基于Android Q的蓝牙通话无声问题

分享一下这几天改蓝牙通话无声的bug，文章有点长，希望各位看官看完能帮助到大家—今天分析的主题是蓝牙通话没有声音之运行流程分析

一. 结果说在前面

蓝牙通话分别有七个阶段，基本上每个阶段都会走到底层，把数据回调到上层，这么一个流程叫一个阶段；回调的数据代表一个状态，而我这个问题就在于底层回调数据到上层时，携带的数据不满足上层的要求导致无法进入下一个阶段而产生的蓝牙通话无声问题；

蓝牙通话的七个连接阶段使用的模式是：状态机模式，没弄明白状态机模式之前有点不好入手；我这里分享一下状态机模式的详解文章：状态机模式介绍

二.涉及到的文件/内容

vendor/mediatek/proprietary/packages/apps/Bluetooth/src/com/android/bluetooth/hfp/HeadsetNativeInterface.java
vendor/mediatek/proprietary/packages/apps/Bluetooth/src/com/android/bluetooth/hfp/HeadsetStateMachine.java
vendor/mediatek/proprietary/packages/apps/Bluetooth/src/com/android/bluetooth/hfp/HeadsetService.java
frameworks/base/services/core/java/com/android/server/audio/BtHelper.java

蓝牙服务类别：
HeadsetPro-file（HSP）代表耳机功能，提供手机与耳机之间通信所需的基本功能。
HandProfile（HFP）则代表免提功能，HFP在HSP的基础上增加了某些扩展功能。
Advanced Audio Distribution Profile（A2DP），指的是蓝牙音频传输模型协定。
蓝牙物理链路SCO(Synchronous Connection Oriented)主要用来传输对时间要求很高的数据通信，通常用于通话

三.蓝牙连接状态分析

1.连接状态分析

蓝牙连接步骤分为七个状态，分别是：

Disconnected

该状态为初始化阶段，在蓝牙打开阶段会执行
Connecting

该状态在连接蓝牙时执行
Connected

该状态在蓝牙连接完成后执行
AudioConnecting

该状态在接听电话后执行，处于一个连接中的一个状态，很快就能连接上
AudioOn

该状态在接听电话后，AudioConnecting阶段完成后执行，这个时候通常就能用蓝牙耳机通话了
AudioDiconnecting

该状态在挂断电话后执行，此时又回到了Connected状态，因为蓝牙还是开启的
Disconnecting

该状态在蓝牙断开中执行，执行完成后回到Disconnected该状态

以上就是蓝牙连接到蓝牙断开的七个连接状态，每个状态都继承了状态机，接下来看看每个连接状态的具体方法，具体实现稍后分析

2.状态机方法

每个连接状态都有一个状态模式，都分别继承于HeadsetStateBase和ConnectedBase，它们共同的父父类就是State，先来看一段代码，七个连接状态

2.1 HeadsetStateMachine.java

 // State machine statesprivate final Disconnected mDisconnected = new Disconnected();private final Connecting mConnecting = new Connecting();private final Disconnecting mDisconnecting = new Disconnecting();private final Connected mConnected = new Connected();private final AudioConnecting mAudioConnecting = new AudioConnecting();private final AudioOn mAudioOn = new AudioOn();private final AudioDisconnecting mAudioDisconnecting = new AudioDisconnecting();
... // Initialize state machineaddState(mDisconnected);addState(mConnecting);addState(mDisconnecting);addState(mConnected);addState(mAudioOn);addState(mAudioConnecting);addState(mAudioDisconnecting);setInitialState(mDisconnected);

分别把七个连接阶段加入到状态机中，初始化mDisconnected为默认状态，每个状态机都有四个方法，具体看代码

    class 七个连接状态 extends ConnectedBase 或者 HeadsetStateBase {@Overrideint getAudioStateInt() {...}@Overridepublic void enter() {...}// ... @Overridepublic boolean processMessage(Message message) {...}@Overridepublic void exit() {...}}

这三个方法是每个连接阶段必有的，getAudioStateInt用于一个常量代表当前返回的状态，enter进入该方法，processMessage事件逻辑处理，exit退出当前状态，这四个方法是顺序执行。

3.连接状态具体实现

之前说道基本上每个连接状态都会走到底层拿数据回调上层，这里我们来具体看看，主要分析AudioConnecting阶段，大致分析其他阶段

3.1 Disconnected

 class Disconnected extends HeadsetStateBase {...@Overridepublic boolean processMessage(Message message) {...if (!mNativeInterface.connectHfp(device)) { // 第一步stateLogE("CONNECT failed for connectHfp(" + device + ")");// No state transition is involved, fire broadcast immediatelybroadcastConnectionState(device, BluetoothProfile.STATE_DISCONNECTED,BluetoothProfile.STATE_DISCONNECTED);break;}transitionTo(mConnecting); // 第二步...return HANDLED;}   ...}

很关键的两步，第一步连接之前提到过的HFP服务，调用底层，连接成功后发送广播；第二步状态切换，进入下一步连接状态；这里的返回值一定要是true才行，才能进入exit，HANDLED默认就是true；底层回调：HeadsetNativeInterface.java # private native boolean connectHfpNative(byte[] address);

3.2 Connecting

class Connecting extends HeadsetStateBase {...@Overridepublic void processConnectionEvent(Message message, int state) {switch (state) {...case HeadsetHalConstants.CONNECTION_STATE_SLC_CONNECTED://走了一系列流程后进入该casestateLogD("SLC connected");transitionTo(mConnected);//调用该方法进入下一个阶段break;...}} ...}

这里的processConnectionEvent方法的state值是从HeadsetNativeInterface#onConnectionStateChanged开始调用底层，携带state数据，再回调上层来，接着再根据state来走case是否进入mConnected阶段

每个阶段差不多都是这样的流程，这里就不一一去分析了，直接看AudioConnecting阶段

3.3 AudioConnecting

这个阶段就是我遇到问题的一个阶段，由于state值导致无法进入下一阶段，上代码

     //各阶段常量static final int CONNECT = 1;static final int DISCONNECT = 2;static final int CONNECT_AUDIO = 3;//注意static final int DISCONNECT_AUDIO = 4;class AudioConnecting extends ConnectedBase {@Overrideint getAudioStateInt() {return BluetoothHeadset.STATE_AUDIO_CONNECTING; //记住这段代码，它的值为11}@Overridepublic void enter() {super.enter();sendMessageDelayed(CONNECT_TIMEOUT, mDevice, sConnectTimeoutMs);//发送消息给状态机的SmHandler-设置超时，延时发送和当前状态信息broadcastStateTransitions();//发送广播给BtHleper.java，该方法稍后分析}@Overridepublic boolean processMessage(Message message) {/// M: add log. @{stateLogD("processMessage:" + message.what);///// @}switch (message.what) {//该阶段的msg.what == 3,也就对应case CONNECT_AUDIOcase CONNECT:case DISCONNECT:case CONNECT_AUDIO:case DISCONNECT_AUDIO:deferMessage(message);//把msg放进消息队列break;case CONNECT_TIMEOUT: {//超时处理，我调试时没走该段代码BluetoothDevice device = (BluetoothDevice) message.obj;if (!mDevice.equals(device)) {stateLogW("CONNECT_TIMEOUT for unknown device " + device);break;}stateLogW("CONNECT_TIMEOUT");transitionTo(mConnected);break;}default: //当没有匹配的case时return super.processMessage(message);}return HANDLED;}@Overridepublic void processAudioEvent(int state) {switch (state) {case HeadsetHalConstants.AUDIO_STATE_DISCONNECTED:stateLogW("processAudioEvent: audio connection failed");transitionTo(mConnected);break;case HeadsetHalConstants.AUDIO_STATE_CONNECTING://目前匹配的该条case；常量值：1// ignore, already in audio connecting statebreak;case HeadsetHalConstants.AUDIO_STATE_DISCONNECTING:// ignore, there is no BluetoothHeadset.STATE_AUDIO_DISCONNECTINGbreak;case HeadsetHalConstants.AUDIO_STATE_CONNECTED://如果case走这一步就一切正常，能进行状态切换；常量值：2stateLogI("processAudioEvent: audio connected");transitionTo(mAudioOn);break;default:stateLogE("processAudioEvent: bad state: " + state);break;}}@Overridepublic void exit() {removeMessages(CONNECT_TIMEOUT);super.exit();}}

进入该阶段时，调用processMessage方法，会调用N次，第一次为msg.what == 3是正常的，看log日志后发现还有101的值传过来，该方法里匹配不到则走了default，导致循环调用，最后走到了processAudioEvent，state为1,产生的异常，那么这个101的值代表什么呢？又从哪里进来的？带着这个疑问继续跟踪代码

static final int STACK_EVENT = 101; //看该常量的意思，应该是发送粘性事件

发现它在HeadsetService.java中被调用了，跟着走，上代码

 /*** Handle messages from native (JNI) to Java. This needs to be synchronized to avoid posting* messages to state machine before start() is done** @param stackEvent event from native stack*/void messageFromNative(HeadsetStackEvent stackEvent) {Objects.requireNonNull(stackEvent.device,"Device should never be null, event: " + stackEvent);synchronized (mStateMachines) {HeadsetStateMachine stateMachine = mStateMachines.get(stackEvent.device);if (stackEvent.type == HeadsetStackEvent.EVENT_TYPE_CONNECTION_STATE_CHANGED) {switch (stackEvent.valueInt) {case HeadsetHalConstants.CONNECTION_STATE_CONNECTED:case HeadsetHalConstants.CONNECTION_STATE_CONNECTING: {// Create new state machine if none is foundif (stateMachine == null) {stateMachine = HeadsetObjectsFactory.getInstance().makeStateMachine(stackEvent.device,mStateMachinesThread.getLooper(), this, mAdapterService,mNativeInterface, mSystemInterface);mStateMachines.put(stackEvent.device, stateMachine);}break;}}}if (stateMachine == null) {throw new IllegalStateException("State machine not found for stack event: " + stackEvent);}//101值在这里进行调用了，发送到AudioConnecting阶段stateMachine.sendMessage(HeadsetStateMachine.STACK_EVENT, stackEvent);}}

注意看最开始的官方注释，这是一套JNI代码，说明这里肯定是走了底层；我又有两个疑惑了

走AudioConnecting阶段时，正常的话是不是不会走messageFromNative方法
如果正常的情况也要走该段代码，这个101值是必传给AudioConnecting的，那么是不是传过去后这个101值处理有问题

带着这两个问题，又继续出发，看看messageFromNative是在哪里被调用的，发现在HeadsetNativeInterface.java#sendMessageToService中去调用了，而且不止一处被调用，很多JNI相关的方法都执行了该方法，具体来看看一段截图
在这里插入图片描述以上这些方法都是底层回调数据到上层的方法，这下刚刚的疑惑就得到解决了，那么这个101状态值肯定是必须要走的，期间把event作为传入传递过去了，其中event就包含了state和type信息，记住此时的state为1,type为EVENT_TYPE_AUDIO_STATE_CHANGED，至此源头就找到了，接着回到AudioConnecting连接状态，看如下片段代码

     @Overridepublic boolean processMessage(Message message) {/// M: add log. @{stateLogD("processMessage:" + message.what);// 此时这里的what已经是101了/// @}switch (message.what) {case CONNECT:case DISCONNECT:case CONNECT_AUDIO:case DISCONNECT_AUDIO:deferMessage(message);break;case CONNECT_TIMEOUT: {BluetoothDevice device = (BluetoothDevice) message.obj;if (!mDevice.equals(device)) {stateLogW("CONNECT_TIMEOUT for unknown device " + device);break;}stateLogW("CONNECT_TIMEOUT");transitionTo(mConnected);break;}default: //因为没有101常量值匹配，走defaultreturn super.processMessage(message);}return HANDLED;}

再看看super.processMessage(msg);上代码

 /*** Handle common messages in connected states. However, state specific messages must be* handled individually.** @param message Incoming message to handle* @return True if handled successfully, False otherwise*/@Overridepublic boolean processMessage(Message message) {switch (message.what) {... case STACK_EVENT: //此时走了该case，因为子类把message也传过来了HeadsetStackEvent event = (HeadsetStackEvent) message.obj;stateLogD("STACK_EVENT: " + event);if (!mDevice.equals(event.device)) {stateLogE("Event device does not match currentDevice[" + mDevice+ "], event: " + event);break;}switch (event.type) { //拿到底层给的event数据case HeadsetStackEvent.EVENT_TYPE_CONNECTION_STATE_CHANGED:processConnectionEvent(message, event.valueInt);break;case HeadsetStackEvent.EVENT_TYPE_AUDIO_STATE_CHANGED://正好type值匹配的该条caseprocessAudioEvent(event.valueInt); //该方法是AudioConnecting连接阶段的一个回调方法，而event.valueInt == 1,也就是state == 1break;...}break;default:stateLogE("Unexpected msg " + getMessageName(message.what) + ": " + message);return NOT_HANDLED;}return HANDLED;}

这时回到了AudioConnecting连接状态的processAudioEvent方法，上面已经提到过了，再来看一遍

@Overridepublic void processAudioEvent(int state) {//此时为1switch (state) {case HeadsetHalConstants.AUDIO_STATE_DISCONNECTED:stateLogW("processAudioEvent: audio connection failed");transitionTo(mConnected);break;case HeadsetHalConstants.AUDIO_STATE_CONNECTING://该常量值：1// ignore, already in audio connecting statebreak;case HeadsetHalConstants.AUDIO_STATE_DISCONNECTING:// ignore, there is no BluetoothHeadset.STATE_AUDIO_DISCONNECTINGbreak;case HeadsetHalConstants.AUDIO_STATE_CONNECTED://该常量值：2stateLogI("processAudioEvent: audio connected");transitionTo(mAudioOn);break;default:stateLogE("processAudioEvent: bad state: " + state);break;}}

而刚好state为1,走的 case HeadsetHalConstants.AUDIO_STATE_CONNECTING，导致直接break;什么事情都没做，如果此时state为2，则进入case HeadsetHalConstants.AUDIO_STATE_CONNECTED，再调用transitionTo(mAudioOn);进行状态切换，就一切正常了，那么基于之前的一些疑问，在这里就已经解决了

分析完上层，接着看底层是怎么把state值回调到上层的。

3.4 底层状态分析

com_android_bluetooth_hfp.cpp

void AudioStateCallback(bluetooth::headset::bthf_audio_state_t state,RawAddress* bd_addr) override {ALOGI("%s, %d for %s", __func__, state, bd_addr->ToString().c_str());std::shared_lock<std::shared_timed_mutex> lock(callbacks_mutex);CallbackEnv sCallbackEnv(__func__);if (!sCallbackEnv.valid() || !mCallbacksObj) return;ScopedLocalRef<jbyteArray> addr(sCallbackEnv.get(), marshall_bda(bd_addr));if (!addr.get()) return;// (jint)state 该值将回调到上层sCallbackEnv->CallVoidMethod(mCallbacksObj, method_onAudioStateChanged,(jint)state, addr.get());}

接着跟踪state值怎么拿到的

btif_hf.cc

bt_status_t HeadsetInterface::ConnectAudio(RawAddress* bd_addr) {CHECK_BTHF_INIT();int idx = btif_hf_idx_by_bdaddr(bd_addr);if ((idx < 0) || (idx >= BTA_AG_MAX_NUM_CLIENTS)) {BTIF_TRACE_ERROR("%s: Invalid index %d", __func__, idx);return BT_STATUS_FAIL;}/* Check if SLC is connected */if (!IsSlcConnected(bd_addr)) {LOG(ERROR) << ": SLC not connected for " << *bd_addr;return BT_STATUS_NOT_READY;}// 注意看do_in_jni_thread(base::Bind(&Callbacks::AudioStateCallback,// Manual pointer management for nowbase::Unretained(bt_hf_callbacks),BTHF_AUDIO_STATE_CONNECTING,//该值就是state，而恰好这个常量就是1,上层也是卡在connecting无法执行&btif_hf_cb[idx].connected_bda));BTA_AgAudioOpen(btif_hf_cb[idx].handle);return BT_STATUS_SUCCESS;
}

BTHF_AUDIO_STATE_CONNECTING该值就是state =1 ，说明还没执行完就在这卡住了，所以上层也会卡在connecting。如果继续执行的话 --看代码

static void btif_hf_upstreams_evt(uint16_t event, char* p_param) {...case BTA_AG_WBS_EVT: //先走这条case，用于编解码音频BTIF_TRACE_DEBUG("BTA_AG_WBS_EVT Set codec status %d codec %d 1=CVSD 2=MSBC",p_data->val.hdr.status, p_data->val.num);//如果p_data->val.num = 1则执行CVSD编码，为2的话走MSBC编码if (p_data->val.num == BTA_AG_CODEC_CVSD) {bt_hf_callbacks->WbsCallback(BTHF_WBS_NO,&btif_hf_cb[idx].connected_bda);} else if (p_data->val.num == BTA_AG_CODEC_MSBC) {bt_hf_callbacks->WbsCallback(BTHF_WBS_YES,&btif_hf_cb[idx].connected_bda);} else {bt_hf_callbacks->WbsCallback(BTHF_WBS_NONE,&btif_hf_cb[idx].connected_bda);}break;...case BTA_AG_AUDIO_OPEN_EVT://然后走这条case，把state=2回调给上层bt_hf_callbacks->AudioStateCallback(BTHF_AUDIO_STATE_CONNECTED,&btif_hf_cb[idx].connected_bda);break;...
}

btif_hf_upstreams_evt方法会被多次执行，具体怎么执行的暂不清楚，上面很关键的两条case，选择音频编解码和state=2回调到上层，但是我遇到的问题就是只走了编解码，state=2的case没有执行

至此整个流程差不多就要结束了，回到上层来，既然状态机的各个阶段都正常的话，是不是该把广播发出去，通知各个方法。接着看到broadcastStateTransitions()方法，它在每个状态机阶段都会执行一次，发送不同阶段的广播以便于知道执行到哪个阶段了

void broadcastStateTransitions() {if (mPrevState == null) {return;}// TODO: Add STATE_AUDIO_DISCONNECTING constant to get rid of the 2nd part of this logicif (getAudioStateInt() != mPrevState.getAudioStateInt() || (mPrevState instanceof AudioDisconnecting && this instanceof AudioOn)) {stateLogD("audio state changed: " + mDevice + ": " + mPrevState + " -> " + this);broadcastAudioState(mDevice, mPrevState.getAudioStateInt(), getAudioStateInt());//发送当前的device和上一个状态和当前状态，这个状态指的是每个状态机的 getAudioStateInt 方法返回的值 ，AudioConnecting状态机的返回值=11,AudioOn状态机的返回值=12}if (getConnectionStateInt() != mPrevState.getConnectionStateInt()) {stateLogD("connection state changed: " + mDevice + ": " + mPrevState + " -> " + this);broadcastConnectionState(mDevice, mPrevState.getConnectionStateInt(),getConnectionStateInt());}}//发送广播void broadcastAudioState(BluetoothDevice device, int fromState, int toState) {stateLogD("broadcastAudioState: " + device + ": " + fromState + "->" + toState);StatsLog.write(StatsLog.BLUETOOTH_SCO_CONNECTION_STATE_CHANGED,mAdapterService.obfuscateAddress(device),getConnectionStateFromAudioState(toState),TextUtils.equals(mAudioParams.get(HEADSET_WBS), HEADSET_AUDIO_FEATURE_ON)? BluetoothHfpProtoEnums.SCO_CODEC_MSBC: BluetoothHfpProtoEnums.SCO_CODEC_CVSD);mHeadsetService.onAudioStateChangedFromStateMachine(device, fromState, toState);Intent intent = new Intent(BluetoothHeadset.ACTION_AUDIO_STATE_CHANGED);//写入当前state状态intent.putExtra(BluetoothProfile.EXTRA_PREVIOUS_STATE, fromState);intent.putExtra(BluetoothProfile.EXTRA_STATE, toState);intent.putExtra(BluetoothDevice.EXTRA_DEVICE, device);mHeadsetService.sendBroadcastAsUser(intent, UserHandle.ALL,HeadsetService.BLUETOOTH_PERM);}

该广播会在BtHelper.java#receiveBtEvent中接收

    @GuardedBy("AudioDeviceBroker.mDeviceStateLock")/*package*/ synchronized void receiveBtEvent(Intent intent) {final String action = intent.getAction();if (action.equals(BluetoothHeadset.ACTION_ACTIVE_DEVICE_CHANGED)) {...} else if (action.equals(BluetoothHeadset.ACTION_AUDIO_STATE_CHANGED)) {boolean broadcast = false;int scoAudioState = AudioManager.SCO_AUDIO_STATE_ERROR;int btState = intent.getIntExtra(BluetoothProfile.EXTRA_STATE, -1);//拿到state值// broadcast intent if the connection was initated by AudioService...switch (btState) {// 正常的话 state状态值为12case BluetoothHeadset.STATE_AUDIO_CONNECTED://该值=12scoAudioState = AudioManager.SCO_AUDIO_STATE_CONNECTED;if (mScoAudioState != SCO_STATE_ACTIVE_INTERNAL&& mScoAudioState != SCO_STATE_DEACTIVATE_REQ) {mScoAudioState = SCO_STATE_ACTIVE_EXTERNAL;}//开启SCO服务，再执行startBluetoothScoOnmDeviceBroker.setBluetoothScoOn(true, "BtHelper.receiveBtEvent");break;...case BluetoothHeadset.STATE_AUDIO_CONNECTING://该值=11if (mScoAudioState != SCO_STATE_ACTIVE_INTERNAL&& mScoAudioState != SCO_STATE_DEACTIVATE_REQ) {mScoAudioState = SCO_STATE_ACTIVE_EXTERNAL;}break;default:// do not broadcast CONNECTING or invalid statebroadcast = false;break;}//当state=12时，broadcast=true，代码没贴进来--作用是建立SCO服务if (broadcast) {broadcastScoConnectionState(scoAudioState);...Intent newIntent = new Intent(AudioManager.ACTION_SCO_AUDIO_STATE_CHANGED);newIntent.putExtra(AudioManager.EXTRA_SCO_AUDIO_STATE, scoAudioState);sendStickyBroadcastToAll(newIntent);}}}
