value = random.Next(1, 100)}};cmd.Parameters.AddRange(paras);int rowCount = cmd.ExecuteNonQuery();   //exec proc_UpdateInventory @GoodsId=1,@Inventory=25if (rowCount > 0)CommonHelper.AppLogger.InfoFormat("商品：{0}，库存已更新，新的库存为：{1}", paras[0].Value, paras[1].Value);elseCommonHelper.AppLogger.InfoFormat("更新商品库失败，无受影响记录：{0}", rowCount);}}}catch (Exception ex){CommonHelper.AppLogger.ErrorFormat("UpdateInventoryJob 作业执行异常：{0}", ex);}}}

View Code

六、CommonHelper

  class CommonHelper{public static readonly ILog AppLogger = log4net.LogManager.GetLogger("ColoredConsoleAppender");static CommonHelper() { }}

View Code

七、Program中代码调用

 static void Main(string[] args){XmlConfigurator.ConfigureAndWatch(new FileInfo(AppDomain.CurrentDomain.BaseDirectory + "log4net.config"));HostFactory.Run(x => {x.UseLog4Net();x.Service<ServiceRunner>();x.RunAsLocalSystem();x.SetDescription("Quartz+TopShelf实现Windows服务作业调度的一个示例Demo");x.SetDisplayName("QuartzTopShelfDemo服务");x.SetServiceName("QuartzTopShelfDemoService");x.EnablePauseAndContinue();});}

View Code

八、特别注意

这三个文件手动创建，默认是“不复制”，这里需要修改为“始终复制”

这样一个Host便可以运行起来了。

九、安装到Windows

用cmd命令行打开这个文件夹

执行命令： HostProject.exe install

卸载：HostProject.exe uninstall

十、SQL脚本(先把存储过程执行过在运行项目)

IF ( OBJECT_ID('Goods', 'U') IS NOT NULL )DROP TABLE Goods;GOCREATE TABLE Goods(Id INT IDENTITY(1, 1)NOT NULL ,Name NVARCHAR(30) NOT NULL ,Inventory INTNOT NULLCONSTRAINT PK_Goods_Id PRIMARY KEY CLUSTERED ( Id ASC ) ON [PRIMARY])
ON  [PRIMARY];INSERT  INTO Goods
VALUES  ( '大米', 0 ),( '香蕉', 0 ),( '苹果', 0 );SELECT  *
FROM    Goods;IF ( OBJECT_ID('proc_UpdateInventory', 'P') IS NOT NULL )DROP PROCEDURE proc_UpdateInventory;GOCREATE PROCEDURE proc_UpdateInventory(@GoodsId INT ,@Inventory INT)
ASUPDATE  GoodsSET     Inventory = @InventoryWHERE   Id = @GoodsId;GO
