一、React项目快速搭建

1、新建文件夹

2、直接在对应目录输入 cmd ，打开终端

3、执行指令完成React应用建立

npx create-react-app react_echarts_demo

cd react_echarts_demo
npm start

二、React项目结构和分析

• 终端对应目录下输入 code . 打开 vs code

1、删除多于文件，使得结构清晰

2、删除剩余文件中多于的引用内容

3、使用vs code打开终端，运行项目

三、Echarts工具使用

1、npm安装依赖

npm install echarts --save
npm install --save echarts-for-react

2、简单折线图 使用 echarts-for-react

• 引用代码

import React from 'react';
import ReactDOM from 'react-dom/client';
import LineCharts  from './LineCharts';const root = ReactDOM.createRoot(document.getElementById('root'));root.render(<div> <h1> 简单折线图</h1><LineCharts></LineCharts></div>
);

• 组件代码

import React, {Component} from 'react';
import ReactECharts from 'echarts-for-react';// 在此组件中绘制一个简单的折线图
export default class LineCharts  extends Component{// 返回折线图的配置对象option = {xAxis: {type: 'category',data: ['A', 'B', 'C']},yAxis: {type: 'value'},series: [{data: [120, 200, 150],type: 'line'}]};render() {return(<div><ReactECharts option={this.option} /></div>)}
}

3、燃尽图 使用echarts

• 代码如下：

index.js

import React from 'react';
import ReactDOM from 'react-dom/client';
import LineEChartsDemo  from './LineEchartsDemo';const root = ReactDOM.createRoot(document.getElementById('root'));root.render(<div> <h1>燃尽图</h1><LineEChartsDemo></LineEChartsDemo></div>
);

LineEchartsDemo.jsx

import React, { Component } from 'react'
import LineECharts from './LineECharts'class LineEchartsDemo extends Component{constructor(props) {super(props)this.state = {data: {x: ['2023-03-18', '2023-03-19', '2023-03-20', '2023-03-22', '2023-03-23', '2023-03-24', '2023-03-25'],y: [100, 93, 80, 70, 53, 36, 0]}}}componentDidMount() { }render() {return (<LineECharts data={this.state.data} yname="进度/%" />  )}
}export default LineEchartsDemo

LineECharts.jsx

import React, {Component} from 'react';import * as echarts from 'echarts';export default class LineECharts  extends Component{constructor(props) {super(props)this.state = {}}// 挂载完成之后，因为React初始化echarts时长宽可能会获取到顶层，所以延迟200去生成，不影响视觉效果componentDidMount() {setTimeout(() => {this.initEchart(this.props.data)}, 200)}// 更新props以后调用componentWillReceiveProps(newProps) {this.initEchart(newProps.data)}initEchart = (data) => {let myEcharts = echarts.init(this.echartsBox)let option = {title: {text: this.props.title || '',left: 'center',top: '0'},tooltip: {show: true,trigger: 'axis',formatter: '{b}<br/>进度：{c}%',extraCssText: 'box-shadow: 0 0 3px rgba(0, 0, 0, 0.3);'},xAxis: {type: 'category',data: data.x,  },yAxis: {name: this.props.yname,nameGap: 15,position: 'left',axisLabel: {formatter: '{value}'}},series: [{name: '汇总',type: 'line',data: data.y,smooth: false,lineStyle: {color: '#00CC99',width: 2},}]}myEcharts.setOption(option)myEcharts.on('finished', () => {myEcharts.resize()})}render() {return (<div ref={(c) => { this.echartsBox = c }} style={{ width: '500px', height: '500px' }} />)}
}

4、不同的图形，Echarts官网找对应Option内容复制即可

option = {xAxis: {data: ['A', 'B', 'C', 'D', 'E']},yAxis: {},series: [{data: [10, 22, 28, 43, 49],type: 'line',stack: 'x'},{data: [5, 4, 3, 5, 10],type: 'line',stack: 'x'}]
};
