JAVA_树状表格分页(layUI、treeTable.js)

效果图展示(PS:本人很懒，刚开始想在网上随意找一个就用，后来发现好像PHP的不少，JAVA的树状表格大多数跟我开始写的一样没有分页，导致数据量过大后加载过于缓慢被客户吐糟，最后没找到合适的就自己写了一个简单的demo，不嫌弃的话可以自己再改改样式)

准备：layUI、treeTable.js

代码展示：

<input id="total" type="hidden" value="${total }"><table class="layui-table layui-form" id="tree-table" lay-size="sm"></table><div id="pageDemo"></div><script type="text/javascript">$(function(){$.ajax({url :'tSDepartController.do?getDataNew',data : {'curr' : 1,'limit' : 10},type : 'post',dataType : 'json',success : function(data){test(data);}})            })function test(data){layui.config({base: 'plug-in/test/',})layui.use(['laypage', 'treeTable', 'layer', 'code', 'form'],function(){var o = layui.$,form = layui.form,laypage = layui.laypage,layer = layui.layer,treeTable = layui.treeTable;var	re = treeTable.render({elem: '#tree-table',data: data,icon_key: 'departname',is_checkbox: true,end: function(e){form.render();},cols: [{key: 'departname',title: '机构名称',width: '1500px',align: 'left',},{key: 'description',title: '机构描述',width: '1000px',align: 'center',},{key: 'parentdepartid',title: '父ID',width: '100px',align: 'left',},{key: 'orgCode',title: '机构编码',width: '100px',align: 'center',},{key: 'orgType',title: '机构类型',width: '100px',align: 'center',},{key: 'mobile',title: '电话',width: '300px',align: 'center',},{key: 'fax',title: '传真',width: '300px',align: 'center',},{key: 'address',title: '地址',width: '1000px',align: 'left',},{title: '标记',width: '100px',align: 'center',template: function(item){return '<input type="checkbox" name="close" lay-skin="switch" lay-text="ON|OFF">';}}]});// 监听checkbox选择treeTable.on('tree(box)',function(data){layer.msg(JSON.stringify(data));})});}layui.use(['laypage', 'layer'],function(){var laypage = layui.laypage,layer = layui.layer;var total = $('#total').val();//分页laypage.render({elem: 'pageDemo',count: total,limit: 10,skin: '#1E9FFF',layout: ['count', 'prev', 'page', 'next', 'limit', 'skip'],jump: function(obj, first){if(!first){$.ajax({url :'tSDepartController.do?getDataNew',data : {'curr' : obj.curr,'limit' : obj.limit},type : 'post',dataType : 'json',success : function(data){test(data);}});}}});})</script>

@RequestMapping(params = "list")
public ModelAndView list(HttpServletRequest request) {int total = 0;// 一级机构总数// 获取一级机构总数String sql_total = "select count(1) total from t_s_depart where org_type = '1'";List<Map<String, Object>> list_total =  systemService.findForJdbc(sql_total);if(!ListUtils.isNullOrEmpty(list_total)){for (Map<String, Object> map : list_total) {total = Integer.parseInt(map.get("total")==null?"0":map.get("total").toString());}}request.setAttribute("total", total);return new ModelAndView("com/szerp/department/tSDepartListNew");}@RequestMapping(params = "getDataNew")
@ResponseBody
public List<TSDepartEntity> getDataNew(HttpServletRequest request, HttpServletResponse response) throws IOException{int page = request.getParameter("curr")==null?1:Integer.parseInt(request.getParameter("curr").toString());int limit = request.getParameter("limit")==null?1:Integer.parseInt(request.getParameter("limit").toString());// 分页数据String sql_data = "select id,departname,description,parentdepartid,org_code,org_type,mobile,fax,address,depart_order from (select rownum num,d.* from t_s_depart d where d.org_type = '1') where num > "+((page-1)*limit)+" and num <= "+(page*limit);List<Map<String, Object>> list_data = systemService.findForJdbc(sql_data);List<TSDepartEntity> listDepart = new ArrayList<TSDepartEntity>();String ids = "";if(!ListUtils.isNullOrEmpty(list_data)){for (Map<String, Object> map : list_data) {ids = ids + "'" + (map.get("ID")==null?"":map.get("ID").toString()) + "',";TSDepartEntity tSDepart = new TSDepartEntity();tSDepart.setId(map.get("ID")==null?"":map.get("ID").toString());tSDepart.setDepartname(map.get("DEPARTNAME")==null?"":map.get("DEPARTNAME").toString());tSDepart.setDescription(map.get("DESCRIPTION")==null?"":map.get("DESCRIPTION").toString());tSDepart.setParentdepartid(map.get("PARENTDEPARTID")==null?"":map.get("PARENTDEPARTID").toString());tSDepart.setOrgCode(map.get("ORG_CODE")==null?"":map.get("ORG_CODE").toString());tSDepart.setOrgType(map.get("ORG_TYPE")==null?"":map.get("ORG_TYPE").toString());tSDepart.setMobile(map.get("MOBILE")==null?"":map.get("MOBILE").toString());tSDepart.setFax(map.get("FAX")==null?"":map.get("FAX").toString());tSDepart.setAddress(map.get("ADDRESS")==null?"":map.get("ADDRESS").toString());tSDepart.setDepartOrder(map.get("DEPART_ORDER")==null?"":map.get("DEPART_ORDER").toString());listDepart.add(tSDepart);}}ids = "("+ids.substring(0, ids.length()-1)+")";String sql = "select id,departname,description,parentdepartid,org_code,org_type,mobile,fax,address,depart_order from t_s_depart where parentdepartid in"+ids;List<Map<String, Object>> list_data2 = systemService.findForJdbc(sql);if(!ListUtils.isNullOrEmpty(list_data2)){return getNext(listDepart, list_data2, ids);}return listDepart;}public List<TSDepartEntity> getNext(List<TSDepartEntity> listDepart, List<Map<String, Object>> list_data2, String ids){String ids_ = "";for (Map<String, Object> map : list_data2) {ids_ = ids_ + "'" + (map.get("ID")==null?"":map.get("ID").toString()) + "',";TSDepartEntity tSDepart = new TSDepartEntity();tSDepart.setId(map.get("ID")==null?"":map.get("ID").toString());tSDepart.setDepartname(map.get("DEPARTNAME")==null?"":map.get("DEPARTNAME").toString());tSDepart.setDescription(map.get("DESCRIPTION")==null?"":map.get("DESCRIPTION").toString());tSDepart.setParentdepartid(map.get("PARENTDEPARTID")==null?"":map.get("PARENTDEPARTID").toString());tSDepart.setOrgCode(map.get("ORG_CODE")==null?"":map.get("ORG_CODE").toString());tSDepart.setOrgType(map.get("ORG_TYPE")==null?"":map.get("ORG_TYPE").toString());tSDepart.setMobile(map.get("MOBILE")==null?"":map.get("MOBILE").toString());tSDepart.setFax(map.get("FAX")==null?"":map.get("FAX").toString());tSDepart.setAddress(map.get("ADDRESS")==null?"":map.get("ADDRESS").toString());tSDepart.setDepartOrder(map.get("DEPART_ORDER")==null?"":map.get("DEPART_ORDER").toString());listDepart.add(tSDepart);}ids_ = "("+ids_.substring(0, ids_.length()-1)+")";String sql = "select id,departname,description,parentdepartid,org_code,org_type,mobile,fax,address,depart_order from t_s_depart where parentdepartid in"+ids_;List<Map<String, Object>> list = systemService.findForJdbc(sql);if(!ListUtils.isNullOrEmpty(list)){getNext(listDepart, list, ids_);}   return listDepart;}

treeTable.js代码如下：

layui.define(['jquery'], function(exports) {var MOD_NAME = 'treeTable',o = layui.jquery,tree = function() {};tree.prototype.config = function() {return {top_value: 0,primary_key: 'id',parent_key: 'parentdepartid',hide_class: 'layui-hide',icon: {open: 'layui-icon layui-icon-triangle-d',close: 'layui-icon layui-icon-triangle-r',left: 16,},cols: [],checked: {},is_click_icon: false,is_checkbox: false,is_cache: true,};}tree.prototype.template = function(e) {var t = this,level = [],tbody = '',is_table = o('table' + e.elem).length || !(e.is_click_icon = true),checkbox = e.is_checkbox ? '<div class="layui-unselect layui-form-checkbox cbx" lay-skin="primary"><i class="layui-icon layui-icon-ok"></i></div>' : '',checked = checkbox ? checkbox.replace('cbx', 'cbx layui-form-checked') : '',thead = checkbox && '<th style="width:28px;">' + (o.inArray(e.top_value, e.checked.data) > -1 ? checked : checkbox) + '</th>';o.each(t.data(e, e.data), function(idx, item) {var tr = '',is_checked = false,hide_class = (item[e.parent_key] == e.top_value) || (item[e.parent_key] == t.cache(e, item[e.parent_key])) ? '' : e.hide_class;// 设置每行数据层级item.level = level[item[e.primary_key]] = item[e.parent_key] != e.top_value ? (level[item[e.parent_key]] + 1) : 0;// 设置是否为最后一级item.is_end = !e.childs[item[e.primary_key]];o.each(e.cols, function(index, obj) {var style = '';obj.width && (style += 'width:' + obj.width + ';'), obj.align && (style += 'text-align:' + obj.align + ';'), style && (style = 'style="' + style + '"');// 标记设置行checkbox选中if(e.is_checkbox && e.checked && o.inArray(item[e.checked.key], e.checked.data) > -1) {is_checked = true;}// 第一次遍历头部的时候拼接表格头部idx || (thead += '<th ' + style + '>' + obj.title + '</th>');// 指定列加入开启、关闭小图标var icon = (obj.key == e.icon_key && !item.is_end) ? '<i class="' + (t.cache(e, item[e.primary_key]) ? e.icon.open : e.icon.close) + '"></i>' : '<span></span>';// 指定列小图标按照层级向后位移var left = (obj.key == e.icon_key ? level[item[e.primary_key]] * e.icon.left + 'px' : '');icon = icon.replace('>', ' style="margin-left:' + left + ';">');// 拼接行tr += '<td ' + style + (left ? 'data-down' : '') + '>' + icon + (is_table ? '' : (is_checked ? checked : checkbox)) + (obj.template ? obj.template(item) : item[obj.key]) + '</td>';});var box = is_table ? o(is_checked ? checked : checkbox).wrap('<td style="width:28px;">').parent().prop('outerHTML') : '';tbody += '<tr class="' + hide_class + '" data-id="' + item[e.primary_key] + '" data-parentdepartid="' + item[e.parent_key] + '">' + box + tr + '</tr>';});// 处理表树和树的赋值模板var table = is_table ? '<thead><tr data-id="' + e.top_value + '">' + thead + '</tr></thead><tbody>' + tbody + '</tbody>' : tbody.replace(/<tr/g, '<ul').replace(/tr>/g, 'ul>').replace(/<td/g, '<li').replace(/td>/g, 'li>');// 确认点击图标或点击列触发展开关闭var click_btn = e.is_click_icon ? '[data-down] i:not(.layui-icon-ok)' : '[data-down]';// 模板渲染并处理点击展开收起等功能o(e.elem).html(table).off('click', click_btn).on('click', click_btn, function() {var tr = o(this).parents('[data-id]'),td = tr.find('[data-down]'),id = tr.data('id'),parentdepartid = tr.data('parentdepartid'),is_open = (td.find('i:not(.layui-icon-ok)').attr('class') == e.icon.close);if(is_open) {// 展开子级（子级出现、更改图标）td.find('i:not(.layui-icon-ok)').attr('class', e.icon.open);td.parents(e.elem).find('[data-parentdepartid=' + id + ']').removeClass(e.hide_class);t.cache(e, id, true);} else {// 关闭子级（更改图标、隐藏所有子孙级）td.find('i:not(.layui-icon-ok)').attr('class', e.icon.close);t.childs_hide(e, id);}// 设置监听展开关闭layui.event.call(this, MOD_NAME, 'tree(flex)', {elem: this,item: e.childs[parentdepartid][id],table: e.elem,is_open: is_open,})}).off('click', '.cbx').on('click', '.cbx', function() {var is_checked = o(this).toggleClass('layui-form-checked').hasClass('layui-form-checked'),tr = o(this).parents('[data-id]'),id = tr.data('id'),parentdepartid = tr.data('parentdepartid');t.childs_checkbox(e, id, is_checked);t.parents_checkbox(e, parentdepartid);// 设置监听checkbox选择layui.event.call(this, MOD_NAME, 'tree(box)', {elem: this,item: parentdepartid === undefined ? {} : e.childs[parentdepartid][id],table: e.elem,is_checked: is_checked,})}).off('click', '[lay-filter]').on('click', '[lay-filter]', function() {var tr = o(this).parents('[data-id]'),id = tr.data('id'),parentdepartid = tr.data('parentdepartid'),filter = o(this).attr("lay-filter");return layui.event.call(this, MOD_NAME, 'tree(' + filter + ')', {elem: this,item: e.childs[parentdepartid][id],})});e.end && e.end(e);};// 同级全部选中父级选中/同级全部取消取消父级tree.prototype.parents_checkbox = function(e, parentdepartid) {var po = o(e.elem).find('[data-parentdepartid=' + parentdepartid + ']'),co = o(e.elem).find('[data-id=' + parentdepartid + ']'),len = o(e.elem).find('[data-parentdepartid=' + parentdepartid + '] .cbx.layui-form-checked').length;if(po.length == len || len == 0) {var parentdepartid = co.data('parentdepartid');len ? co.find('.cbx').addClass('layui-form-checked') : co.find('.cbx').removeClass('layui-form-checked');parentdepartid === undefined || this.parents_checkbox(e, parentdepartid);}};// 子级反选tree.prototype.childs_checkbox = function(e, id, is_checked) {var t = this;o(e.elem).find('[data-parentdepartid=' + id + ']').each(function() {var checkbox = o(this).find('.cbx');is_checked ? checkbox.addClass('layui-form-checked') : checkbox.removeClass('layui-form-checked');t.childs_checkbox(e, o(this).data('id'), is_checked);})};// 点击收起循环隐藏子级元素tree.prototype.childs_hide = function(e, id) {var t = this;t.cache(e, id, false);o(e.elem).find('[data-parentdepartid=' + id + ']:not(.' + e.hide_class + ')').each(function() {var td = o(this).find('[data-down]'),i = td.find('i:not(.layui-icon-ok)');// 关闭更换小图标i.length && i.attr('class', e.icon.close);// 隐藏子级td.parents(e.elem).find('[data-parentdepartid=' + id + ']').addClass(e.hide_class);t.childs_hide(e, o(this).data('id'))});};// 重新组合数据，父子级关系跟随tree.prototype.data = function(e) {var lists = [],childs = [];o.each(e.data, function(idx, item) {lists[item[e.primary_key]] = item;if(!childs[item[e.parent_key]]) {childs[item[e.parent_key]] = [];}childs[item[e.parent_key]][item[e.primary_key]] = item;});e.childs = childs;return this.tree_data(e, lists, e.top_value, []);};tree.prototype.tree_data = function(e, lists, parentdepartid, data) {var t = this;if(lists[parentdepartid]) {data.push(lists[parentdepartid]);delete lists[parentdepartid]}o.each(e.data, function(index, item) {if(item[e.parent_key] == parentdepartid) {data.concat(t.tree_data(e, lists, item[e.primary_key], data))}});return data;};tree.prototype.render = function(e) {var t = this;e = o.extend(t.config(), e);if(e.url) {o.get(e.url, function(res) {e.data = res;t.template(e);})} else {t.template(e);}return e;};// 获取已选值集合tree.prototype.checked = function(e) {var ids = [];o(e.elem).find('.cbx.layui-form-checked').each(function() {var id = o(this).parents('[data-id]').data('id');ids.push(id);})return ids;};// 全部展开tree.prototype.openAll = function(e) {var t = this;o.each(e.data, function(idx, item) {item[e.primary_key] && t.cache(e, item[e.primary_key], true);})t.render(e);}// 全部关闭tree.prototype.closeAll = function(e) {localStorage.setItem(e.elem.substr(1), '');this.render(e);}tree.prototype.on = function(events, callback) {return layui.onevent.call(this, MOD_NAME, events, callback)};// 存储折叠状态tree.prototype.cache = function(e, val, option) {if(!e.is_cache) {return false;}var t = this,name = e.elem.substr(1),val = val.toString(),cache = localStorage.getItem(name) ? localStorage.getItem(name).split(',') : [],index = o.inArray(val, cache);if(option === undefined) {return index == -1 ? false : val}if(option && index == -1) {cache.push(val)}if(!option && index > -1) {cache.splice(index, 1)}localStorage.setItem(name, cache.join(','));};var tree = new tree();exports(MOD_NAME, tree)
});

更改父级ID字段时，别忘记treeTable.js中也要一同更改哦（以上展示代码为初版demo,若需使用建议优化，还有不要跟我一样不是正式发行版代码就不写备注）
