TreeView控件与SQL数据库的应用(遍历算法)

开发环境：WinXP SP3，VS2008，SQL2000

TreeView控件与SQL数据库的应用(遍历算法)

(数据与TreeView的绑定及Treeview的增加、删除、修改、遍历等数据库的操作)

这个是数据库连接及一些操作数据库的方法，文件：SqlManager.cs

 using  System;
 using  System.Collections.Generic;
 using  System.Linq;
 using  System.Text;
 using  System.Data.SqlClient;
 using  System.Data;
 using  System.Windows.Forms;

 namespace  TreeViewText
{
 class  SqlManager
 {
 SqlConnection conn;
 string  strConn;

 public  SqlManager()
 {
 strConn  =   @" Data Source = .;Initial Catalog = TreeView; Integrated Security = SSPI; Persist Security Info = False; User ID = sa; Password = sa " ;
 conn  =   new  SqlConnection(strConn);
 }

 public  DataSet GetDataSet()
 {
 DataSet ds  =   new  DataSet();
 SqlDataAdapter sda  =   new  SqlDataAdapter(querySqlCmd, conn);
 try
 {
 conn.Open();
 sda.Fill(ds);
 }
 catch  (Exception ex)
 {
 MessageBox.Show(ex.Message,  " 获取数据失败！ " );
 }
 finally
 {
 if  (conn.State  ==  ConnectionState.Open)
 {
 conn.Close();
 }
 }
 return  ds;
 }

 public  DataSet GetDataSet( string  sqlCmd)
 {
 DataSet ds  =   new  DataSet();
 SqlDataAdapter da  =   new  SqlDataAdapter(sqlCmd, conn);
 try
 {
 conn.Open();
 da.Fill(ds);
 }
 catch  (Exception ex)
 {
 MessageBox.Show(ex.Message,  " 获取数据失败！ " );
 }
 finally
 {
 if  (conn.State  ==  ConnectionState.Open)
 {
 conn.Close();
 }
 }
 return  ds;
 }

 public   void  RunSqlCommand( string  sqlCmd)
 {
 SqlCommand cmd  =   new  SqlCommand(sqlCmd, conn);
 try
 {
 conn.Open();
 cmd.ExecuteNonQuery();
 }
 catch  (Exception ex)
 {
 MessageBox.Show(ex.Message,  " 操作数据库失败！ " );
 }
 finally
 {
 if  (conn.State  ==  ConnectionState.Open)
 {
 conn.Close();
 }
 }
 }

 private   string  m_querySqlCmd;
 #region  获取SQL语句
 public   string  querySqlCmd
 {
 get
 {
 if  (m_querySqlCmd  ==   null )
 {
 return   " select * from TreeNode " ;
 }
 return  querySqlCmd;
 }
 set
 {
 m_querySqlCmd  =  value;
 }
 }
 #endregion
 }
}

主窗体：Form1.cs

 using  System;
 using  System.Collections.Generic;
 using  System.ComponentModel;
 using  System.Data;
 using  System.Drawing;
 using  System.Linq;
 using  System.Text;
 using  System.Windows.Forms;
 using  System.Data.SqlClient;

 namespace  TreeViewText
{
 public   partial   class  Form1 : Form
 {
 public  Form1()
 {
 InitializeComponent();
 }

 private   void  Form1_Load( object  sender, EventArgs e)
 {
 // TreeNode treeNode1 = new TreeNode("节点1", new TreeNode[] { treeNode4, treeNode5 });
 // treeView1.Nodes.AddRange(new TreeNode[] { treeNode1 });
  }

 #region  TreeView节点编辑(没有修改数据库)
 private   void  btnEdit_Click( object  sender, EventArgs e)
 {
 if  (treeView1.SelectedNode  !=   null )
 if  ( ! treeView1.SelectedNode.IsEditing)
 treeView1.SelectedNode.BeginEdit();
 }

 private   void  btnDelete_Click( object  sender, EventArgs e)
 {
 if  (treeView1.SelectedNode  !=   null )
 treeView1.SelectedNode.Remove();
 }

 private   void  btnAddNode_Click( object  sender, EventArgs e)
 {
 TreeNode treeNodeTemp  =   new  TreeNode(GetNodeText());
 if  (treeView1.Nodes.Count  >   0 )
 {
 if  (treeView1.SelectedNode  !=   null )
 {
 if  (treeView1.SelectedNode.Parent  !=   null )
 treeView1.SelectedNode.Parent.Nodes.Add(treeNodeTemp);
 else
 treeView1.Nodes.Add(treeNodeTemp);
 }
 }
 else
 {
 treeView1.Nodes.Add(treeNodeTemp);
 }
 }

 private   void  btnAddChild_Click( object  sender, EventArgs e)
 {
 TreeNode treeNodeTemp  =   new  TreeNode(GetNodeText());
 if  (treeView1.SelectedNode  !=   null )
 {
 treeView1.SelectedNode.Nodes.Add(treeNodeTemp);
 }
 }

 #region  获取文本框文本信息
 ///   <summary>
 ///  获取文本框文本信息
 ///   </summary>
 ///   <returns> string </returns>
   private   string  GetNodeText()
 {
 if  ( ! String.IsNullOrEmpty(tbNodeName.Text.Trim()))
 return  tbNodeName.Text.Trim();
 return   " TreeNode " ;
 }
 #endregion
 #endregion

 ///   <summary>
 ///  查询数据
 ///   </summary>
 ///   <param name="sender"></param>
 ///   <param name="e"></param>
   private   void  btnQuery_Click( object  sender, EventArgs e)
 {
 SqlManager sqlManager  =   new  SqlManager();
 dataGridView1.DataSource  =  sqlManager.GetDataSet(sqlManager.querySqlCmd).Tables[ 0 ];
 // 清空TreeView的内容
  treeView1.Nodes.Clear();
 // 递归函数，0为根节点的父节点ParentID的值
  AddTreeView( 0 , (TreeNode) null );

 // 非递归(两层分类显示)
 // ShowTreeView((TreeNode)null);

 // 展开所有树节点
 // treeView1.Expand();
  }
 ///   <summary>
 ///  退出程序
 ///   </summary>
 ///   <param name="sender"></param>
 ///   <param name="e"></param>
   private   void  btnExit_Click( object  sender, EventArgs e)
 {
 this .Close();
 }

 #region  获得数据库信息放入TreeView中 (递归)
 private   void  AddTreeView( int  ParentID, TreeNode parentNode)
 {
 SqlManager sqlManager  =   new  SqlManager();
 DataView dataTree  =   new  DataView(sqlManager.GetDataSet().Tables[ 0 ]);
 string  filter  =   " ParentID =  "   +  ParentID;
 dataTree.RowFilter  =  filter;
 foreach  (DataRowView row  in  dataTree)
 {
 TreeNode node  =   new  TreeNode();
 // 处理根节点
   if  (parentNode  ==   null )
 {
 node.Name  =  row[ " ID " ].ToString();
 node.Text  =  row[ " Name " ].ToString();
 treeView1.Nodes.Add(node);
 AddTreeView(Int32.Parse(row[ " ID " ].ToString().Trim()), node);
 }
 // 处理子节点
   else
 {
 node.Name  =  row[ " ID " ].ToString();
 node.Text  =  row[ " Name " ].ToString();
 parentNode.Nodes.Add(node);
 AddTreeView(Int32.Parse(row[ " ID " ].ToString().Trim()), node);
 }
 }
 }
 #endregion

 #region  获得数据库信息放入TreeView中 (非递归函数，根据Category来分类，仅支持两层分类)
 /* private void ShowTreeView(TreeNode pNode)
 {
 treeView1.Nodes.Clear();
 SqlManager sqlManager = new SqlManager();
 DataView dataTree = new DataView(sqlManager.GetDataSet("select distinct Category from TreeNode").Tables[0]);
 foreach (DataRowView row in dataTree)
 {
 TreeNode node = new TreeNode();
 node.Text = row["Category"].ToString();
 treeView1.Nodes.Add(node);
 CreateChildNodes(node);
 }
 }
 //获取第二层节点的的数据
 private void CreateChildNodes(TreeNode treenode)
 {
 SqlManager sqlManager = new SqlManager();
 DataView dataTree = new DataView(sqlManager.GetDataSet().Tables[0]);
 dataTree.RowFilter = "Category = '" + treenode.Text + "'";
 foreach (DataRowView row in dataTree)
 {
 TreeNode node = new TreeNode();
 node.Text = row["Name"].ToString();
 treenode.Nodes.Add(node);
 }
 } */
 #endregion

 ///   <summary>
 ///  添加记录
 ///   </summary>
 ///   <param name="sender"></param>
 ///   <param name="e"></param>
   private   void  btnAdd_Click( object  sender, EventArgs e)
 {
 SqlManager sqlManager  =   new  SqlManager();
 string  insertSqlCmd  =  String.Empty;
 if  (TextBoxValidator(tbParentID))
 {
 MessageBox.Show( " 请输入ParentID(父节点) " ,  " 提示 " );
 tbParentID.Focus();
 }
 else   if  (TextBoxValidator(tbName))
 {
 MessageBox.Show( " 请输入Name(物品名称) " ,  " 提示 " );
 tbName.Focus();
 }
 else   if  (TextBoxValidator(tbCategory))
 {
 MessageBox.Show( " 请输入Category(物品类别) " ,  " 提示 " );
 tbCategory.Focus();
 }
 else
 {
 insertSqlCmd  =   " insert into TreeNode (ParentID,Name,Category) values ( "   +  tbParentID.Text.Trim()  +   " ,' "   +  tbName.Text.Trim()  +   " ',' "   +  tbCategory.Text.Trim()  +   " '); " ;
 sqlManager.RunSqlCommand(insertSqlCmd);
 dataGridView1.DataSource  =  sqlManager.GetDataSet(sqlManager.querySqlCmd).Tables[ 0 ];
 treeView1.Nodes.Clear();
 AddTreeView( 0 , (TreeNode) null );
 // treeView1.ExpandAll();
  }
 }

 ///   <summary>
 ///  修改记录
 ///   </summary>
 ///   <param name="sender"></param>
 ///   <param name="e"></param>
   private   void  btnModify_Click( object  sender, EventArgs e)
 {
 SqlManager sqlManager  =   new  SqlManager();
 string  updateSqlCmd  =  String.Empty;
 if  (TextBoxValidator(tbID))
 MessageBox.Show( " 请先选择一个产品 " ,  " 提示 " );
 else   if  (TextBoxValidator(tbParentID))
 {
 MessageBox.Show( " 请输入ParentID(父节点) " ,  " 提示 " );
 tbParentID.Focus();
 }
 else   if  (tbID.Text.Trim()  ==  tbParentID.Text.Trim())
 {
 MessageBox.Show( " ID(产品ID)不能与ParentID(父节点)相同，请重新输入 " ,  " 提示 " );
 tbParentID.Focus();
 }
 else   if  (TextBoxValidator(tbName))
 {
 MessageBox.Show( " 请输入Name(物品名称) " ,  " 提示 " );
 tbName.Focus();
 }
 else   if  (TextBoxValidator(tbCategory))
 {
 MessageBox.Show( " 请输入Category(物品类别) " ,  " 提示 " );
 tbCategory.Focus();
 }
 else
 {
 updateSqlCmd  =   " update TreeNode set ParentID =  "   +  tbParentID.Text.Trim()  +   " ,Name = ' "   +  tbName.Text.Trim()  +   " ',Category = ' "   +  tbCategory.Text.Trim()  +   " ' where ID =  "   +  tbID.Text.Trim()  +   " ; " ;
 sqlManager.RunSqlCommand(updateSqlCmd);
 dataGridView1.DataSource  =  sqlManager.GetDataSet(sqlManager.querySqlCmd).Tables[ 0 ];
 treeView1.Nodes.Clear();
 AddTreeView( 0 , (TreeNode) null );
 // treeView1.ExpandAll();
  }
 }

 ///   <summary>
 ///  删除记录
 ///   </summary>
 ///   <param name="sender"></param>
 ///   <param name="e"></param>
   private   void  btnRemove_Click( object  sender, EventArgs e)
 {
 if  (treeView1.SelectedNode  !=   null )
 {
 TreeNode node  =  treeView1.SelectedNode;
 // 删除所选节点及其所有子节点
  DeleteTreeNode(node);
 SqlManager sqlManager  =   new  SqlManager();
 dataGridView1.DataSource  =  sqlManager.GetDataSet(sqlManager.querySqlCmd).Tables[ 0 ];
 }
 }

 ///   <summary>
 ///  删除所选节点及其所有子节点 (通过遍历节点删除对应的数据库数据)
 ///   </summary>
 ///   <param name="parentNode"></param>
   private   void  DeleteTreeNode(TreeNode parentNode)
 {
 /* **************方法一：删除选中节点及其所有子节点************** */
 int  childCount  =  parentNode.Nodes.Count;
 for  ( int  i  =   0 ; i  <  childCount; i ++ )
 {
 TreeNode childNode  =  parentNode.Nodes[ 0 ];
 if  (childNode.Nodes.Count  >   0 )
 {
 DeleteTreeNode(childNode);
 }
 else
 {
 DeleteNodeData(childNode);
 childNode.Remove();
 }
 }
 if  (parentNode.Nodes.Count  ==   0 )
 {
 DeleteNodeData(parentNode);
 parentNode.Remove();
 }

 /* **************方法二：删除选中节点及其所有子节点************** */
 // TreeNodeCollection treeNodeCollection = parentNode.Nodes;
 // int count = treeNodeCollection.Count;
 // for (int i = 0; i < count; i++)
 // {
 //  TreeNode node = treeNodeCollection[0];
 //  if (node.Nodes.Count > 0)
 //  {
 //  DeleteTreeNode(node);
 //  }
 //  else
 //  {
 //  DeleteNodeData(node);
 //  node.Remove();
 //  }
 // }
 // if (treeNodeCollection.Count == 0)
 // {
 //  DeleteNodeData(parentNode);
 //  parentNode.Remove();
 // }
  }
 ///   <summary>
 ///  方法三：删除选中节点的所有子节点（选中的主节点不会被删除）
 ///   </summary>
 ///   <param name="parentNode"></param>
   private   void  DeleteTreeNodeWithoutPareNode(TreeNode parentNode)
 {
 int  count  =  parentNode.Nodes.Count;
 for  ( int  i  =   0 ; i  <  count; i ++ )
 {
 TreeNode node  =  parentNode.Nodes[ 0 ];
 DeleteTreeNodeWithoutPareNode(node);
 DeleteNodeData(node);
 node.Remove();
 }
 }

 ///   <summary>
 ///  将要删除的节点传给该函数，利用节点的Name属性(ID)删除数据库数据
 ///   </summary>
 ///   <param name="node"></param>
   private   void  DeleteNodeData(TreeNode node)
 {
 SqlManager sqlManager  =   new  SqlManager();
 string  deleteSqlCmd  =  String.Empty;
 deleteSqlCmd  =   " delete from TreeNode where ID =  "   +  node.Name;
 sqlManager.RunSqlCommand(deleteSqlCmd);
 }

 ///   <summary>
 ///  检查TextBox的Text属性是否为空或没有字符
 ///   </summary>
 ///   <param name="sender"></param>
 ///   <returns> true/false </returns>
   private   bool  TextBoxValidator( object  sender)
 {
 if  (String.IsNullOrEmpty(((TextBox)sender).Text))
 return   true ;
 else
 return   false ;
 }

 ///   <summary>
 ///  TreeView中节点选择事件，用来将数据放入TextBox
 ///   </summary>
 ///   <param name="sender"></param>
 ///   <param name="e"></param>
   private   void  treeView1_AfterSelect( object  sender, TreeViewEventArgs e)
 {
 string  treeNodeID  =  treeView1.SelectedNode.Name;
 SqlManager sqlManager  =   new  SqlManager();
 DataTable dt;
 dt  =  sqlManager.GetDataSet( " select * from TreeNode where ID = ' "   +  treeNodeID  +   " ' " ).Tables[ 0 ];
 if  (dt.Rows.Count  >   0 )
 {
 tbID.Text  =  dt.Rows[ 0 ][ " ID " ].ToString();
 tbParentID.Text  =  dt.Rows[ 0 ][ " ParentID " ].ToString();
 tbName.Text  =  dt.Rows[ 0 ][ " Name " ].ToString();
 tbCategory.Text  =  dt.Rows[ 0 ][ " Category " ].ToString();
 }
 }

 private   void  dataGridView1_SelectionChanged( object  sender, EventArgs e)
 {
 if  (dataGridView1.SelectedCells.Count  !=   0 )
 {
 tbID.Text  =  dataGridView1.CurrentRow.Cells[ " ID " ].Value.ToString();
 tbParentID.Text  =  dataGridView1.CurrentRow.Cells[ " ParentID " ].Value.ToString();
 tbName.Text  =  dataGridView1.CurrentRow.Cells[ " Name " ].Value.ToString();
 tbCategory.Text  =  dataGridView1.CurrentRow.Cells[ " Category " ].Value.ToString();
 }
 }

 private   void  展开下一层节点ToolStripMenuItem_Click( object  sender, EventArgs e)
 {
 if  (treeView1.SelectedNode  !=   null )
 {
 treeView1.SelectedNode.Expand();
 }
 }

 private   void  展开所有节点ToolStripMenuItem_Click( object  sender, EventArgs e)
 {
 if  (treeView1.SelectedNode  !=   null )
 {
 treeView1.SelectedNode.ExpandAll();
 }
 }

 private   void  选中节点的所有子节点ToolStripMenuItem_Click( object  sender, EventArgs e)
 {
 if  (treeView1.SelectedNode  !=   null )
 {
 TreeNode node  =  treeView1.SelectedNode;
 // 删除所选节点的所有子节点
  DeleteTreeNodeWithoutPareNode(node);
 SqlManager sqlManager  =   new  SqlManager();
 dataGridView1.DataSource  =  sqlManager.GetDataSet(sqlManager.querySqlCmd).Tables[ 0 ];
 }
 }

 private   void  节点及其所有子节点ToolStripMenuItem_Click( object  sender, EventArgs e)
 {
 btnRemove_Click( null ,  null );
 }

 private   void  treeView1_MouseDown( object  sender, MouseEventArgs e)
 {
 if  (e.Button  ==  MouseButtons.Right)
 {
 TreeNode treenode  =  treeView1.GetNodeAt(e.X, e.Y);
 if  (treenode  !=   null   &&  treenode.Bounds.Contains(e.X, e.Y))
 {
 treeView1.SelectedNode  =  treenode;
 }
 else
 {
 treeView1.SelectedNode  =   null ;
 }
 }
 }
 }
}

 Form1.Designer.cs文件：

namespace TreeViewText
{partial class Form1{/// <summary>/// 必需的设计器变量。/// </summary>private System.ComponentModel.IContainer components = null;/// <summary>/// 清理所有正在使用的资源。/// </summary>/// <param name="disposing">如果应释放托管资源，为 true；否则为 false。</param>protected override void Dispose(bool disposing){if (disposing && (components != null)){components.Dispose();}base.Dispose(disposing);}#region Windows 窗体设计器生成的代码/// <summary>/// 设计器支持所需的方法 - 不要/// 使用代码编辑器修改此方法的内容。/// </summary>private void InitializeComponent(){this.components = new System.ComponentModel.Container();System.Windows.Forms.DataGridViewCellStyle dataGridViewCellStyle1 = new System.Windows.Forms.DataGridViewCellStyle();System.Windows.Forms.DataGridViewCellStyle dataGridViewCellStyle2 = new System.Windows.Forms.DataGridViewCellStyle();System.Windows.Forms.DataGridViewCellStyle dataGridViewCellStyle3 = new System.Windows.Forms.DataGridViewCellStyle();this.treeView1 = new System.Windows.Forms.TreeView();this.contextMenuStrip1 = new System.Windows.Forms.ContextMenuStrip(this.components);this.展开树ToolStripMenuItem = new System.Windows.Forms.ToolStripMenuItem();this.展开所有节点ToolStripMenuItem = new System.Windows.Forms.ToolStripMenuItem();this.删除ToolStripMenuItem = new System.Windows.Forms.ToolStripMenuItem();this.节点ToolStripMenuItem = new System.Windows.Forms.ToolStripMenuItem();this.节点及其所有子节点ToolStripMenuItem = new System.Windows.Forms.ToolStripMenuItem();this.label1 = new System.Windows.Forms.Label();this.btnDelete = new System.Windows.Forms.Button();this.btnAddNode = new System.Windows.Forms.Button();this.btnAddChild = new System.Windows.Forms.Button();this.label2 = new System.Windows.Forms.Label();this.dataGridView1 = new System.Windows.Forms.DataGridView();this.btnQuery = new System.Windows.Forms.Button();this.btnExit = new System.Windows.Forms.Button();this.btnEdit = new System.Windows.Forms.Button();this.tbNodeName = new System.Windows.Forms.TextBox();this.label3 = new System.Windows.Forms.Label();this.btnModify = new System.Windows.Forms.Button();this.btnRemove = new System.Windows.Forms.Button();this.btnAdd = new System.Windows.Forms.Button();this.tbID = new System.Windows.Forms.TextBox();this.tbName = new System.Windows.Forms.TextBox();this.tbCategory = new System.Windows.Forms.TextBox();this.label4 = new System.Windows.Forms.Label();this.label5 = new System.Windows.Forms.Label();this.label6 = new System.Windows.Forms.Label();this.tbParentID = new System.Windows.Forms.TextBox();this.label7 = new System.Windows.Forms.Label();this.panel1 = new System.Windows.Forms.Panel();this.contextMenuStrip1.SuspendLayout();((System.ComponentModel.ISupportInitialize)(this.dataGridView1)).BeginInit();this.panel1.SuspendLayout();this.SuspendLayout();// // treeView1// this.treeView1.ContextMenuStrip = this.contextMenuStrip1;this.treeView1.HideSelection = false;this.treeView1.LabelEdit = true;this.treeView1.Location = new System.Drawing.Point(12, 24);this.treeView1.Name = "treeView1";this.treeView1.Size = new System.Drawing.Size(208, 326);this.treeView1.TabIndex = 0;this.treeView1.AfterSelect += new System.Windows.Forms.TreeViewEventHandler(this.treeView1_AfterSelect);this.treeView1.MouseDown += new System.Windows.Forms.MouseEventHandler(this.treeView1_MouseDown);// // contextMenuStrip1// this.contextMenuStrip1.Items.AddRange(new System.Windows.Forms.ToolStripItem[] {this.展开树ToolStripMenuItem,this.展开所有节点ToolStripMenuItem,this.删除ToolStripMenuItem});this.contextMenuStrip1.Name = "contextMenuStrip1";this.contextMenuStrip1.ShowImageMargin = false;this.contextMenuStrip1.Size = new System.Drawing.Size(130, 70);// // 展开树ToolStripMenuItem// this.展开树ToolStripMenuItem.Name = "展开树ToolStripMenuItem";this.展开树ToolStripMenuItem.Size = new System.Drawing.Size(129, 22);this.展开树ToolStripMenuItem.Text = "展开下一层节点";this.展开树ToolStripMenuItem.Click += new System.EventHandler(this.展开下一层节点ToolStripMenuItem_Click);// // 展开所有节点ToolStripMenuItem// this.展开所有节点ToolStripMenuItem.Name = "展开所有节点ToolStripMenuItem";this.展开所有节点ToolStripMenuItem.Size = new System.Drawing.Size(129, 22);this.展开所有节点ToolStripMenuItem.Text = "展开所有子节点";this.展开所有节点ToolStripMenuItem.Click += new System.EventHandler(this.展开所有节点ToolStripMenuItem_Click);// // 删除ToolStripMenuItem// this.删除ToolStripMenuItem.DropDownItems.AddRange(new System.Windows.Forms.ToolStripItem[] {this.节点ToolStripMenuItem,this.节点及其所有子节点ToolStripMenuItem});this.删除ToolStripMenuItem.Name = "删除ToolStripMenuItem";this.删除ToolStripMenuItem.Size = new System.Drawing.Size(129, 22);this.删除ToolStripMenuItem.Text = "删除节点->";// // 节点ToolStripMenuItem// this.节点ToolStripMenuItem.Name = "节点ToolStripMenuItem";this.节点ToolStripMenuItem.Size = new System.Drawing.Size(202, 22);this.节点ToolStripMenuItem.Text = "选中节点的所有子节点";this.节点ToolStripMenuItem.Click += new System.EventHandler(this.选中节点的所有子节点ToolStripMenuItem_Click);// // 节点及其所有子节点ToolStripMenuItem// this.节点及其所有子节点ToolStripMenuItem.Name = "节点及其所有子节点ToolStripMenuItem";this.节点及其所有子节点ToolStripMenuItem.Size = new System.Drawing.Size(202, 22);this.节点及其所有子节点ToolStripMenuItem.Text = "选中节点及其所有子节点";this.节点及其所有子节点ToolStripMenuItem.Click += new System.EventHandler(this.节点及其所有子节点ToolStripMenuItem_Click);// // label1// this.label1.AutoSize = true;this.label1.Location = new System.Drawing.Point(12, 9);this.label1.Name = "label1";this.label1.Size = new System.Drawing.Size(41, 12);this.label1.TabIndex = 1;this.label1.Text = "节点：";// // btnDelete// this.btnDelete.Enabled = false;this.btnDelete.Location = new System.Drawing.Point(113, 370);this.btnDelete.Name = "btnDelete";this.btnDelete.Size = new System.Drawing.Size(75, 23);this.btnDelete.TabIndex = 16;this.btnDelete.Text = "删除";this.btnDelete.UseVisualStyleBackColor = true;this.btnDelete.Click += new System.EventHandler(this.btnDelete_Click);// // btnAddNode// this.btnAddNode.Location = new System.Drawing.Point(5, 30);this.btnAddNode.Name = "btnAddNode";this.btnAddNode.Size = new System.Drawing.Size(75, 23);this.btnAddNode.TabIndex = 20;this.btnAddNode.Text = "添加根";this.btnAddNode.UseVisualStyleBackColor = true;this.btnAddNode.Click += new System.EventHandler(this.btnAddNode_Click);// // btnAddChild// this.btnAddChild.Location = new System.Drawing.Point(99, 30);this.btnAddChild.Name = "btnAddChild";this.btnAddChild.Size = new System.Drawing.Size(75, 23);this.btnAddChild.TabIndex = 21;this.btnAddChild.Text = "添加子级";this.btnAddChild.UseVisualStyleBackColor = true;this.btnAddChild.Click += new System.EventHandler(this.btnAddChild_Click);// // label2// this.label2.AutoSize = true;this.label2.Location = new System.Drawing.Point(224, 9);this.label2.Name = "label2";this.label2.Size = new System.Drawing.Size(65, 12);this.label2.TabIndex = 7;this.label2.Text = "节点信息：";// // dataGridView1// this.dataGridView1.AllowUserToAddRows = false;this.dataGridView1.AllowUserToDeleteRows = false;this.dataGridView1.Anchor = ((System.Windows.Forms.AnchorStyles)(((System.Windows.Forms.AnchorStyles.Top | System.Windows.Forms.AnchorStyles.Left)| System.Windows.Forms.AnchorStyles.Right)));this.dataGridView1.BackgroundColor = System.Drawing.SystemColors.Window;dataGridViewCellStyle1.Alignment = System.Windows.Forms.DataGridViewContentAlignment.MiddleLeft;dataGridViewCellStyle1.BackColor = System.Drawing.SystemColors.Control;dataGridViewCellStyle1.Font = new System.Drawing.Font("宋体", 9F, System.Drawing.FontStyle.Regular, System.Drawing.GraphicsUnit.Point, ((byte)(134)));dataGridViewCellStyle1.ForeColor = System.Drawing.SystemColors.WindowText;dataGridViewCellStyle1.SelectionBackColor = System.Drawing.SystemColors.Highlight;dataGridViewCellStyle1.SelectionForeColor = System.Drawing.SystemColors.HighlightText;dataGridViewCellStyle1.WrapMode = System.Windows.Forms.DataGridViewTriState.True;this.dataGridView1.ColumnHeadersDefaultCellStyle = dataGridViewCellStyle1;this.dataGridView1.ColumnHeadersHeightSizeMode = System.Windows.Forms.DataGridViewColumnHeadersHeightSizeMode.AutoSize;dataGridViewCellStyle2.Alignment = System.Windows.Forms.DataGridViewContentAlignment.MiddleLeft;dataGridViewCellStyle2.BackColor = System.Drawing.SystemColors.Window;dataGridViewCellStyle2.Font = new System.Drawing.Font("宋体", 9F, System.Drawing.FontStyle.Regular, System.Drawing.GraphicsUnit.Point, ((byte)(134)));dataGridViewCellStyle2.ForeColor = System.Drawing.SystemColors.ControlText;dataGridViewCellStyle2.SelectionBackColor = System.Drawing.SystemColors.Highlight;dataGridViewCellStyle2.SelectionForeColor = System.Drawing.SystemColors.HighlightText;dataGridViewCellStyle2.WrapMode = System.Windows.Forms.DataGridViewTriState.False;this.dataGridView1.DefaultCellStyle = dataGridViewCellStyle2;this.dataGridView1.Location = new System.Drawing.Point(226, 24);this.dataGridView1.Name = "dataGridView1";this.dataGridView1.ReadOnly = true;dataGridViewCellStyle3.Alignment = System.Windows.Forms.DataGridViewContentAlignment.MiddleLeft;dataGridViewCellStyle3.BackColor = System.Drawing.SystemColors.Control;dataGridViewCellStyle3.Font = new System.Drawing.Font("宋体", 9F, System.Drawing.FontStyle.Regular, System.Drawing.GraphicsUnit.Point, ((byte)(134)));dataGridViewCellStyle3.ForeColor = System.Drawing.SystemColors.WindowText;dataGridViewCellStyle3.SelectionBackColor = System.Drawing.SystemColors.Highlight;dataGridViewCellStyle3.SelectionForeColor = System.Drawing.SystemColors.HighlightText;dataGridViewCellStyle3.WrapMode = System.Windows.Forms.DataGridViewTriState.True;this.dataGridView1.RowHeadersDefaultCellStyle = dataGridViewCellStyle3;this.dataGridView1.RowTemplate.Height = 23;this.dataGridView1.Size = new System.Drawing.Size(346, 326);this.dataGridView1.TabIndex = 1;this.dataGridView1.SelectionChanged += new System.EventHandler(this.dataGridView1_SelectionChanged);// // btnQuery// this.btnQuery.Location = new System.Drawing.Point(226, 370);this.btnQuery.Name = "btnQuery";this.btnQuery.Size = new System.Drawing.Size(75, 44);this.btnQuery.TabIndex = 2;this.btnQuery.Text = "查询(&S)";this.btnQuery.UseVisualStyleBackColor = true;this.btnQuery.Click += new System.EventHandler(this.btnQuery_Click);// // btnExit// this.btnExit.Location = new System.Drawing.Point(226, 429);this.btnExit.Name = "btnExit";this.btnExit.Size = new System.Drawing.Size(75, 44);this.btnExit.TabIndex = 3;this.btnExit.Text = "退出(&C)";this.btnExit.UseVisualStyleBackColor = true;this.btnExit.Click += new System.EventHandler(this.btnExit_Click);// // btnEdit// this.btnEdit.Enabled = false;this.btnEdit.Location = new System.Drawing.Point(19, 370);this.btnEdit.Name = "btnEdit";this.btnEdit.Size = new System.Drawing.Size(75, 23);this.btnEdit.TabIndex = 15;this.btnEdit.Text = "编辑";this.btnEdit.UseVisualStyleBackColor = true;this.btnEdit.Click += new System.EventHandler(this.btnEdit_Click);// // tbNodeName// this.tbNodeName.Location = new System.Drawing.Point(74, 3);this.tbNodeName.Name = "tbNodeName";this.tbNodeName.Size = new System.Drawing.Size(100, 21);this.tbNodeName.TabIndex = 19;// // label3// this.label3.AutoSize = true;this.label3.Location = new System.Drawing.Point(3, 6);this.label3.Name = "label3";this.label3.Size = new System.Drawing.Size(65, 12);this.label3.TabIndex = 18;this.label3.Text = "节点名称：";// // btnModify// this.btnModify.Location = new System.Drawing.Point(409, 464);this.btnModify.Name = "btnModify";this.btnModify.Size = new System.Drawing.Size(75, 23);this.btnModify.TabIndex = 13;this.btnModify.Text = "修改(&M)";this.btnModify.UseVisualStyleBackColor = true;this.btnModify.Click += new System.EventHandler(this.btnModify_Click);// // btnRemove// this.btnRemove.Location = new System.Drawing.Point(490, 464);this.btnRemove.Name = "btnRemove";this.btnRemove.Size = new System.Drawing.Size(75, 23);this.btnRemove.TabIndex = 14;this.btnRemove.Text = "删除(&D)";this.btnRemove.UseVisualStyleBackColor = true;this.btnRemove.Click += new System.EventHandler(this.btnRemove_Click);// // btnAdd// this.btnAdd.Location = new System.Drawing.Point(328, 464);this.btnAdd.Name = "btnAdd";this.btnAdd.Size = new System.Drawing.Size(75, 23);this.btnAdd.TabIndex = 12;this.btnAdd.Text = "新增(&A)";this.btnAdd.UseVisualStyleBackColor = true;this.btnAdd.Click += new System.EventHandler(this.btnAdd_Click);// // tbID// this.tbID.Location = new System.Drawing.Point(465, 356);this.tbID.Name = "tbID";this.tbID.ReadOnly = true;this.tbID.Size = new System.Drawing.Size(100, 21);this.tbID.TabIndex = 5;// // tbName// this.tbName.Location = new System.Drawing.Point(465, 410);this.tbName.Name = "tbName";this.tbName.Size = new System.Drawing.Size(100, 21);this.tbName.TabIndex = 9;// // tbCategory// this.tbCategory.Location = new System.Drawing.Point(465, 437);this.tbCategory.Name = "tbCategory";this.tbCategory.Size = new System.Drawing.Size(100, 21);this.tbCategory.TabIndex = 11;// // label4// this.label4.AutoSize = true;this.label4.Location = new System.Drawing.Point(382, 359);this.label4.Name = "label4";this.label4.Size = new System.Drawing.Size(77, 12);this.label4.TabIndex = 4;this.label4.Text = "ID(产品ID)：";// // label5// this.label5.AutoSize = true;this.label5.Location = new System.Drawing.Point(358, 413);this.label5.Name = "label5";this.label5.Size = new System.Drawing.Size(101, 12);this.label5.TabIndex = 8;this.label5.Text = "Name(物品名称)：";// // label6// this.label6.AutoSize = true;this.label6.Location = new System.Drawing.Point(334, 440);this.label6.Name = "label6";this.label6.Size = new System.Drawing.Size(125, 12);this.label6.TabIndex = 10;this.label6.Text = "Category(物品类别)：";// // tbParentID// this.tbParentID.Location = new System.Drawing.Point(465, 383);this.tbParentID.Name = "tbParentID";this.tbParentID.Size = new System.Drawing.Size(100, 21);this.tbParentID.TabIndex = 7;// // label7// this.label7.AutoSize = true;this.label7.Location = new System.Drawing.Point(346, 386);this.label7.Name = "label7";this.label7.Size = new System.Drawing.Size(113, 12);this.label7.TabIndex = 6;this.label7.Text = "ParentID(父节点)：";// // panel1// this.panel1.Controls.Add(this.label3);this.panel1.Controls.Add(this.btnAddNode);this.panel1.Controls.Add(this.btnAddChild);this.panel1.Controls.Add(this.tbNodeName);this.panel1.Enabled = false;this.panel1.Location = new System.Drawing.Point(14, 410);this.panel1.Name = "panel1";this.panel1.Size = new System.Drawing.Size(177, 56);this.panel1.TabIndex = 17;// // Form1// this.AcceptButton = this.btnQuery;this.AutoScaleDimensions = new System.Drawing.SizeF(6F, 12F);this.AutoScaleMode = System.Windows.Forms.AutoScaleMode.Font;this.ClientSize = new System.Drawing.Size(577, 496);this.Controls.Add(this.panel1);this.Controls.Add(this.label6);this.Controls.Add(this.label5);this.Controls.Add(this.label7);this.Controls.Add(this.label4);this.Controls.Add(this.tbCategory);this.Controls.Add(this.tbName);this.Controls.Add(this.tbParentID);this.Controls.Add(this.tbID);this.Controls.Add(this.btnAdd);this.Controls.Add(this.btnRemove);this.Controls.Add(this.btnModify);this.Controls.Add(this.btnEdit);this.Controls.Add(this.btnExit);this.Controls.Add(this.btnQuery);this.Controls.Add(this.dataGridView1);this.Controls.Add(this.label2);this.Controls.Add(this.btnDelete);this.Controls.Add(this.label1);this.Controls.Add(this.treeView1);this.Name = "Form1";this.Text = "TreeViewText by danch744";this.Load += new System.EventHandler(this.Form1_Load);this.contextMenuStrip1.ResumeLayout(false);((System.ComponentModel.ISupportInitialize)(this.dataGridView1)).EndInit();this.panel1.ResumeLayout(false);this.panel1.PerformLayout();this.ResumeLayout(false);this.PerformLayout();}#endregionprivate System.Windows.Forms.TreeView treeView1;private System.Windows.Forms.Label label1;private System.Windows.Forms.Button btnDelete;private System.Windows.Forms.Button btnAddNode;private System.Windows.Forms.Button btnAddChild;private System.Windows.Forms.Label label2;private System.Windows.Forms.DataGridView dataGridView1;private System.Windows.Forms.Button btnQuery;private System.Windows.Forms.Button btnExit;private System.Windows.Forms.Button btnEdit;private System.Windows.Forms.TextBox tbNodeName;private System.Windows.Forms.Label label3;private System.Windows.Forms.Button btnModify;private System.Windows.Forms.Button btnRemove;private System.Windows.Forms.Button btnAdd;private System.Windows.Forms.TextBox tbID;private System.Windows.Forms.TextBox tbName;private System.Windows.Forms.TextBox tbCategory;private System.Windows.Forms.Label label4;private System.Windows.Forms.Label label5;private System.Windows.Forms.Label label6;private System.Windows.Forms.TextBox tbParentID;private System.Windows.Forms.Label label7;private System.Windows.Forms.Panel panel1;private System.Windows.Forms.ContextMenuStrip contextMenuStrip1;private System.Windows.Forms.ToolStripMenuItem 展开树ToolStripMenuItem;private System.Windows.Forms.ToolStripMenuItem 节点ToolStripMenuItem;private System.Windows.Forms.ToolStripMenuItem 节点及其所有子节点ToolStripMenuItem;private System.Windows.Forms.ToolStripMenuItem 删除ToolStripMenuItem;private System.Windows.Forms.ToolStripMenuItem 展开所有节点ToolStripMenuItem;}
}

点上面的那个图标显示代码。另外说一下，数据库的定义就在那张图片那样定义，主键是ID，ID和ParentID都是int,其余两个都是nvarchar，数据库名：TreeView，表为TreeNode，具体可以从代码看出来。

要源代码及数据库的朋友请留下邮箱，第一次在博客园发帖，还请各位高手指点迷津，虚心接受批评。。。
