在前面的blog中，我们已经讲了SIFT的原理，这里我们再详细讲解SIFT的变体：PCA-SIFT和GLOH。

– Scale invariant feature transform (SIFT): Lowe, 2004.

– PCA-SIFT: SIFT: Ke and Sukthankar 2004 Ke and Sukthankar, 2004.

– Gradient location-orientation histogram (GLOH): Mikolajczyk and Schmid 2005

– SURF(Speeded Up Robust Features), Bay, 2006回顾前面讲过的SIFT算法，可以很好地应对旋转和尺度不变，光强不变，位置遮挡不变（http://blog.csdn.net/abcjennifer/article/details/7639681），其过程分为四步：

– Detection of scale-space extreme 构建尺度空间
– Accurate keypoint localization 关键点检测
– Orientation assignment 指定方向
– The local image descriptor 局部图像描述子

David G. Lowe, "Distinctive image features from scale-invariant keypoints," International Journal of Computer Vision, 60, 2 (2004), pp. 91-110

/***************************************************PCA-SIFT*****************************************************/

PCA(Principle component analysis) SIFT 描述子将在所有描述子中提取出更有区分度，更robust to image deformations的特征。其方法：

– 在第四步中，不用原先的4*4*8个描述子，而是在41*41的图像块上计算39*39*2（x,y方向）个梯度导数，然后使用PCA将得到的3042维向量降到36维。

Y. Ke and R. Sukthankar, “PCA-SIFT: A More Distinctive Representation for Local Image 15 Descriptors,” Computer Vision and Pattern Recognition, 2004.

当然，上图只是PCA-SIFT作者的一面之词，Mikolajczyk and Schmid（2005）的描述子测评显示还是SIFT比较靠谱。

/***************************************************GLOH*****************************************************/

Mikolajczyk and Schmid（2005）提出了一种SIFT变体的描述子，使用对数极坐标分级结构替代Lowe（2004）使用的4象限。空间上取半径6，11，15，角度上分八个区间（除中间区域）,然后将272（17*16）维的histogram在一个大数据库上训练，用PCA投影到一个128维向量。

K. Mikolajczyk and C. Schmid,“A performance evaluation of local descriptors ,” IEEE Transactions on Pattern Analysis and Machine Intelligence, Vol. 27, No. 10, pp. 1615-1630, Oct. 2005

/***************************************************SURF*****************************************************/

SURF与SIFT稍有不同，

-SIFT建立一幅图像的金字塔，在每一层进行高斯滤波并求取图像差（DOG）进行特征点的提取，而SURF用的是hessian matrix黑森矩阵。

-SIFT特征建立图像金字塔处理尺度不变特性，而SURF特征将高斯核近似为一个方波滤波，SURF金字塔仅仅用来作特征点的检测。

下文来自《A Comparison of SIFT, PCA-SIFT and SURF》

SIFT and SURF algorithms employ slightly different ways of detecting features [9]. SIFT builds an image
pyramids, filtering each layer with Gaussians of increasing sigma values and taking the difference. On the
other hand, SURF creates a “stack” without 2:1 down sampling for higher levels in the pyramid resulting
in images of the same resolution [9]. Due to the use of integral images, SURF filters the stack using a box
filter approximation of second-order Gaussian partial derivatives, since integral images allow the
computation of rectangular box filters in near constant time [3].

In keypoint matching step, the nearest neighbor is defined as the keypoint with minimum Euclidean
distance for the invariant descriptor vector. Lowe used a more effective measurement that obtained by
comparing the distance of the closest neighbor to that second-closest neighbor [1] so the author of this
paper decided to choose 0.5 as distance ratio like Lowe did in SIFT.

Herbert Bay, Andreas Ess, Tinne Tuytelaars, Luc Van Gool "SURF: Speeded Up Robust Features", Computer Vision and Image Understanding (CVIU), Vol. 110, No. 3, pp. 346--359, 2008

ftp://ftp.vision.ee.ethz.ch/publications/articles/eth_biwi_00517.pdf

/***************************************************COMPARISON*****************************************************/

论文：A comparison of SIFT, PCA-SIFT and SURF 对三种方法给出了性能上的比较，源图片来源于Graffiti dataset，对原图像进行尺度、旋转、模糊、亮度变化、仿射变换等变化后，再与原图像进行匹配，统计匹配的效果。效果以可重复出现性为评价指标。

对以上三种方法进行比较：
