Flink DataStream API 介绍

StreamExecutionEnvironment

DataStram数据源

Datastream 基本数据源

//从给定的数据元素中转换
DatastreamSource<OUT> fromElements(OUT... data)
//从指定的集合中转换成DataStream
DatastreamSource<OUT> flomCollection(Collection<OUT> data)
//读取文件并转换
DataStreamSource<OUT> readFile(FileInputFormat<OUT> inputFormat, String filePath)
//从Scocket端口中读取
DataStreamSource<String> socketTextStream(String hostname, int port, String delimiter)
//直接通过InputFormat创建
DataStreamSource<OUT> createInput(InputFormat<OUT, ?> inputFormat)

最终都是通过 ExecutionEnvironment 创建 fromSource() 方法转换成DataStreamSource

Datastream 数据源连接器

Flink 内置 Connector:

Apache Kafka (source/sink)
Apache Cassandra (Sink)
Amazon Kinesis Streams (source/sink)
Elasticsearch(Sink)
Hadoop FileSystem (sink)
RabbitMQ (source/sink)
Apache NiFi (source/sink)
Twitter Streaming API (source)
Google PubSub (source/sink)
JDBC (sinkJ

Apache Bahir 项目 :

Apache ActiveMQ (source/sink)
Apache Flume (sink)
Redis (sink)
Akka (sink)
Netty (source)

以Kafka 连接器为例 :

<dependency><groupld>org.apache.flink</groupld><artifactId>flink-connector-kafka_2.11</artifactId><version>1.11.0</version>
</dependency>

Datastream 数据源连接器 - Source

Properties properties = new Properties();
properties.setProperty("bootstrap.servers", "localhost:9092);
properties.setProperty("group.id", "test0");Datastream<String> stream = env.addSource(new FlinkKafkaConsumer<>("topic",new SimpleStringSchema(), properties));

Datastream 数据源连接器

以Kafka 连接器为例 :

Map<KafkaTopicPartition, Long> specificStartOffsets = new HashMap<>();specificStartOffsets.put(new KafkaTopicPartition(“myTopic“, 0), 23L);
specificStartOffsets.put(new KafkaTopicPartition(“myTopic“, 1), 31L);
specificStartOffsets.put(new KafkaTopicPartition(“myTopic“, 2), 43L);myConsumer.setStartFromSpecificOffsets(specificstartOffsets);

Datastream 数据源连接器 - Sink

Datastream<string> stream = …Properties properties = new Properties();
properties.setpProperty("bootstrap.servers", "localhost:9092");FlinkKafkaProducer<String> myProducer = new FlinkKafkaProducer<>("my-topic",//target topic
new SimpleStringSchema(), // serialization schema
properties, // producer config
FlinkKafkaProducer.Semantic.EXACTLY_ONCE); // fault-tolerance
stream.addsSink(myProducer);

Datastream 主要转换操作

在这里插入图片描述

理解Keyedstream

在这里插入图片描述

Datastream 之间的转换

在这里插入图片描述

物理分组操作

类型	描述
dataStream.global();	全部发往第1个task
dataStream.broadcast();	广播
dataStream.forward();	上下游并发度一样时一对一发送
dataStream.shuffle();	随机均匀分配
dataStream.rebalance();	Round-Robin(轮流分配)
dataStream.recale();	Local Round-Robin(本地轮流分配)
dataStream.partitionCustom();	自定义单播

public DataStream<T> shuffle(){return setConnectionType(new ShufflePartitioner<T>());
}

DataStream Kafka 实例

public class KafkaExample{public static void main(String[] args) throws Exception {// parse inputarg umenltsfinal ParameterTool parameterTool = ParameterTooLfromArgs(args);StreamExecutionEnvironment env = StreamExecutionEnvironment.getExecutionEnvironment();env.getConfig().setRestartStrategy(RestartStrategies.fixedDelayRestart(4, 10000));env.enableCheckpointing(5000); // create a checkpoint every 5 secondsenv.getConfig().setGlobalobParameters(parameterTool); // make parameters available in the web interfaceenv.setStreamTimeCharacteristic(TimeCharacteristic.EventTime);DataStream<kafkaEvent> input = env.addSource(new FlinkKafKaConsumer<>(parameterTool.getRedquired("input-topic"),new KafkaEventSchema(),parameterTool.getPropelties()).assignTimestampsAndWatermarks(new CustomWatermarkExtractor())).keyBy("word").map(new RollingAdditionMapper()).shuffle();input.addSink(new FlinKafkaProduCer<>(parameterTool.getRequired("output-topic"),new KeyedSerializationSchemaWrapper<>(new KafKaEventSChema()),parameterTool.getProperties(),FlinkKafkaProducer.Semantic.EXACTLY_ONCE));env.execute("Modern Kafka ExamPle");}
}
