protobuf的编译其实相对简单，这里搬一下protobuf的ReadMe就很清楚了~ 如果是平时接触开源项目无从下手的小伙伴，也建议从阅读ReadMe开始哦!

This directory contains CMake files that can be used to build
protobuf with MSVC on Windows. You can build the project from
Command Prompt and using an Visual Studio IDE.

我们需要安装cmake工具以及vs studio的IDE。

You need to have CMake, Visual
Studio and optionally
Git installed on your computer before
proceeding.

Most of the instructions will be given to the Сommand Prompt, but
the same actions can be performed using appropriate GUI tools.

Environment Setup

Open the appropriate Command Prompt from the Start menu.

For example x86 Native Tools Command Prompt for VS 2019:
C:\Program Files (x86)\Microsoft Visual Studio\2019\Professional>

Change to your working directory:

C:\Program Files (x86)\Microsoft Visual Studio\2019\Professional>cd C:\Path\to
C:\Path\to>

Where C:\Path\to is path to your real working directory.

Create a folder where protobuf headers/libraries/binaries will be installed after built:

C:\Path\to>mkdir install

If cmake command is not available from Command Prompt, add it to system PATH variable:

C:\Path\to>set PATH=%PATH%;C:\Program Files (x86)\CMake\bin

If git command is not available from Command Prompt, add it to system PATH variable:

C:\Path\to>set PATH=%PATH%;C:\Program Files\Git\cmd

Good. Now you are ready to continue.

Getting Sources

You can get the latest stable source packages from the release page:

https://github.com/protocolbuffers/protobuf/releases/latest

For example: if you only need C++, download protobuf-cpp-[VERSION].tar.gz; if
you need C++ and Java, download protobuf-java-[VERSION].tar.gz (every package
contains C++ source already); if you need C++ and multiple other languages,
download protobuf-all-[VERSION].tar.gz.

Or you can use git to clone from protobuf git repository.

 C:\Path\to> git clone -b [release_tag] https://github.com/protocolbuffers/protobuf.git

Where [release_tag] is a git tag like v3.0.0-beta-1 or a branch name like master
if you want to get the latest code.

Go to the project folder:

 C:\Path\to>cd protobufC:\Path\to\protobuf>

Remember to update any submodules if you are using git clone (you can skip this
step if you are using a release .tar.gz or .zip package):

C:\Path\to> git submodule update --init --recursive

Now go to cmake folder in protobuf sources:

C:\Path\to\protobuf>cd cmake
C:\Path\to\protobuf\cmake>

Good. Now you are ready to CMake configuration.

CMake Configuration

CMake supports a lot of different
generators
for various native build systems.
We are only interested in
Makefile
and
Visual Studio
generators.

We will use shadow building to separate the temporary files from the protobuf source code.

Create a temporary build folder and change your working directory to it:

 C:\Path\to\protobuf\cmake>mkdir build & cd buildC:\Path\to\protobuf\cmake\build>

The Makefile generator can build the project in only one configuration, so you need to build
a separate folder for each configuration.

To start using a *Release* configuration:C:\Path\to\protobuf\cmake\build>mkdir release & cd releaseC:\Path\to\protobuf\cmake\build\release>cmake -G "NMake Makefiles" ^-DCMAKE_BUILD_TYPE=Release ^-DCMAKE_INSTALL_PREFIX=../../../../install ^../..

It will generate nmake Makefile in current directory.

To use *Debug* configuration:C:\Path\to\protobuf\cmake\build>mkdir debug & cd debugC:\Path\to\protobuf\cmake\build\debug>cmake -G "NMake Makefiles" ^-DCMAKE_BUILD_TYPE=Debug ^-DCMAKE_INSTALL_PREFIX=../../../../install ^../..

It will generate nmake Makefile in current directory.

To create *Visual Studio* solution file:C:\Path\to\protobuf\cmake\build>mkdir solution & cd solutionC:\Path\to\protobuf\cmake\build\solution>cmake -G "Visual Studio 16 2019" ^-DCMAKE_INSTALL_PREFIX=../../../../install ^../..

It will generate Visual Studio solution file protobuf.sln in current directory.

If the gmock directory does not exist, and you do not want to build protobuf unit tests,
you need to add cmake command argument -Dprotobuf_BUILD_TESTS=OFF to disable testing.

To make a Visual Studio file for Visual Studio 16 2019, create the Visual Studio
solution file above and edit the CMakeCache file.

C:Path\to\protobuf\cmake\build\solution\CMakeCache

Then create the Visual Studio solution file again

Compiling

To compile protobuf:

 C:\Path\to\protobuf\cmake\build\release>nmake

or

  C:\Path\to\protobuf\cmake\build\debug>nmake

And wait for the compilation to finish.

If you prefer to use the IDE:

• Open the generated protobuf.sln file in Microsoft Visual Studio.
• Choose “Debug” or “Release” configuration as desired.
• From the Build menu, choose “Build Solution”.

And wait for the compilation to finish.

Testing

To run unit-tests, first you must compile protobuf as described above.
Then run:

 C:\Path\to\protobuf\cmake\build\release>nmake check

or

 C:\Path\to\protobuf\cmake\build\debug>nmake check

You can also build project check from Visual Studio solution.
Yes, it may sound strange, but it works.

You should see output similar to:

 Running main() from gmock_main.cc[==========] Running 1546 tests from 165 test cases....[==========] 1546 tests from 165 test cases ran. (2529 ms total)[  PASSED  ] 1546 tests.

To run specific tests:

 C:\Path\to\protobuf>cmake\build\release\tests.exe --gtest_filter=AnyTest*Running main() from gmock_main.ccNote: Google Test filter = AnyTest*[==========] Running 3 tests from 1 test case.[----------] Global test environment set-up.[----------] 3 tests from AnyTest[ RUN      ] AnyTest.TestPackAndUnpack[       OK ] AnyTest.TestPackAndUnpack (0 ms)[ RUN      ] AnyTest.TestPackAndUnpackAny[       OK ] AnyTest.TestPackAndUnpackAny (0 ms)[ RUN      ] AnyTest.TestIs[       OK ] AnyTest.TestIs (0 ms)[----------] 3 tests from AnyTest (1 ms total)[----------] Global test environment tear-down[==========] 3 tests from 1 test case ran. (2 ms total)[  PASSED  ] 3 tests.

Note that the tests must be run from the source folder.

If all tests are passed, safely continue.

Installing

To install protobuf to the specified install folder:

 C:\Path\to\protobuf\cmake\build\release>nmake install

or

 C:\Path\to\protobuf\cmake\build\debug>nmake install

You can also build project INSTALL from Visual Studio solution.
It sounds not so strange and it works.

This will create the following folders under the install location:

• bin - that contains protobuf protoc.exe compiler;
• include - that contains C++ headers and protobuf *.proto files;
• lib - that contains linking libraries and CMake configuration files for protobuf package.

Now you can if needed:

• Copy the contents of the include directory to wherever you want to put headers.
• Copy protoc.exe wherever you put build tools (probably somewhere in your PATH).
• Copy linking libraries libprotobuf[d].lib, libprotobuf-lite[d].lib, and libprotoc[d].lib wherever you put libraries.

To avoid conflicts between the MSVC debug and release runtime libraries, when
compiling a debug build of your application, you may need to link against a
debug build of libprotobufd.lib with “d” postfix. Similarly, release builds should link against
release libprotobuf.lib library.

DLLs vs. static linking

默认的编译是编译静态库，如果要编译动态库，需要添加 -Dprotobuf_BUILD_SHARED_LIBS=ON

Static linking is now the default for the Protocol Buffer libraries. Due to
issues with Win32’s use of a separate heap for each DLL, as well as binary
compatibility issues between different versions of MSVC’s STL library, it is
recommended that you use static linkage only. However, it is possible to
build libprotobuf and libprotoc as DLLs if you really want. To do this,
do the following:

• Add an additional flag -Dprotobuf_BUILD_SHARED_LIBS=ON when invoking cmake
• Follow the same steps as described in the above section.
• When compiling your project, make sure to #define PROTOBUF_USE_DLLS.

When distributing your software to end users, we strongly recommend that you
do NOT install libprotobuf.dll or libprotoc.dll to any shared location.
Instead, keep these libraries next to your binaries, in your application’s
own install directory. C++ makes it very difficult to maintain binary
compatibility between releases, so it is likely that future versions of these
libraries will not be usable as drop-in replacements.

If your project is itself a DLL intended for use by third-party software, we
recommend that you do NOT expose protocol buffer objects in your library’s
public interface, and that you statically link protocol buffers into your
library.

ZLib support

If you want to include GzipInputStream and GzipOutputStream
(google/protobuf/io/gzip_stream.h) in libprotobuf, you will need to do a few
additional steps.

Obtain a copy of the zlib library. The pre-compiled DLL at zlib.net works.
You need prepare it:

• Make sure zlib’s two headers are in your C:\Path\to\install\include path
• Make sure zlib’s linking libraries (*.lib file) is in your
  C:\Path\to\install\lib library path.

You can also compile it from source by yourself.

Getting sources:

 C:\Path\to>git clone -b v1.2.8 https://github.com/madler/zlib.gitC:\Path\to>cd zlib

Compiling and Installing:

 C:\Path\to\zlib>mkdir build & cd buildC:\Path\to\zlib\build>mkdir release & cd releaseC:\Path\to\zlib\build\release>cmake -G "NMake Makefiles" -DCMAKE_BUILD_TYPE=Release ^-DCMAKE_INSTALL_PREFIX=../../../install ../..C:\Path\to\zlib\build\release>nmake & nmake install

You can make debug version or use Visual Studio generator also as before for the
protobuf project.

Now add bin folder from install to system PATH:

 C:\Path\to>set PATH=%PATH%;C:\Path\to\install\bin

You need reconfigure protobuf with flag -Dprotobuf_WITH_ZLIB=ON when invoking cmake.

Note that if you have compiled ZLIB yourself, as stated above,
further disable the option -Dprotobuf_MSVC_STATIC_RUNTIME=OFF.

If it reports NOTFOUND for zlib_include or zlib_lib, you might haven’t put
the headers or the .lib file in the right directory.

If you already have ZLIB library and headers at some other location on your system then alternatively you can define following configuration flags to locate them:

-DZLIB_INCLUDE_DIR=<path to dir containing zlib headers>
-DZLIB_LIB=<path to dir containing zlib>

Build and testing protobuf as usual.

Notes on Compiler Warnings

The following warnings have been disabled while building the protobuf libraries
and compiler. You may have to disable some of them in your own project as
well, or live with them.

• C4018 - ‘expression’ : signed/unsigned mismatch
• C4146 - unary minus operator applied to unsigned type, result still unsigned
• C4244 - Conversion from ‘type1’ to ‘type2’, possible loss of data.
• C4251 - ‘identifier’ : class ‘type’ needs to have dll-interface to be used by
  clients of class ‘type2’
• C4267 - Conversion from ‘size_t’ to ‘type’, possible loss of data.
• C4305 - ‘identifier’ : truncation from ‘type1’ to ‘type2’
• C4355 - ‘this’ : used in base member initializer list
• C4800 - ‘type’ : forcing value to bool ‘true’ or ‘false’ (performance warning)
• C4996 - ‘function’: was declared deprecated

C4251 is of particular note, if you are compiling the Protocol Buffer library
as a DLL (see previous section). The protocol buffer library uses templates in
its public interfaces. MSVC does not provide any reasonable way to export
template classes from a DLL. However, in practice, it appears that exporting
templates is not necessary anyway. Since the complete definition of any
template is available in the header files, anyone importing the DLL will just
end up compiling instances of the templates into their own binary. The
Protocol Buffer implementation does not rely on static template members being
unique, so there should be no problem with this, but MSVC prints warning
nevertheless. So, we disable it. Unfortunately, this warning will also be
produced when compiling code which merely uses protocol buffers, meaning you
may have to disable it in your code too.

编译完成，如图：（x64 debug without zlib 版本）

下一篇，开始使用protobuf~~
