zipkin

zipkin为分布式链路调用监控系统，聚合各业务系统调用延迟数据，达到链路调用监控跟踪。

architecture

如图，在复杂的调用链路中假设存在一条调用链路响应缓慢，如何定位其中延迟高的服务呢？

• 日志： 通过分析调用链路上的每个服务日志得到结果
• zipkin：使用zipkin的web UI可以一眼看出延迟高的服务

如图所示，各业务系统在彼此调用时，将特定的跟踪消息传递至zipkin,zipkin在收集到跟踪信息后将其聚合处理、存储、展示等，用户可通过web UI方便
获得网络延迟、调用链路、系统依赖等等。

zipkin主要涉及四个组件 collector storage search web UI

• Collector接收各service传输的数据
• Cassandra作为Storage的一种，也可以是mysql等，默认存储在内存中，配置cassandra可以参考这里
• Query负责查询Storage中存储的数据,提供简单的JSON API获取数据，主要提供给web UI使用
• Web 提供简单的web界面

install

执行如下命令下载jar包

wget -O zipkin.jar 'https://search.maven.org/remote_content?g=io.zipkin.java&a=zipkin-server&v=LATEST&c=exec'

其为一个spring boot 工程，直接运行jar

nohup java -jar zipkin.jar &

访问 http://ip:9411

terminology

使用zipkin涉及几个概念

• Span:基本工作单元，一次链路调用(可以是RPC，DB等没有特定的限制)创建一个span，通过一个64位ID标识它，
  span通过还有其他的数据，例如描述信息，时间戳，key-value对的(Annotation)tag信息，parent-id等,其中parent-id
  可以表示span调用链路来源，通俗的理解span就是一次请求信息

• Trace:类似于树结构的Span集合，表示一条调用链路，存在唯一标识

• Annotation: 注解,用来记录请求特定事件相关信息(例如时间)，通常包含四个注解信息

  cs - Client Start,表示客户端发起请求

  sr - Server Receive,表示服务端收到请求

  ss - Server Send,表示服务端完成处理，并将结果发送给客户端

  cr - Client Received,表示客户端获取到服务端返回信息

• BinaryAnnotation:提供一些额外信息，一般已key-value对出现

概念说完，来看下完整的调用链路

上图表示一请求链路，一条链路通过Trace Id唯一标识，Span标识发起的请求信息，各span通过parent id 关联起来，如图

整个链路的依赖关系如下:

完成链路调用的记录后，如何来计算调用的延迟呢，这就需要利用Annotation信息

sr-cs 得到请求发出延迟

ss-sr 得到服务端处理延迟

cr-cs 得到真个链路完成延迟

brave

作为各调用链路，只需要负责将指定格式的数据发送给zipkin即可，利用brave可快捷完成操作。

首先导入jar包pom.xml

<parent><groupId>org.springframework.boot</groupId><artifactId>spring-boot-starter-parent</artifactId><version>1.3.6.RELEASE</version></parent><!-- https://mvnrepository.com/artifact/io.zipkin.brave/brave-core --><dependencies><dependency><groupId>org.springframework.boot</groupId><artifactId>spring-boot-starter-web</artifactId></dependency><dependency><groupId>org.springframework.boot</groupId><artifactId>spring-boot-starter-aop</artifactId></dependency><dependency><groupId>org.springframework.boot</groupId><artifactId>spring-boot-starter-actuator</artifactId></dependency><dependency><groupId>io.zipkin.brave</groupId><artifactId>brave-core</artifactId><version>3.9.0</version></dependency><!-- https://mvnrepository.com/artifact/io.zipkin.brave/brave-http --><dependency><groupId>io.zipkin.brave</groupId><artifactId>brave-http</artifactId><version>3.9.0</version></dependency><dependency><groupId>io.zipkin.brave</groupId><artifactId>brave-spancollector-http</artifactId><version>3.9.0</version></dependency><dependency><groupId>io.zipkin.brave</groupId><artifactId>brave-web-servlet-filter</artifactId><version>3.9.0</version></dependency><dependency><groupId>io.zipkin.brave</groupId><artifactId>brave-okhttp</artifactId><version>3.9.0</version></dependency><!-- https://mvnrepository.com/artifact/org.slf4j/slf4j-api --><dependency><groupId>org.slf4j</groupId><artifactId>slf4j-api</artifactId><version>1.7.13</version></dependency><dependency><groupId>org.apache.httpcomponents</groupId><artifactId>httpclient</artifactId><version>4.5.1</version></dependency></dependencies>

利用spring boot创建工程

Application.java

package com.lkl.zipkin;import org.springframework.boot.SpringApplication;
import org.springframework.boot.autoconfigure.SpringBootApplication;/**** Created by liaokailin on 16/7/27.*/
@SpringBootApplication
public class Application {public static void main(String[] args) {SpringApplication app = new SpringApplication(Application.class);app.run(args);}
}

建立controller对外提供服务

HomeController.java

RestController
@RequestMapping("/")
public class HomeController {@Autowiredprivate OkHttpClient client;private  Random random = new Random();@RequestMapping("start")public String start() throws InterruptedException, IOException {int sleep= random.nextInt(100);TimeUnit.MILLISECONDS.sleep(sleep);Request request = new Request.Builder().url("http://localhost:9090/foo").get().build();Response response = client.newCall(request).execute();return " [service1 sleep " + sleep+" ms]" + response.body().toString();}

HomeController中利用OkHttpClient调用发起http请求。在每次发起请求时则需要通过brave记录Span信息，并异步传递给zipkin
作为被调用方(服务端)也同样需要完成以上操作.

ZipkinConfig.java

package com.lkl.zipkin.config;import com.github.kristofa.brave.Brave;
import com.github.kristofa.brave.EmptySpanCollectorMetricsHandler;
import com.github.kristofa.brave.SpanCollector;
import com.github.kristofa.brave.http.DefaultSpanNameProvider;
import com.github.kristofa.brave.http.HttpSpanCollector;
import com.github.kristofa.brave.okhttp.BraveOkHttpRequestResponseInterceptor;
import com.github.kristofa.brave.servlet.BraveServletFilter;
import okhttp3.OkHttpClient;
import org.springframework.beans.factory.annotation.Autowired;
import org.springframework.context.annotation.Bean;
import org.springframework.context.annotation.Configuration;/*** Created by liaokailin on 16/7/27.*/
@Configuration
public class ZipkinConfig {@Autowiredprivate ZipkinProperties properties;@Beanpublic SpanCollector spanCollector() {HttpSpanCollector.Config config = HttpSpanCollector.Config.builder().connectTimeout(properties.getConnectTimeout()).readTimeout(properties.getReadTimeout()).compressionEnabled(properties.isCompressionEnabled()).flushInterval(properties.getFlushInterval()).build();return HttpSpanCollector.create(properties.getUrl(), config, new EmptySpanCollectorMetricsHandler());}@Beanpublic Brave brave(SpanCollector spanCollector){Brave.Builder builder = new Brave.Builder(properties.getServiceName());  //指定statebuilder.spanCollector(spanCollector);builder.traceSampler(Sampler.ALWAYS_SAMPLE);Brave brave = builder.build();return brave;}@Beanpublic BraveServletFilter braveServletFilter(Brave brave){BraveServletFilter filter = new BraveServletFilter(brave.serverRequestInterceptor(),brave.serverResponseInterceptor(),new DefaultSpanNameProvider());return filter;}@Beanpublic OkHttpClient okHttpClient(Brave brave){OkHttpClient client = new OkHttpClient.Builder().addInterceptor(new BraveOkHttpRequestResponseInterceptor(brave.clientRequestInterceptor(), brave.clientResponseInterceptor(), new DefaultSpanNameProvider())).build();return client;}
}

• SpanCollector 配置收集器

• Brave 各工具类的封装,其中builder.traceSampler(Sampler.ALWAYS_SAMPLE)设置采样比率，0-1之间的百分比

• BraveServletFilter 作为拦截器，需要serverRequestInterceptor,serverResponseInterceptor 分别完成sr和ss操作

• OkHttpClient 添加拦截器，需要clientRequestInterceptor,clientResponseInterceptor 分别完成cs和cr操作,该功能由
  brave中的brave-okhttp模块提供，同样的道理如果需要记录数据库的延迟只要在数据库操作前后完成cs和cr即可，当然brave提供其封装。

以上还缺少一个配置信息ZipkinProperties.java

package com.lkl.zipkin.config;import org.springframework.boot.context.properties.ConfigurationProperties;
import org.springframework.context.annotation.Configuration;/*** Created by liaokailin on 16/7/28.*/
@Configuration
@ConfigurationProperties(prefix = "com.zipkin")
public class ZipkinProperties {private String serviceName;private String url;private int connectTimeout;private int readTimeout;private int flushInterval;private boolean compressionEnabled;public String getUrl() {return url;}public void setUrl(String url) {this.url = url;}public int getConnectTimeout() {return connectTimeout;}public void setConnectTimeout(int connectTimeout) {this.connectTimeout = connectTimeout;}public int getReadTimeout() {return readTimeout;}public void setReadTimeout(int readTimeout) {this.readTimeout = readTimeout;}public int getFlushInterval() {return flushInterval;}public void setFlushInterval(int flushInterval) {this.flushInterval = flushInterval;}public boolean isCompressionEnabled() {return compressionEnabled;}public void setCompressionEnabled(boolean compressionEnabled) {this.compressionEnabled = compressionEnabled;}public String getServiceName() {return serviceName;}public void setServiceName(String serviceName) {this.serviceName = serviceName;}
}

则可以在配置文件application.properties中配置相关信息

com.zipkin.serviceName=service1
com.zipkin.url=http://110.173.14.57:9411
com.zipkin.connectTimeout=6000
com.zipkin.readTimeout=6000
com.zipkin.flushInterval=1
com.zipkin.compressionEnabled=true
server.port=8080

那么其中的service1即完成，同样的道理，修改配置文件(调整com.zipkin.serviceName,以及server.port)以及controller对应的方法构造若干服务

service1 中访问http://localhost:8080/start需要访问http://localhost:9090/foo,则构造server2提供该方法

server2配置

com.zipkin.serviceName=service2
com.zipkin.url=http://110.173.14.57:9411
com.zipkin.connectTimeout=6000
com.zipkin.readTimeout=6000
com.zipkin.flushInterval=1
com.zipkin.compressionEnabled=trueserver.port=9090

controller方法

    @RequestMapping("foo")public String foo() throws InterruptedException, IOException {Random random = new Random();int sleep= random.nextInt(100);TimeUnit.MILLISECONDS.sleep(sleep);Request request = new Request.Builder().url("http://localhost:9091/bar").get().build();  //service3Response response = client.newCall(request).execute();String result = response.body().string();request = new Request.Builder().url("http://localhost:9092/tar").get().build();  //service4response = client.newCall(request).execute();result += response.body().string();return " [service2 sleep " + sleep+" ms]" + result;}

在server2中调用server3和server4中的方法

方法分别为

 @RequestMapping("bar")public String bar() throws InterruptedException, IOException {  //service3 methodRandom random = new Random();int sleep= random.nextInt(100);TimeUnit.MILLISECONDS.sleep(sleep);return " [service3 sleep " + sleep+" ms]";}@RequestMapping("tar")public String tar() throws InterruptedException, IOException { //service4 methodRandom random = new Random();int sleep= random.nextInt(1000);TimeUnit.MILLISECONDS.sleep(sleep);return " [service4 sleep " + sleep+" ms]";}

将工程修改后编译成jar形式

执行

nohup java -jar server4.jar &
nohup java -jar server3.jar &
nohup java -jar server2.jar &
nohup java -jar server1.jar &

访问http://localhost:8080/start后查看zipkin的web UI

点击条目可以查看具体的延迟信息

服务之间的依赖为

brave 源码

以上完成了基本的操作，下面将从源码角度来看下brave的实现

首先从SpanCollector来入手

@Beanpublic SpanCollector spanCollector() {HttpSpanCollector.Config config = HttpSpanCollector.Config.builder().connectTimeout(properties.getConnectTimeout()).readTimeout(properties.getReadTimeout()).compressionEnabled(properties.isCompressionEnabled()).flushInterval(properties.getFlushInterval()).build();return HttpSpanCollector.create(properties.getUrl(), config, new EmptySpanCollectorMetricsHandler());}

从名称上看HttpSpanCollector是基于http的span收集器,因此超时配置是必须的，默认给出的超时时间较长，flushInterval表示span的传递
间隔，实际为定时任务执行的间隔时间.在HttpSpanCollector中覆写了父类方法sendSpans

@Overrideprotected void sendSpans(byte[] json) throws IOException {// intentionally not closing the connection, so as to use keep-alivesHttpURLConnection connection = (HttpURLConnection) new URL(url).openConnection();connection.setConnectTimeout(config.connectTimeout());connection.setReadTimeout(config.readTimeout());connection.setRequestMethod("POST");connection.addRequestProperty("Content-Type", "application/json");if (config.compressionEnabled()) {connection.addRequestProperty("Content-Encoding", "gzip");ByteArrayOutputStream gzipped = new ByteArrayOutputStream();try (GZIPOutputStream compressor = new GZIPOutputStream(gzipped)) {compressor.write(json);}json = gzipped.toByteArray();}connection.setDoOutput(true);connection.setFixedLengthStreamingMode(json.length);connection.getOutputStream().write(json);try (InputStream in = connection.getInputStream()) {while (in.read() != -1) ; // skip} catch (IOException e) {try (InputStream err = connection.getErrorStream()) {if (err != null) { // possible, if the connection was droppedwhile (err.read() != -1) ; // skip}}throw e;}}
}

可以看出最终span信息是通过HttpURLConnection实现的，同样道理就可以推理brave对brave-spring-resttemplate-interceptors模块的实现，
只是换了一种http封装。

Brave

 @Beanpublic Brave brave(SpanCollector spanCollector){Brave.Builder builder = new Brave.Builder(properties.getServiceName());  //指定statebuilder.spanCollector(spanCollector);builder.traceSampler(Sampler.ALWAYS_SAMPLE);Brave brave = builder.build();return brave;}

Brave类包装了各种工具类

public Brave build() {return new Brave(this);}

创建一个Brave

private Brave(Builder builder) {serverTracer = ServerTracer.builder().randomGenerator(builder.random).spanCollector(builder.spanCollector).state(builder.state).traceSampler(builder.sampler).build();clientTracer = ClientTracer.builder().randomGenerator(builder.random).spanCollector(builder.spanCollector).state(builder.state).traceSampler(builder.sampler).build();localTracer = LocalTracer.builder().randomGenerator(builder.random).spanCollector(builder.spanCollector).spanAndEndpoint(SpanAndEndpoint.LocalSpanAndEndpoint.create(builder.state)).traceSampler(builder.sampler).build();serverRequestInterceptor = new ServerRequestInterceptor(serverTracer);serverResponseInterceptor = new ServerResponseInterceptor(serverTracer);clientRequestInterceptor = new ClientRequestInterceptor(clientTracer);clientResponseInterceptor = new ClientResponseInterceptor(clientTracer);serverSpanAnnotationSubmitter = AnnotationSubmitter.create(SpanAndEndpoint.ServerSpanAndEndpoint.create(builder.state));serverSpanThreadBinder = new ServerSpanThreadBinder(builder.state);clientSpanThreadBinder = new ClientSpanThreadBinder(builder.state);}

封装了*Tracer,*Interceptor,*Binder等

其中 serverTracer当服务作为服务端时处理span信息，clientTracer当服务作为客户端时处理span信息

Filter

BraveServletFilter是http模块提供的拦截器功能，传递serverRequestInterceptor,serverResponseInterceptor,spanNameProvider等参数
其中spanNameProvider表示如何处理span的名称，默认使用method名称,spring boot中申明的filter bean 默认拦截所有请求

@Overridepublic void doFilter(ServletRequest request, ServletResponse response, FilterChain filterChain) throws IOException, ServletException {String alreadyFilteredAttributeName = getAlreadyFilteredAttributeName();boolean hasAlreadyFilteredAttribute = request.getAttribute(alreadyFilteredAttributeName) != null;if (hasAlreadyFilteredAttribute) {// Proceed without invoking this filter...filterChain.doFilter(request, response);} else {final StatusExposingServletResponse statusExposingServletResponse = new StatusExposingServletResponse((HttpServletResponse) response);requestInterceptor.handle(new HttpServerRequestAdapter(new ServletHttpServerRequest((HttpServletRequest) request), spanNameProvider));try {filterChain.doFilter(request, statusExposingServletResponse);} finally {responseInterceptor.handle(new HttpServerResponseAdapter(new HttpResponse() {@Overridepublic int getHttpStatusCode() {return statusExposingServletResponse.getStatus();}}));}}}

首先来看requestInterceptor.handle方法，

public void handle(ServerRequestAdapter adapter) {serverTracer.clearCurrentSpan();final TraceData traceData = adapter.getTraceData();Boolean sample = traceData.getSample();if (sample != null && Boolean.FALSE.equals(sample)) {serverTracer.setStateNoTracing();LOGGER.fine("Received indication that we should NOT trace.");} else {if (traceData.getSpanId() != null) {LOGGER.fine("Received span information as part of request.");SpanId spanId = traceData.getSpanId();serverTracer.setStateCurrentTrace(spanId.traceId, spanId.spanId,spanId.nullableParentId(), adapter.getSpanName());} else {LOGGER.fine("Received no span state.");serverTracer.setStateUnknown(adapter.getSpanName());}serverTracer.setServerReceived();for(KeyValueAnnotation annotation : adapter.requestAnnotations()){serverTracer.submitBinaryAnnotation(annotation.getKey(), annotation.getValue());}}}

其中serverTracer.clearCurrentSpan()清除当前线程上的span信息，调用ThreadLocalServerClientAndLocalSpanState中的

@Overridepublic void setCurrentServerSpan(final ServerSpan span) {if (span == null) {currentServerSpan.remove();} else {currentServerSpan.set(span);}}

currentServerSpan为ThreadLocal对象

private final static ThreadLocal<ServerSpan> currentServerSpan = new ThreadLocal<ServerSpan>() {

回到ServerRequestInterceptor#handle()方法中final TraceData traceData = adapter.getTraceData()

 @Overridepublic TraceData getTraceData() {final String sampled = serverRequest.getHttpHeaderValue(BraveHttpHeaders.Sampled.getName());if (sampled != null) {if (sampled.equals("0") || sampled.toLowerCase().equals("false")) {return TraceData.builder().sample(false).build();} else {final String parentSpanId = serverRequest.getHttpHeaderValue(BraveHttpHeaders.ParentSpanId.getName());final String traceId = serverRequest.getHttpHeaderValue(BraveHttpHeaders.TraceId.getName());final String spanId = serverRequest.getHttpHeaderValue(BraveHttpHeaders.SpanId.getName());if (traceId != null && spanId != null) {SpanId span = getSpanId(traceId, spanId, parentSpanId);return TraceData.builder().sample(true).spanId(span).build();}}}return TraceData.builder().build();}

其中SpanId span = getSpanId(traceId, spanId, parentSpanId) 将构造一个SpanId对象

 private SpanId getSpanId(String traceId, String spanId, String parentSpanId) {return SpanId.builder().traceId(convertToLong(traceId)).spanId(convertToLong(spanId)).parentId(parentSpanId == null ? null : convertToLong(parentSpanId)).build();}

将traceId,spanId,parentId关联起来，其中设置parentId方法为

public Builder parentId(@Nullable Long parentId) {if (parentId == null) {this.flags |= FLAG_IS_ROOT;} else {this.flags &= ~FLAG_IS_ROOT;}this.parentId = parentId;return this;}

如果parentId为空为根节点，则执行this.flags |= FLAG_IS_ROOT ,因此后续在判断节点是否为根节点时，只需要执行(flags & FLAG_IS_ROOT) == FLAG_IS_ROOT即可.

构造完SpanId后看

    serverTracer.setStateCurrentTrace(spanId.traceId, spanId.spanId,spanId.nullableParentId(), adapter.getSpanName());

设置当前Span

 public void setStateCurrentTrace(long traceId, long spanId, @Nullable Long parentSpanId, @Nullable String name) {checkNotBlank(name, "Null or blank span name");spanAndEndpoint().state().setCurrentServerSpan(ServerSpan.create(traceId, spanId, parentSpanId, name));}

ServerSpan.create创建Span信息

static ServerSpan create(long traceId, long spanId, @Nullable Long parentSpanId, String name) {Span span = new Span();span.setTrace_id(traceId);span.setId(spanId);if (parentSpanId != null) {span.setParent_id(parentSpanId);}span.setName(name);return create(span, true);}

构造了一个包含Span信息的AutoValue_ServerSpan对象

通过setCurrentServerSpan设置到当前线程上

继续看serverTracer.setServerReceived()方法

public void setServerReceived() {submitStartAnnotation(zipkinCoreConstants.SERVER_RECV);}

为当前请求设置了server received event

void submitStartAnnotation(String annotationName) {Span span = spanAndEndpoint().span();if (span != null) {Annotation annotation = Annotation.create(currentTimeMicroseconds(),annotationName,spanAndEndpoint().endpoint());synchronized (span) {span.setTimestamp(annotation.timestamp);span.addToAnnotations(annotation);}}}

在这里为Span信息设置了Annotation信息,后续的

 for(KeyValueAnnotation annotation : adapter.requestAnnotations()){serverTracer.submitBinaryAnnotation(annotation.getKey(), annotation.getValue());}

设置了BinaryAnnotation信息，adapter.requestAnnotations()在构造HttpServerRequestAdapter时已完成

 @Overridepublic Collection<KeyValueAnnotation> requestAnnotations() {KeyValueAnnotation uriAnnotation = KeyValueAnnotation.create(TraceKeys.HTTP_URL, serverRequest.getUri().toString());return Collections.singleton(uriAnnotation);}

以上将Span信息(包括sr)存储在当前线程中，接下来继续看BraveServletFilter#doFilter方法的finally部分

responseInterceptor.handle(new HttpServerResponseAdapter(new HttpResponse() {@Override  //获取http状态码public int getHttpStatusCode() {return statusExposingServletResponse.getStatus();}}));

handle方法

 public void handle(ServerResponseAdapter adapter) {// We can submit this in any case. When server state is not set or// we should not trace this request nothing will happen.LOGGER.fine("Sending server send.");try {for(KeyValueAnnotation annotation : adapter.responseAnnotations()){serverTracer.submitBinaryAnnotation(annotation.getKey(), annotation.getValue());}serverTracer.setServerSend();} finally {serverTracer.clearCurrentSpan();}}

首先配置BinaryAnnotation信息，然后执行serverTracer.setServerSend,在finally中清除当前线程中的Span信息(不管前面是否清楚成功,最终都将执行该不走)，ThreadLocal中的数据要做到有始有终

看serverTracer.setServerSend()

public void setServerSend() {if (submitEndAnnotation(zipkinCoreConstants.SERVER_SEND, spanCollector())) {spanAndEndpoint().state().setCurrentServerSpan(null);}}

终于看到spanCollector收集器了，说明下面将看是收集Span信息,这里为ss注解

boolean submitEndAnnotation(String annotationName, SpanCollector spanCollector) {Span span = spanAndEndpoint().span();if (span == null) {return false;}Annotation annotation = Annotation.create(currentTimeMicroseconds(),annotationName,spanAndEndpoint().endpoint());span.addToAnnotations(annotation);if (span.getTimestamp() != null) {span.setDuration(annotation.timestamp - span.getTimestamp());}spanCollector.collect(span);return true;}

首先获取当前线程中的Span信息，然后处理注解信息，通过annotation.timestamp - span.getTimestamp()计算延迟,
调用spanCollector.collect(span)进行收集Span信息，那么Span信息是同步收集的吗？肯定不是的，接着看

调用spanCollector.collect(span)则执行FlushingSpanCollector中的collect方法

@Overridepublic void collect(Span span) {metrics.incrementAcceptedSpans(1);if (!pending.offer(span)) {metrics.incrementDroppedSpans(1);}}

首先进行的是metrics统计信息，可以自定义该SpanCollectorMetricsHandler信息收集各指标信息,利用如grafana等展示信息

pending.offer(span)将span信息存储在BlockingQueue中，然后通过定时任务去取出阻塞队列中的值，偷偷摸摸的上传span信息

定时任务利用了Flusher类来执行，在构造FlushingSpanCollector时构造了Flusher类

static final class Flusher implements Runnable {final Flushable flushable;final ScheduledExecutorService scheduler = Executors.newScheduledThreadPool(1);Flusher(Flushable flushable, int flushInterval) {this.flushable = flushable;this.scheduler.scheduleWithFixedDelay(this, 0, flushInterval, SECONDS);}@Overridepublic void run() {try {flushable.flush();} catch (IOException ignored) {}}}

创建了一个核心线程数为1的线程池，每间隔flushInterval秒执行一次Span信息上传，执行flush方法

@Overridepublic void flush() {if (pending.isEmpty()) return;List<Span> drained = new ArrayList<Span>(pending.size());pending.drainTo(drained);if (drained.isEmpty()) return;int spanCount = drained.size();try {reportSpans(drained);} catch (IOException e) {metrics.incrementDroppedSpans(spanCount);} catch (RuntimeException e) {metrics.incrementDroppedSpans(spanCount);}}

首先将阻塞队列中的值全部取出存如集合中，最后调用reportSpans(List<Span> drained)抽象方法，该方法在AbstractSpanCollector得到覆写

@Overrideprotected void reportSpans(List<Span> drained) throws IOException {byte[] encoded = codec.writeSpans(drained);sendSpans(encoded);}

转换成字节流后调用sendSpans抽象方法发送Span信息，此时就回到一开始说的HttpSpanCollector通过HttpURLConnection实现的sendSpans方法。
